Commissioning / Operation / Maintenance
The FEM_AI has the following input parameters:
Table 5-7 Input parameters of the FEM_AI
Parameter Comment
G_ADR_1A Geografical Address Interface A Unit 1
G_ADR_1B Geografical Address Interface B Unit 1
G_ADR_2A Geografical Address Interface A Unit 2
G_ADR_2B Geografical Address Interface B Unit 2
MASTER Set Master (no failure state)
0 = Unit 1 is master
1 = Unit 2 is master
FEF_EN 1 = Front End Function enabled
DBNRFEF Data Block Number FEF Input Parameter
AI1_HRG Analog Input 1 High Range
AI1_LRG Analog Input 1 Low Range
AI1_SIM Simulation Value Analog Input 1
SIMUAI1 1 = Simulation on
AI2_HRG Analog Input 2 High Range
AI2_LRG Analog Input 2 Low Range
AI2_SIM Simulation Value Analog Input 2
SIMUAI2 1 = Simulation on
AI3_HRG Analog Input 3 High Range
AI3_LRG Analog Input 3 Low Range
AI3_SIM Simulation Value Analog Input 3
SIMUAI3 1 = Simulation on
AI4_HRG Analog Input 4 High Range
AI4_LRG Analog Input 4 Low Range
AI4_SIM Simulation Value Analog Input 4
SIMUAI4 1 = Simulation on
AI5_HRG Analog Input 5 High Range
AI5_LRG Analog Input 5 Low Range
AI5_SIM Simulation Value Analog Input 5
SIMUAI5 1 = Simulation on
AI6_HRG Analog Input 6 High Range
AI6_LRG Analog Input 6 Low Range
AI6_SIM Simulation Value Analog Input 6
SIMUAI6 1 = Simulation on
AI7_HRG Analog Input 7 High Range
AI7_LRG analog Input 7 Low Range
AI7_SIM Simulation Value Analog Input 7
SIMUAI7 1 = Simulation on
AI8_HRG Analog Input 8 High Range
AI8_LRG Analog Input 8 Low Range
5-48
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Data type Visible Default
INT Yes 0
INT Yes 0
INT Yes 0
INT Yes 0
BOOL Yes 0
BOOL Yes 0
INT Yes 0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 100.0
REAL Yes –100.0
