Component locations

Exterior locations

MS510dn and MS610dn exterior locations

Front view
3
2
1
# Part name
1 Control panel
2 Paper stop
3 Standard bin
4 Front door release button
5 Controller board access door
6 100‑sheet multipurpose feeder
7 Standard tray
8 Optional 250‑ or 550‑sheet tray
Component locations
4
5
6
7
325
4514-6xx
