CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Appendix C
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Retrieve next
N/A
80 bytes
5 unread
stored Events
Retrieved
N/A
130 bytes
next 5 unread
Stored
Statistics
(Modem Only)
Description of Arguments
Query
Query only.
Unit returns the oldest 5 Stored Events, which have not yet been
read over the remote control, in the form {CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}, where Sub-
body = ABCCddmmyyhhmmss, where:
A being the fault/clear indicator
F=Fault
C=Clear
I =Info
B being the fault type where:
1=Unit
2=RX Traffic on Slot#1
3=RX Traffic on Slot#2
4=RX Traffic on Slot#3
5=RX Traffic on Slot#4
6=TX Traffic on Slot#1
7=TX Traffic on Slot#2
8=TX Traffic on Slot#3
9=TX Traffic on Slot#4
A=ODU
B=Power ON/OFF, or log cleared
CC is Fault Code numbers, as in FLT? Or Infor Code, which is:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
If there are less than 5 events to be retrieved, the remaining
positions are padded with zeros.
If there are no new events, the response is RNE*.
Query only.
Unit returns the oldest 5 Stored Statistics, which have not yet been
read over the remote control, in the form {CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR}Sub-body{CR}Sub-body, where Sub-
body=AA.ABB.BC.CD.Dddmmyyhhmmss, where:
AA.A Minimum Eb/No during sample period
BB.B=Average Eb/No during sample period
C.C=Max. TX Power Level Increase during sample period
D.D=Average TX Power Level during sample period
ddmmyyhhmmss=date/time stamp
If there are no new events, the unit replies with RNS* If there are
less than 5 statistics to be retrieved, the remaining positions are
padded with zeros.
Response to
Command
N/A
N/A
C–29
Revision 7
MN/CDMQX.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
RNE?
RNE=
{CR}ABCCddmmyyhhmms
s{CR}ABCCddmmyyhhmm
ss{CR}ABCCddmmyyhhm
mss{CR}ABCCddmmyyhh
mmss{CR}ABCCddmmyyh
hmmss
(see Description of
Arguments)
RNS?
RNS={CR}
AA.ABB.BC.CD.Dddmmyy
hhmmss{CR}
AA.ABB.BC.CD.Dddmmyy
hhmmss{CR}
AA.ABB.BC.CD.Dddmmyy
hhmmss{CR}
AA.ABB.BC.CD.Dddmmyy
hhmmss{CR}
AA.ABB.BC.CD.Dddmmyy
hhmmss
(see Description of
Arguments)
