■ Repeater operation

A repeater retransmts a receved sgnal on a dffer-
ent frequency. When usng a repeater, the transmt
frequency s shfted from the receve frequency by an
offset frequency. A repeater can be accessed usng
splt frequency operaton wth the transmt frequency
shfted to the repeater's receve frequency.
For accessng a repeater whch requres an access
tone, set the tone frequency n the tone frequency
set mode as descrbed below.
q Frst, set the offset frequency for HF and 50 MHz
bands n "FM SPLIT Offset (HF)" and "FM SPLIT
Offset (50M)," and set the quck splt functon to ON
n "Quck SPLIT" n the Others set mode. (p. 129)
w Push [VFO/MEMO] to select the VFO mode.
e Push the desred band key, then set the receve fre-
quency (repeater output frequency).
r Push [AM/FM] several tmes to select the FM mode.
t Push and hold [SPLIT] for 1 sec. to start repeater
operaton.
• Repeater tone s turned ON automatcally.
• [SPLIT] ndcator lghts and "
the LCD.
• The tone encoder functon s turned ON n the FM mode.
• Shfted transmt frequency and "TX" appear n the sub
band.
• The transmt frequency can be montored whle push-
ng [XFC].
y Push and hold [PTT] to transmt; release [PTT] to
receve.
u To return to smplex, push [SPLIT] momentarly.

D Repeater access tone frequency setting

Some repeaters requre subaudble tones to be
accessed. Subaudble tones are supermposed on
your normal sgnal and must be set n advance. The
transcever has 50 tones from 67.0 Hz to 254.1 Hz.
q Durng FM mode operaton, push and hold [TONE]
(MF7) for 1 sec. to select the tone frequency set mode.
w Push [Y] (F-1) or [Z] (F-2) to select REPEATER
TONE tem.
e Rotate the man dal to select the desred repeater
tone frequency.
• Push and hold [DEF] (F-4) for 1 sec. to select the
default settng.
r Push [EXIT/SET] to return to the prevous dsplay.
• Available tone frequencies
67.0 85.4 107.2 136.5
69.3 088.5 110.9 141.3
71.9 091.5 114.8 146.2
74.4 094.8 118.8 151.4
77.0 097.4 123.0 156.7
79.7 100.0 127.3 159.8
82.5 103.5 131.8 162.2
" appears on
(unt: Hz)
165.5 186.2 210.7 254.1
167.9 189.9 218.1
171.3 192.8 225.7
173.8 196.6 229.1
177.3 199.5 233.6
179.9 203.5 241.8
183.5 206.5 250.3
