Savin 3350DNP Operating Instructions Manual

Savin printer operating instructions
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3350DNP/5450
OPERATING INSTRUCTIONS
TPEH162N
Read this manual carefully before you use this product and keep it handy for future
reference.
For safety, please follow the instructions in this manual.

Advertisement

Table of Contents
loading

Related Manuals for Savin 3350DNP

Summary of Contents for Savin 3350DNP

  • Page 1 3350DNP/5450 OPERATING INSTRUCTIONS TPEH162N Read this manual carefully before you use this product and keep it handy for future reference. For safety, please follow the instructions in this manual.
  • Page 2 Note to users in the United States of America Notice: This equipment has been tested and found to comply with the limits for a Class A digital devices, pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 3: Safety Information

    Safety Information When using your machine, the following safety precautions should always be followed. Safety During Operation In this manual, the following important symbols are used: R WARNING: Ignoring this warning could cause serious injury or even death. R CAUTION: Ignoring this caution could cause injury or damage to property.
  • Page 4 R Warning: • Only connect the machine to the power source described on the inside front cover of this manual. • Avoid multi-wiring. • Do not damage, break or make any modifications to the pow- er cord. Do not place heavy objects on it, pull it hard or bend it more than necessary.
  • Page 5 R Caution: • Keep the machine away from humidity and dust. A fire or an elec- tric shock might occur. • Do not place the machine on an unstable or tilted surface. If it top- ples over, it could cause injury. •...
  • Page 6 • Keep the ink or ink container out of reach of children. • If ink is ingested, force vomiting by drinking a strong saline solu- tion and consult a doctor immediately. • Be careful not to cut yourself on any sharp edges when you reach inside the machine to remove misfed sheets of paper or masters.

  • Page 7: How To Read This Manual

    How To Read This Manual Symbols In this manual, the following symbols are used: R WARNING: This symbol indicates a potentially hazardous situation that might result in death or serious injury when you misuse the machine without following the in- structions under this symbol.

  • Page 8: Making Prints

    Making Prints Before making prints using this ma- chine, you have to make a master by pressing the {Start} key. When you press the {Start} key, the machine scans the original image and makes a master. This procedure describes how to make basic prints. Set your originals.
  • Page 9 key. See P.26 “Adjusting Print Image Density”. Speed Combine Class Slow Fast Enter the desired number of prints with the Number keys. Program Clear Modes Proof Print Enter Start Clear/Stop Press the { { { { Print} } } } key. Program Clear Modes Proof...

  • Page 10: What You Can Do With This Machine

    What You Can Do With This Machine Standard Printing P.20 “Standard Printing”. Adjusting Print Image Position P.25 “Adjusting Print Image Position”. *: Paper feed direction Adjusting Print Image Density P.26 “Adjusting Print Image Density”. Halftone Printing P.27 “Tint Mode—Halftone Printing”. Changing The Printing Speed P.28 “Changing The Printing Speed”.
  • Page 11 Stretching And Squeezing The Image In 1 % Steps P.37 “Directional Magnifica- tion—Stretching And Squeezing The Image In 1 % Steps”. Erasing Edge Margins P.40 “Edge Erase—Erasing Edge Margins”. Printing On Various Kinds Of Paper P.42 “Printing On Various Kinds Of Paper”. Selecting A Mode To Match Your Orig- inal P.45 “Selecting A Mode To...
  • Page 12 Making Variable Numbers Of Prints From Different Originals P.58 “Manual Class Mode With 2 Or More Originals—Making Variable Numbers Of Prints From Different Originals”. Making Fixed Numbers Of Prints From The Same Original P.61 “Class Mode—Making Fixed Numbers Of Prints From The same Original”.
  • Page 13 On Line Printing P.80 “On Line Printing”. Making Color Prints P.87 “Making Color Prints”. Printing In Two Colors P.88 “Printing In Two Col- ors”. Rotating The Original Images P.91 “Image Rotation—Rotat- ing Original Images”. Make-up Printing P.105 “Make-up Printing”. Merging Images P.113 “Image Overlay—...
  • Page 14 Printing Your Own Messages On Your Prints P.122 “User Stamping— Printing Your Own Messages On Your Prints”. Combining Originals Into One Print With The Memory Board P.124 “Memory Combine— Combining Originals Into One Print With The Memory Board”. GRUSTA0E GRMCOM0E GRREPE0E...

