Siemens Add 7 AddFEM Manual page 68

AddFEM
Bumping
In operation, mounted by means
of screw fixing device or on DIN
rails (see Section 5.1)
Packed for dispatch
Conductive and corrosive components must be kept away from the AddFEM.
The conditions of use specified in DIN IEC 721 Part 3 Class 3S1 apply for other dust and sand.
Particular points
Quality assurance
AddFEM
C79000–G8076–C900–03
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Mechanical Ambient Conditions (continued)
Tested to DIN EN 60068-2-29:
Half–sine: 10 g (100 m/s
100 shocks per axis
Note: DIN rail design corresponding to DIN EN 50022 (min.
material thickness 2.2 mm). At a rail length of 19" a middle
fastening is required in addition to the side fastening in order to
achieve the rigidity of the rails required to hold the module
firmly.
Tested to DIN EN 60068-2-27:
Half–sine: 25 g (250 m/s
1000 shocks per axis
Dust Endangering The Functionality
Conforming to ISO 9001
Technical Data
2
) for 16 ms
2
) for 6 ms
4-17
