Comtech EF Data CDM-Qx Installation And Operation Manual page 231

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Appendix C
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
RX Buffer RBS= 1 byte, value of
Size 0 through 6
RX Data RCI= 1 byte, value of
Clock Invert 0, 1
RX Data RDI= 1 byte, value of
Invert 0, 1
RX RDS= 1 byte, value of
Descrambler 0 1, 2
RX RFQ= 9 bytes
Frequency
Description of Arguments
Query
Command or Query.
RX Buffer size in the form x, where:
0=Buffer disabled
1=± 512 bits
2=± 1024 bits
3=± 2048 bits
4=± 4096 bits
5=± 8192 bits
6=± 16384 bits
Example: RBS=0
Command or Query.
Invert Receive Data Clock in the form x, where:
0=Normal
1=Inverted
Command or Query.
Invert Receive Data in the form x, where:
0=Normal
1=Inverted
Example: RDI=1 (Inverted RX Data)
Command or Query.
RX Descrambler state in the form x, where:
0=Off
1=On (default descrambler type)
2=On (IESS-315 Turbo only)
Command or Query.
Tx Frequency in the form xxxx.xxxx, where:
0950.0000 to 1950.0000 MHz (for L-Band units), 0050.0000 to
0090.0000 or 0100.0000 to 0180.0000 MHz ( for 70/140 MHz units)
Resolution = 100 Hz
Example: RFQ=0950.9872
Response to
Command
RBS=
RBS?
RBS*
RBS#
RBS$
RBS^
RBS@
RCI=
RCI?
RCI*
RCI#
RCI$
RCI^
RCI@
RDI=
RDI?
RDI*
RDI#
RDI$
RDI^
RDI@
RDS=
RDS?
RDS*
RDS#
RDS$
RDS^
RDS@
RFQ=
RFQ?
RFQ*
RFQ#
RFQ$
RFQ^
RFQ@
C–13
Revision 7
MN/CDMQX.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
RBS? RBS=x
(see description of
arguments)
RCI? RCI=x
(see Description of
Arguments)
RDI? RDI=x
(see Description of
Arguments)
RDS? RDS=x
(see Description of
Arguments)
RFQ? RFQ=xxxx.xxxx
(see Description of
Arguments)
