Option Tray Pick/Lift Motor Service Check; Option Tray Separator/Pass Through Motor Service Check - Lexmark MS517dn Service Manual

Option tray pick/lift motor service check

Action
Step 1
a
Remove the option tray insert.
b
Check the lift plate and gears for proper operation by moving
the metal plate.
Do the lift plate and gears move freely, and are they free of wear
or damage?
Step 2
Check the pick/lift motor for the following:
•
Gear tooth breakage
•
Freedom of rotation
Is it free of wear or damage?
Step 3
Check the cable J11 on the option tray controller card.
Is it properly connected and free of damage?

Option tray separator/pass through motor service check

Action
Step 1
a
Remove the option tray insert.
b
Check the separator roll assembly gear under the tray base for
the following:
•
Gear tooth breakage
•
Freedom of rotation
Does it move freely, and is it free of wear or damage?
Step 2
Check the cable J10 on the option tray controller card.
Is it properly connected and free of damage?
Step 3
Check the separator roll assembly for wear or damage.
Is it free of wear or damage?
Diagnostics and troubleshooting
162
Yes No
Go to step 2. Replace the tray
insert.
Go to step 3. Replace the tray.
Contact the next Replace the tray.
level of support.
Yes No
Go to step 2. Replace the tray.
Go to step 3. Replace the tray.
Contact the next Replace the
level of support. separator roll
assembly. See
"Separator roll
assembly removal"
on page
4514-6xx
320.
