Technical Data
Information in the Diagnostic Message:
Set error state
Unset error state
Group status
AI status
AO status
BO/BI status
Internal error
Individual
signal
1)
BUS
INT
EXT
AIF
AOF
BOF
BSV BAR 1
BSV BAR 2
AI_1F..AI_12F
AO_1F..AO_8F
BO_1F..BO_12
F
2)
S1_MRES
S1_STOP
2)
S1_RUN
2)
S1_RUN_P
3)
S2_TAST
3)
S2_RAST
CP_F
SV_P24V
SV_P15V
SV_N15V
SV_P20V
SV_N20V
RSS_F
RAM_F
4-28
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1
0
(byte 9, 10) Group display – Combination by ORing individual errors
(byte 11, 12) Individual status of the analog inputs
(byte 13, 14) Individual status of the analog outputs
(byte 15, 16) Individual status of the combined binary outputs and outputs
(byte 17, 18) Individual status of the internal error messages
Forms the Description
group dis-
play
– Corresponding to BUSF (... at S7) display of PROFIBUS DP errors
– Corresponding to INTF display of internal errors
– Corresponding to EXTF display of external faults (channel faults)
– ORing of AIF, AOF, BOF, etc.
EXT Group error analog inputs – ORing of AI_1F to AI_12F
EXT Group error analog outputs – ORing of A0_1F to AO_8F
EXT Group error binary outputs – ORing of DO_1F to DO_16F
– External supply voltage DO 1 ... 8 missing
– External supply voltage DO 9 ... 16 missing
AIF Individual error / qualifier of the analog inputs – are set or reset directly
by the acquisition part.
AOF Individual error / qualifier of the analog outputs (see above)
BOF Individual error / qualifier of the binary outputs (see above)
INT Key switch in position MRES
INT Key switch in position STOP
INT Key switch in position RUN
INT Key switch in position RUN P
INT Slide switch in jogging position (Position 0)
INT Slide switch in notched position (Position 2)
INT Co–processor fault occurred
INT Monitoring of the external supply voltage +24 V has been triggered
INT Monitoring of the internal supply voltage +15 V has been triggered
INT Monitoring of the internal supply voltage –15 V has been triggered
INT Monitoring of the internal supply voltage +20 V has been triggered
INT Monitoring of the internal supply voltage –20 V has been triggered
INT Fault at the optical fiber redundancy interface
INT Check sum correction factors in the RAM invalidated
