Siemens Add 7 AddFEM Manual page 130

AddFEM
The FEM_AI has the following input parameters (continued):
Parameter Comment
AI8_SIM Simulation Value Analog Input 8
SIMUAI8 1 = Simulation on
AI9_HRG Analog Input 9 High Range
AI9_LRG Analog Input 9 Low Range
AI9_SIM Simulation Value Analog Input 9
SIMUAI9 1 = Simulation on
AI10_HRG Analog Input 10 High Range
AI10_LRG Analog Input 10 Low Range
AI10_SIM Simulation Value Analog Input 10
SIMUAI10 1 = Simulation on
AI11_HRG Analog Input 11 High Range
AI11_LRG Analog Input 11 Low Range
AI11_SIM Simulation Value Analog Input 11
SIMUAI11 1 = Simulation on
AI12_HRG Analog Input 12 High Range
AI12_LRG Analog Input 12 Low Range
AI12_SIM Simulation Value Analog Input 12
SIMUAI12 1 = Simulation on
CO1_NUM Number of Teeth for Counter 1
CO1_SIM Simulation Value Counter 1
SIMCO1 1 = Simulation on
CO2_NUM Number of Teeth for Counter 2
CO2_SIM Simulation Value Counter 2
SIMUCO2 1 = Simulation on
CO3_NUM Number of Teeth for Counter 3
CO3_SIM Simulation Value Counter 3
SIMUCO3 1 = Simulation on
AddFEM
C79000–G8076–C900–03
