Siemens Add 7 AddFEM Manual page 143

Commissioning / Operation / Maintenance
The FEM_DO has the following input parameters (continued):
Parameter Comment
SIMUDO12 1 = Simulation on
DO13_VAL Output Value DO13
DO13_SM Simulation Value DO13
SIMUDO13 1 = Simulation on
DO4_VAL Output Value DO14
DO14_SM Simulation Value DO14
SIMUDO14 1 = Simulation on
DO15_VAL Output Value DO15
DO15_SM Simulation Value DO15
SIMUDO15 1 = Simulation on
DO16_VAL Output Value DO16
DO16_SM Simulation Value DO16
SIMUDOO16 1 = Simulation on
The FEM_DO has the following output parameters:
Table 5-14 Output parameters of the FEM_DO
Parameter Comment
BLOCKCNO Block Connector Output
QPARF 1 = Parameter Assignment Failure
QCH1_F 1 = Channel Failure DO1
QCH2_F 1 = Channel Failure DO2
QCH3_F 1 = Channel Failure DO3
QCH4_F 1 = Channel Failure DO4
QCH5_F 1 = Channel Failure DO5
QCH6_F 1 = Channel Failure DO6
QCH7_F 1 = Channel Failure DO7
QCH8_F 1 = Channel Failure DO8
QCH9_F 1 = Channel Failure DO9
QCH10_F 1 = Channel Failure DO10
QCH11_F 1 = Channel Failure DO11
QCH12_F 1 = Channel Failure DO12
QCH13_F 1 = Channel Failure DO13
QCH14_F 1 = Channel Failure DO14
QCH15_F 1 = Channel Failure DO15
QCH16_F 1 = Channel Failure DO16
5-62
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Data type Visible Default
BOOL No 0
BOOL Yes 0
BOOL No 0
BOOL No 0
BOOL Yes 0
BOOL No 0
BOOL No 0
BOOL Yes 0
BOOL No 0
BOOL No 0
BOOL Yes 0
BOOL No 0
BOOL No 0
Data type Default
STRUCT 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
BOOL 0
C79000–G8076–C900–03
AddFEM
AddFEM
