Comtech EF Data CDM-Qx Installation And Operation Manual page 133

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Ethernet Management
The modem supports both SNMPv1 traps and SNMPv2 notifications. Which style of traps the
modem sends can be configured by the user via the cdmQxSNMPTrapVersion OID.
The following are the MIB2 v1traps/v2 notifications that the modem supports:
MIB2 SNMPv1 trap: Authentication Failure
MIB2 SNMPv2 notifications: Authentication Failure
The following tables are the Alarms and Faults v1 traps / v2 notifications that the modem supports.
Alarms and Faults SNMPv1 traps:
cdmQxTxTrafficAlarmV2
cdmQxUnitAlarmV2
cdmQxRxTrafficAlarmV2
Alarms and Faults SNMPv2 notifications:
cdmQxUnitAlarm
cdmQxTxTrafficAlarm
cdmQxRxTrafficAlarm
6–3
Revision 7
MN/CDMQX.IOM
5
1.3.6.1.6.3.1.1.5.5
6247272
6247271
6247273
1.3.6.1.4.1.6247.34.2.0.1
1.3.6.1.4.1.6247.34.2.0.2
1.3.6.1.4.1.6247.34.2.0.3
