Intel Itanium 2 Processor Datasheet page 51

Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 14 of 15)
Pin Name
STBP2#
STBP3#
STBP4#
STBP5#
STBP6#
STBP7#
TCK
TDI
TDO
TERMA
TERMB
THRMTRIP#
THRMALERT#
TMS
TND#
TRDY#
TRST#
TUNER[1]
TUNER[2]
VCCMON
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
VCTERM
Datasheet
System Bus Pin
Signal Name Location
STBP2# E11
STBP3# M10
STBP4# E17
STBP5# M16
STBP6# E23
STBP7# M22
TCK AG09
TDI AG07
TDO AH07
FSBT1 AF02
FSBT2 AE03
THRMTRIP# AG25
THRMALERT# A07
TMS AH09
TND# AC15
TRDY# AF14
TRST# AE21
TUNER[1] AH03
TUNER[2] AG03
VCCMON A11
VCTERM A02
VCTERM A06
VCTERM A10
VCTERM A14
VCTERM A18
VCTERM A22
VCTERM A25
VCTERM C01
VCTERM C04
VCTERM C08
VCTERM C12
VCTERM C16
VCTERM C20
VCTERM C24
VCTERM E02
VCTERM E06
VCTERM E10
VCTERM E14
VCTERM E18
VCTERM E22
VCTERM G01
Pinout Specifications
Input/Output Notes
IN/OUT
IN/OUT
IN/OUT
IN/OUT
IN/OUT
IN/OUT
IN JTAG
IN JTAG
OUT JTAG
IN
IN
OUT
OUT
IN JTAG
IN/OUT
IN
IN JTAG
OUT Power pod signal
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
51
