CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Appendix C
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Internal IRM= 5 bytes
Redundancy
Mode
Initialize ISP= None
Statistics
Pointer
T1 Line LBO= 1 byte, value of
Build-Out 0 though 4
Local/Remote LRS= 1 byte, value of
Status 0, 1
Description of Arguments
Query
Command or Query.
Redundancy mode in the form x,abc, where:
For x:
0 = No Redundancy
1=1:1 modem (back-up modules at Slot#3 and Slot#4), or
1:1 Tx (back-up Tx on Slot#4), or
1:1 Rx (back-up Rx on Slot#4)
2=1:2 Tx, or 1:2 Rx (back-up module on Slot#4)
3=1:3 Tx, or 1:3 Rx (back-up module on Slot#4)
4=Reserved
For abc:
000=no redundancy or 1:1 modem or 1:3 Tx or 1:3 Rx.
If a=1, Slot#1 is selected as primary, otherwise it's not.
If b=1, Slot#2 is selected as primary, otherwise it's not.
If c=1, Slot#3 is selected as primary, otherwise it's not.
Note: The settings on a,b, and c fields are only required if Qx is in 1:1
Tx or 1:1 Rx or 1:2 Tx or 1:2 Rx .
Example: IRM =1,000 (1:1 modem)
IRM =1,010 (1:1 Tx or 1:1 Rx with primary at Slot#2)
Command only.
Resets internal pointer to allow RNS? Queries to start at the
beginning of the statistics log.
Command or Query.
Valid only for T1 interface in the form x, where:
0=0 to 133 feet
1=133 to 266 feet
2=266 to 399 feet
3=399 to 533 feet
4=533 to 655 feet
Example: LBO=2
Command or Query.
Local/Remote status in the form x, where:
0=Local
1=Serial Remote
3=Ethernet Remote
Example: LRS=1 (Serial Remote)
Response to
Command
IRM =
IRM?
IRM*
IRM#
IRM$
IRM^
ISP=
ISP#
ISP^
LBO=
LBO?
LBO*
LBO#
LBO$
LBO^
LBO@
LRS=
LRS?
LRS*
LRS#
C–20
Revision 7
MN/CDMQX.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
IRM? IRM = x,abc
(see Description of
Arguments
N/A N/A
LBO? LBO=x
(see Description of
Arguments)
LRS? LRS=x
(see Description of
Arguments)
