General features
Interfaces
PROFIBUS/MPI
PROFINET
Ethernet
USB
Serial
Parallel
Monitor
Keyboard
Mouse
Audio
Power supply
Monitoring functions
Temperature
Fan
Watchdog
Status LEDs
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA
12 Mbps (electrically isolated, compatible with CP 5622),
optional
10/100 Mbps (CP 1616 onboard), three RJ45; optional
2 × 10/100/1000 Mbps (two RJ45)
Wake on LAN, Remote Boot and teaming are supported
2 × front panel, 4 × rear panel, 1 × internal; (high current)
COM1 (V.24), COM2 (V24) optional
LPT, optional
1 × DVI-I (for DVI-D or VGA using cable adapter)
•
2 × DisplayPort
•
2 × DisplayPort / DVI-D/VGA with Dual Head graphics
•
card (optional)
PS/2
PS/2
Microphone, Line out / Headset
100 VAC to 240 VAC, wide range; with short-term power
failure backup in accordance with NAMUR: Max. 20 ms at
0.85 rated voltage
Overshoot/undershoot of permissible operating
•
temperature
Messages can be evaluated by an application program.
•
Speed monitoring
•
Messages can be evaluated by an application program.
•
Monitoring of the IPC
•
Monitoring time can be parameterized in software
•
Restart can be parameterized in the event of a fault
•
Messages can be evaluated by an application program.
•
POWER (internal power supply unit, PC switched On)
•
ETHERNET 1, ETHERNET 2 (Ethernet status)
•
PN Ι MPI/DP (activity display of the PROFIBUS/MPI
•
interface, optional product feature or status display of the
CP 1616 onboard interface, optional product feature)
WATCHDOG (Watchdog function/error display)
•
TEMP (temperature status)
•
FAN (speed monitoring)
•
HDD0 Alarm, HDD1 Alarm, HDD2 Alarm, HDD | HDD3
•
Alarm: Access to hard disk and with RAID option: RAID
status message in conjunction with SIMATIC monitoring
software
Overview
1.1 Product description
