Comtech EF Data CDM-Qx Installation And Operation Manual page 237

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Appendix C
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Group GRP 1 byte
HSSI HHC= 1 byte, value of
handshake 0,1
control (valid
only for HSSI
interface)
Initialize IEP= None
Events
Pointer
IP Address IPA= 18 bytes
numerical
Internal IRA= 5 bytes,
Reference numeric
Oscillator
Adjust
Description of Arguments
Query
Command or Query.
Group a modulator/demodulator pair into a modem. A grouped mod
and demod will respond to either address, in the form x, where:
0=Both sides ungrouped
1=Left side (as viewed from back of chassis) grouped
2=Right side grouped
3=Both sides grouped
Example: GRP=3 (both sides of chassis are grouped into modems)
Command or Query.
Defines how TA/CA control the HSSI interface, where:
0 = TA to CA loop (default)
1 = RR control CA, TA control Tx output.
Example: HHC=0 (TA to CA loop)
Command only.
Resets internal pointer to allow RNE? Queries to start at the
beginning of the stored events log.
Command or Query.
Sets the IP Address and network prefix for the 10/100 BaseT Ethernet
management port, in the format xxx.xxx.xxx.xxx.yy where:
yy is the network prefix (0 to 31)
Example: 010.006.030.001.24
Command or Query.
Fine adjustment to the internal reference oscillator tuning voltage,
thereby, fine tuning the required internal reference frequency, in the
form sxxxx, where:
s = sign (- or +)
xxxx=Range: -2048 to +2047.
Example: IRA=+0192
Response to
Command
GRP=
GRP?
GRP*
GRP#
GRP$
GRP^
HHC=
HHC?
HHC*
HHC#
HHC^
IEP=
IEP#
IEP^
IPA=
IPA?
IPA*
IPA#
IRA=
IRA?
IRA*
IRA#
IRA^
C–19
Revision 7
MN/CDMQX.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
GRP? GRP=x
HHC? HHC=x
(see Description of
Arguments)
N/A N/A
IPA? IPA=xxx.xxx.xxx.xxx.yy
(see Description of
Arguments)
IRA? IRA=x
(see Description of
Arguments)
