Number Name
Here you can make settings for the preamp and compressor of the input channel whose input channel
indicator is lit (p . 19–p . 22) .
[SENS] knob
[AUTO-SENS] button
[PHASE] button
6
[LoCUT] button
[48V] button
[COMPRESSOR] button
[THRESHOLD] knob
GR indicator
[DIRECT MONITOR] knob
7
[MONITOR OUT LEVEL]
knob
[PHONES LEVEL 1],
8 [PHONES LEVEL 2] knobs
PHONES 1, 2 jacks
* The explanations in this manual include illustrations that depict what should typically be
shown by the display . Note, however, that your unit may incorporate a newer, enhanced
version of the system (e .g ., includes newer sounds), so what you actually see in the display may
not always match what appears in the manual .
Explanation
Adjusts the preamp gain of the input channel (p . 20) .
Automatically sets the level optimally for the audio input signal (p . 20) .
Inverts the polarity of the audio input signal (p . 20) .
Applies a low-cut filter to the audio input signal (p . 20) .
Supplies phantom power to the input channel (p . 20) . Turn this on if phantom
power is required, such as when a condenser mic is connected .
Applies a compressor to the audio input signal (p . 22) .
Adjusts the level at which the compressor is applied (p . 22) .
This will light when the compressor is being applied .
Adjusts the level of the audio signal that is output from the input channel
mixer (DIRECT MONITOR; refer to the separate "Block Diagram" leaflet) .
Adjusts the level of the audio signals that are output from MONITOR OUT
1L and 2R (LINE OUT 1L and 2R jacks) (refer to the separate "Block Diagram"
leaflet) .
The [PHONES LEVEL 1] and [PHONES LEVEL 2] knobs adjust the level of the
audio signals that are output from the PHONES 1 and 2 jacks, respectively .
You can connect headphones to these jacks .
