Chapter 31 Configuring Network Security with ACLs
Command
Step 4
match {ip | mac} address {name |
number} [name | number]
Step 5 end
Step 6 show running-config
Step 7
copy running-config startup-config
Use the no vlan access-map name global configuration command to delete a map.
Use the no vlan access-map name number global configuration command to delete a single sequence
entry from within the map.
Use the no action access-map configuration command to enforce the default action, which is to forward.
VLAN maps do not use the specific permit or deny keywords. To deny a packet by using VLAN maps,
create an ACL that would match the packet, and set the action to drop. A permit in the ACL counts as a
match. A deny in the ACL means no match.

Examples of ACLs and VLAN Maps

These examples show how to create ACLs and VLAN maps that for specific purposes.
Example 1
This example shows how to create an ACL and a VLAN map to deny a packet. In the first map, any
packets that match the ip1 ACL (TCP packets) would be dropped. You first create the ip1ACL to permit
any TCP packet and no other packets. Because there is a match clause for IP packets in the VLAN map,
the default action is to drop any IP packet that does not match any of the match clauses.
Switch(config)# ip access-list extended ip1
Switch(config-ext-nacl)# permit tcp any any
Switch(config-ext-nacl)# exit
Switch(config)# vlan access-map map_1 10
Switch(config-access-map)# match ip address ip1
Switch(config-access-map)# action drop
This example shows how to create a VLAN map to permit a packet. ACL ip2 permits UDP packets and
any packets that match the ip2 ACL are forwarded. In this map, any IP packets that did not match any of
the previous ACLs (that is, packets that are not TCP packets or UDP packets) would get dropped.
Switch(config)# ip access-list extended ip2
Switch(config-ext-nacl)# permit udp any any
Switch(config-ext-nacl)# exit
Switch(config)# vlan access-map map_1 20
Switch(config-access-map)# match ip address ip2
Switch(config-access-map)# action forward
OL-9639-07
Purpose
Match the packet (using either the IP or MAC address) against one or more
standard or extended access lists. Note that packets are only matched
against access lists of the correct protocol type. IP packets are matched
against standard or extended IP access lists. Non-IP packets are only
matched against named MAC extended access lists.
Return to global configuration mode.
Display the access list configuration.
(Optional) Save your entries in the configuration file.
Cisco ME 3400 Ethernet Access Switch Software Configuration Guide
Configuring VLAN Maps
31-31
