Siemens Add 7 AddFEM Manual page 36

AddFEM
Host: Single–channel
AddFEM in
Operating Mode 2
AddFEM: Redundant with optical–fiber cable redun-
dancy coupling
Fig. 3-3
AddFEM in
Operating Mode 3
Fig. 3-4
AddFEM
C79000–G8076–C900–03
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuration with operating mode 2
Host: Redundant
AddFEM: Redundant with optical–fiber cable redun-
dancy coupling
Configuration with operating mode 3
Mode of Operation
3-9
