Comtech EF Data CDM-Qx Installation And Operation Manual page 253

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Appendix C
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
BUC Output BOE= 1 byte, value of
Enable 0,1
BUC Output N/A 4 bytes
Power Level
BUC PLL N/A 1 byte, value of
Alarm 0,1
BUC Power BPC= 1 byte, value of
Control 0,1
BUC Software N/A 3 bytes
Version
BUC N/A 4 bytes
Temperature
Description of Arguments
Query
Command or Query.
Note: Valid when the BUC FSK comms and BUC power are
enabled.
Indicates BUC Output enable in the form x, where:
0=Off (Output Disabled)
1=On(Output Enabled)
Example: BOE=1 (BUC Output is Enabled)
Query only.
BUC output power level in the form xxx, where xxx is the value in
watts.
Returns 00.0 when FSK and BUC power are not enabled.
Example: BOL=08.3 (BUC reports output is 8.3 watts)
Query only.
Note: Valid only when the FSK and BUC power are turned On.
Sets BUC PLL lock state in the form x, where:
0=Unlocked
1=Locked
Example: BPA=1 (BUC PLL is locked)
Command or Query.
Sets BUC power in the form x, where:
0=Disable BUC DC Power
1=Enable BUC DC Power
Query only.
Note: Valid only when the FSK and BUC power are turned On.
Indicates the BUC software version in the form x.x.
Example: BSV=1.1 (Software version 1.1)
Query only.
Note: Valid only when the FSK and BUC power are turned On.
Indicates BUC temperature, in the form sxxx, where:
s=sign (+ or – character)
xx=value
If not available, response is –99
Example: BUT=-13 (BUC temperatures is -13°C)
Response to
Command
BOE=
BOE?
BOE*
BOE#
BOE^
N/A
N/A
BPC=
BPC?
BPC*
BPC#
BPC^
N/A
N/A
C–35
Revision 7
MN/CDMQX.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
BOE? BOE=x
(see Description of
Arguments)
BOL? BOL=xx.x
(see Description of
Arguments)
BPA? BPA=x
(see Description of
Arguments)
BPC? BPC=x
(see Description of
Arguments)
BSV? BSV=x.x
(see Description of
Arguments)
BUT? BUT=sxx
(see Description of
Arguments)
