D Band edge warning beep

Ths functon allows you to hear a beep tone when you tune
n or out of an amateur band's frequency range. A regular
beep sounds when you tune nto a range, and an lower
tone error beep wll sound when you tune out of a range.
Also, the TX ndcator shows f the selected frequency
s n or out of an amateur band, when an opton other
than "OFF" s set.
• A TX ndcator wth a doted, "
the regular "
of an amateur band frequency range s selected.
q Push [EXIT/SET] several tmes to close any mult-
functon screens, f necessary.
w Push [SET] (F-6) to select the set mode menu screen.
• Pushng and holdng [EXIT/SET] for 1 sec. also selects
the set mode menu screen.
e Push [OTHERS] (F-5) to select the Others set mode.
r Push [Y] (F-1) or [Z] (F-2) to select "Beep (Band
Edge)."
t Rotate the man dal to select the desred band
edge warnng beep settng.
• OFF : Band edge beep s OFF.
• ON (Default) : When you tune nto or out of the default
amateur band's frequency range, a beep
sounds. (default)
• ON (User) : When you tune outsde of, or back nto
a user programmed amateur band's fre-
quency range, a beep sounds.
• ON (User) & TX Lmt
: When you tune outsde of, or back nto a
user programmed amateur band's frequency
range, a beep sounds. Transmsson s also
nhbted outsde the programmed range.
y Push [EXIT/SET] to ext the set mode.
The beep output level can be set n the level set
mode. (p. 123)
To programming the band edge:
q Perform the steps q to t as shown above, then select
ether "ON (User)" or "ON (User) & TX Lmt" settng.
• [BAND] appears above the functon swtch (F-5).
w Push [BAND] (F-5) to open the band edge screen.
e Push [Y] (F-1) or [Z] (F-2) to select the desred
band edge.
• Push [Ω ≈] (F-3) to select the upper and lower band
edge frequency entry cell.
• Push [INS] (MF6) to nsert a new blank band edge lne.
• Push and hold [DEL] (MF7) for 1 sec. to delete the
selected band edge lne.
r Input the desred frequency wth the keypad, then
push [F-INP•ENT].
• Push [GENE •] to nput decmal pont (".") between the
MHz and kHz dgts.
• Program each channel from left to rght and each fre-
quency must be hgher than the precedng frequency.
• The frequency that s duplcated, or out of an amateur
band, cannot be programmed.
• If you want to return the band edge frequences to ther de-
fault (ntal) value, push and hold [DEF] (F-4) for 1 sec.
The band edge ntalze screen appears, then push and
hold [OK] (F-5) for 1 sec. to ntalze all band edge fre-
quency settngs.
t Push [EXIT/SET] to ext the set mode.
31
" s dsplayed, nstead of
" TX ndcator, when a frequency outsde
When the transverter functon s n use, the band
edge warnng beep sounds wth the default settng.
OTHERS
F-5
F-1 F-2
ON (Default)
Appears when "ON (User)" or
"ON (User) & TX Lmt" s selected,
ON (User)
BAND
[DEL] [INS]
F-1 F-2 F-3
• Band edge screen
NOTE: All frequency ranges are set n default. So
you should delete or change t to add the desred
band edge frequency.