  • Page 15: Table Of Contents

    TABLE OF CONTENTS Machine Exterior... 1 Machine Interior... 2 Options ... 4 Operation Panel ... 6 Keys ... 6 Indicators... 8 Panel Display ... 9 Display Panel Layout ... 10 1. OPERATION Printing Paper ... 11 Originals ... 13 Preparation For Printing ... 15 Loading Paper...
  • Page 16 Entering The Dimensions Of The Original And Print Paper ... 38 Edge Erase—Erasing Edge Margins... 40 Printing On Various Kinds Of Paper... 42 Printing On Thick Paper ... 42 Printing On Thin Paper... 42 Printing On Envelopes ... 43 Printing On Special Kinds Of Paper ... 43 Selecting A Mode To Match Your Original ...
  • Page 17 2. OPTIONAL FUNCTIONS Printing Using The Optional Document Feeder... 81 Originals ... 81 Setting Originals In The Document Feeder... 82 Combine Originals Printing With The Document Feeder ... 83 Manual Class Mode With 2 Or More Originals Using The Document Feeder... 84 Color Printing Using The Optional Color Drum...
  • Page 18 2. Set Operation Modes ... 136 3. Initial Setting... 137 4. Mode Setting ... 139 5. Stamp... 144 6. Set User Code (s) ... 146 User Tool Menus In Detail... 148 1-8 Time Setting... 148 3-4 Reproduction Ratio ... 148 3-5 Class Enter No...
  • Page 19 Poor Printing... 185 Dirty Background... 185 Black Line/Stain ... 188 Skipped Prints ... 188 5. REMARKS Operation Notes... 189 General Cautions ... 189 Print Paper ... 191 Originals ... 191 Misfed Paper ... 191 PC Controller... 192 Where To Put Your Machine... 193 Environmental Conditions ...
  • Page 20 This page is intentionally blank. xviii...

  • Page 21: Machine Exterior

    Machine Exterior Front Door Open for access to the inside of the ma- chine. Flip-up Cover Open to access the {Image Density} key and so on. See P.6 “Operation Panel”. Operation Panel Operator controls and indicators are lo- cated here. See P.6 “Operation Panel”.

  • Page 22: Machine Interior

    Machine Interior Main Switch Use to turn the power on or off. Paper Alignment Wing Knobs Use to lift or lower the paper alignment wings. Paper Alignment Wings Lift or lower the wings depending on the paper type you use. TPEH260E Paper Delivery End Plate This plate aligns the leading edge of...
  • Page 23 Paper Delivery Side Plates These plates align the prints on the paper delivery tray. Paper Delivery Side Plate Knobs Use to move the side plates. Master Eject Unit Front Handle Use to pull out the master eject unit. Ink Holder Set the ink cartridge in this holder.

  • Page 24: Options

    Options Document Feeder Note Other options: • Color Drums: A3, 11" • Color Drums: A4, 8 • Key Counter • Cabinet • Memory Board • PC Controller TPEH163E 17" drum (red, blue, green, and brown) " 11" drum (black, red, blue, green, and brown)
  • Page 25 This page is intentionally blank.

  • Page 26: Operation Panel

    Operation Panel Keys { { { { Quality Start} } } } key P.76 “Quality Start Mode— Regain- ing The Image Density When The Ink On The Drum Dries”. { { { { Security} } } } key P.75 “Security Mode—Printing Se- cret Documents”.
  • Page 27 Program Clear Modes Color Proof Print Enter Start Fast Clear/Stop 20 21 { { { { Class} } } } key Press to select All Class, Auto Class, Manual Class, or Class mode. See “All Class Mode—Making Variable Num- bers Of Prints From The Same Original Us- ing All Stored Data”, Mode—...

  • Page 28: Indicators

    Indicators Image Density Lighter On Line Normal Darker 1 Darker 2 Tint Economy Mode Job Separator Special Feature indicator This indicator is lit when you press keys under the flip-up cover. Monitors The monitors light up when a non-stan- dard condition occurs within the ma- chine.

  • Page 29: Panel Display

    Panel Display The panel display shows operational status, error messages, and function menus. The function items for the select- ed function are displayed. These keys correspond to the item on the display. Press a relevant key to select a function. •...

  • Page 30: Display Panel Layout

    Display Panel Layout The basic elements used on the display are shown below. Understanding their meaning helps you exploit this machine's features quickly and easily. Sample Display for Selecting the [Original] key Operational status or message. Available functions. If you see a picture with a key whitened out, it means “Press this key”.

