Removing and replacing the CPU baffle

Removing the CPU baffle

CAUTION:
CPU in each CPU socket. The CPU baffle is needed for proper system cooling
CAUTION:
socket pins, the socket should never be uncovered for more than 5 seconds. If the socket is damaged,
the entire system board must be replaced.
1. power off the server and remove it from the rack
"Remove the server from the rack" (page
2. Remove the access panel
3. Pull the CPU baffle straight up and out.

Replacing the CPU baffle

1. Line the CPU baffle up with 4 load posts on each corner of the socket.
2. Guide the CPU baffle straight down into place.
To prevent damage to the server, never power on a server without a CPU baffle or
Immediately install a CPU baffle in an empty CPU socket. To avoid damage to the
("Removing the access
("power off the server" (page 102)
102)).
panel").
Removing and replacing the CPU baffle
and
