Icom IC-91A Instruction Manual page 10

2
PANEL DESCRIPTION
D D KEYPAD
KEY
• Inputs digit '1' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "1."
• Inputs digit '2' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "2."
• Inputs digit '3' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "3."
• Inputs digit '4' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "4."
• Inputs digit '5' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "5."
• Inputs digit '6' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "6."
4
Pushed momentarily Pushed and held for 1 sec.
• Displays the simple band scope and sweeps once. (p. 23)
• Starts a scan. (p. 75)
• Toggles the transmit output power between high and low. (p. 24)
- "LOW" appears when low power is selected.
- While pushing and holding this key, with [DIAL] operation also
selects the output power.
• Activates the following duplex functions in order.
- Minus duplex operation— "–DUP" appears.
- Plus duplex operation— "+DUP" appears.
- Simplex operation— no duplex indicator appears.
- While pushing and holding this key, with [DIAL] operation also
selects the duplex function.
• Turn the frequency skip function ON and OFF in VFO mode
(p. 28), or set the memory channel as the following skip chan-
nel in memory mode in order. (p. 28)
- Skip channel— "SKIP" appears.
- Frequency skip channel— "PSKIP" appears.
- Non-skip channel— no skip indicator appears.
• Turn the memory name, bank name indication ON and OFF.
(p. 70)
