Ethernet Management
Modem Group
(Available only on the Base nested Config page) – To create a modem group from the available
installed modulator and demodulator modules, click on Group 1 or Group 2, then click [Set
Group]. Note the following:
•
Note that, if Group 1 is defined, the unit will take the modulator and demodulator
modules installed in Slot#1 and Slot#2, respectively, and group them. The individual Tx
and Rx icons in those slot positions will be replaced with the MD icon, which will
display in the Slot#1 icon position.
•
Similarly, if Group 2 is defined, the unit will take the modulator and demodulator
module pair installed in Slot#3 and Slot#4, respectively, and group them. The individual
Tx and Rx icons in those slot positions will be replaced with the MD icon, which will
display in the Slot#3 icon position.
•
Deselecting either Group will separate the paired modules for that group back to
independent Tx and Rx operation.
Internal Redundancy
(Available only on the Base nested Config page) – Note that, in a non-modem configuration, the
backup device must be installed in Slot#4.
•
Configuration – Use the drop-down menu to select the redundant configuration as OFF
or ON.
•
Primary Slot # – Select No or Yes to set the modules installed in Slots 1, 2 and 3 as
Primary.
Click [Set Redundancy] when done.
Redundancy Mode
(Available only on the Base nested Config page) – Using the drop-down menus:
•
Mode – Select Manual or Auto.
•
Forced BackUp – Select None, Slot1, Slot2, or Slot3.
Click [Submit] when done.
Frequency Reference
(Available only on the Base nested Config page) – Use the drop-down Reference menu to select
Internal 10MHz, External 1MHz, External 2MHz, External 5MHz, External 10MHz,
External 20MHz, Output 10MHz, or External Auto.
Click [Submit] when done.
Interface / Framing
The available configuration parameters available in this section will change
depending on the installed data interface. This section must be configured before
setting any other operating parameters.
IMPORTANT
(Available on the Tx, Rx, and MD nested Config pages) – Click [Submit] once all the parameters
have been set in this section.
6–18
Revision 7
MN/CDMQX.IOM
