4
RECEIVE AND TRANSMIT
D Scope set mode (contnued)
Sweep Speed
Select the sweep speed for the ±25 kHz span selec-
ton from SLOW, MID and FAST.
Sweep Speed
Select the sweep speed for the ±50 kHz span selec-
ton from SLOW, MID and FAST.
Sweep Speed
Select the sweep speed for the ±100 kHz span
selecton from SLOW, MID and FAST.
Sweep Speed
Select the sweep speed for the ±250 kHz span
selecton from SLOW, MID and FAST.
Fixed Edges
Set the scope edge frequences for fixed mode for
bands below 1.6 MHz.
Fixed Edges
Set the scope edge frequences for fxed mode
scope when the 1.6 to 2 MHz band s selected.
Fixed Edges
Set the scope edge frequences for fxed mode
scope when the 2 to 6 MHz band s selected.
Fixed Edges
Set the scope edge frequences for fxed mode
scope when the 6 to 8 MHz band s selected.
69
(± 25k)
(± 50k)
(± 100k)
(± 250k)
( 0.03 − 1.60)
( 1.60 − 2.00)
( 2.00 − 6.00)
( 6.00 − 8.00)
FAST
FAST
FAST
FAST
0.750 − 1.250 MHz
• Set the frequences wthn 0.030 to 1.600 MHz
range n 1 kHz steps.
As edge frequences are set, the other edge fre-
quency wll be automatcally set for a dsplay band
wdth of 5 kHz to a maxmum of 500 kHz.
1.800 − 2.000 MHz
• Set the frequences wthn 1.600 to 2.000 MHz
range n 1 kHz steps.
3.500 − 4.000 MHz
• Set the frequences wthn 2.000 to 6.000 MHz
range n 1 kHz steps.
As edge frequences are set, the other edge fre-
quency wll be automatcally set for a dsplay band
wdth of 5 kHz to a maxmum of 500 kHz.
7.000 − 7.300 MHz
• Set the frequences wthn 6.000 to 8.000 MHz
range n 1 kHz steps.
As edge frequences are set, the other edge fre-
quency wll be automatcally set for a dsplay band
wdth of 5 kHz to a maxmum of 500 kHz.