  • Page 31: Operation

    1. OPERATION Printing Paper The following types of print paper are not recommended for this machine. • Paper smaller than 70 mm 148 mm, 2.8" 5.9" • Paper larger than 297 mm 432 mm, 11.6" 17.0" • Paper heavier than 209.3 g/m , 55.6 lb •...
  • Page 32 OPERATION Important Correct curls in the paper before setting it in the machine. When you cannot correct the paper curl, stack the paper with the curl face down. If paper is curled, it might wrap around the drum or stains might appear. Do not store paper where it will be exposed to heat or direct sunlight.

  • Page 33: Originals

    Originals The following original sizes set on the exposure glass (contact glass) can be de- tected. Metric version A3L, B4L, A4KL, B5KL Inch version 11" Under the following conditions, the machine might not detect the original. In this case, select the original image area with the {Edge Erase} key. See “Edge Erase—Erasing Edge Margins”.
  • Page 34 OPERATION The first 10 mm, 0.4", of the leading edge and the last 2 mm, 0.08”, of the trailing edge cannot be printed. Make sure the leading edge margin is at least 10 mm, 0.4", and the trailing edge margin is at least 2 mm, 0.08”. Original Print a = 10 mm, 0.4"...

  • Page 35: Preparation For Printing

    Preparation For Printing Loading Paper Carefully open the paper feed tray. Lift the feed side/end plates. Grasp the side/end plate knob and adjust the side/end plates to match the paper size. Place the paper on the paper feed tray. Note Correct the paper curl before TPEY998E setting the paper.

  • Page 36: Setting Up The Paper Delivery Tray

    OPERATION Setting Up The Paper Delivery Tray Grasp the end plate knob and move the paper delivery end plate to match the print paper size. When you use A4, 8 or smaller paper A Adjust the end plate to match the paper size scale on the op- eration panel side.
  • Page 37 Lower or lift the paper alignment wings by turning the left and right knobs. Note When the guides are up, you might not be able to load the unit to full capacity (1,000 sheets) depending on the paper you are using. Lift the paper alignment wings when B5L prints are curled.
  • Page 38 OPERATION Turn on the main switch. Note You can have the machine dis- play how much ink and master are left when you switch it on. See “User Tools—Ink/Master Left” in P.139 “4. Mode Set- ting”. TPEH021E...

  • Page 39: User Codes

    User Codes Preparation You have to turn on User Code mode and register your user code with the user tools. You can regis- ter up to 20 user codes. See “Set User Code”, “Reg. User Code”, in P.146 “6. Set User Code (s)”. If the machine is set to use the User Code function, operators must input their user codes before the machine...

  • Page 40: Standard Printing

    OPERATION Standard Printing Lift the platen cover. Note Be sure to lift the platen cover more than 30 cm, 12". Set the original face down on the exposure glass (contact glass). The original should be aligned to the rear left corner. Lower the platen cover.
  • Page 41 Press the { { { { Proof} } } } key and check the image density and the image position of the proof print. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Note If the image position is not cor- rect, adjust it using the [Image =] key.

  • Page 42: Loading Paper On The Paper Feed Tray

    OPERATION Loading Paper On The Paper Feed Tray The Load Paper indicator (B) lights when the paper feed tray runs out of paper. Replenishing Paper Press the { { { { Clear/Stop} } } } key. Program Enter Clear/Stop Note This step is necessary only if you want to pause a print run to replenish paper.

  • Page 43: Changing The Paper Size

    Changing The Paper Size Remove the paper from the paper feed tray. The paper feed tray will lower. Grasp the side/end plate knob and adjust the paper feed side/ end plates to match the paper size. Place the paper on the paper feed tray.

  • Page 44: Closing The Paper Feed And Paper Delivery Trays

    OPERATION Closing The Paper Feed And Paper Delivery Trays Remove the paper from the paper feed tray. The paper feed tray will lower. Turn off the main switch. Adjust the side/end plates to L paper and lower match A4L them. Close the paper feed tray.

  • Page 45: Adjusting Print Image Position

    Adjusting Print Image Position You can adjust the print image posi- tion to suit your needs. *…Paper feed direction Press the [Image = = ] key. Note You can skip step A and adjust the image position directly by pressing the {~}, {}}, {|}, and {{} keys.

  • Page 46: Adjusting Print Image Density

    OPERATION Adjusting Print Image Density You can adjust the print image densi- ty to suit your needs. There are two ways to do this: Before Making A Master Use the {Image Density} key. After Making A Master Use the {Speed} keys. Before Making A Master Press the { { { { Image Density} } } } key to ad- just the image density.

  • Page 47: Tint Mode-Halftone Printing

    Tint Mode—Halftone Printing Use this function to print tinted imag- Press the { { { { Tint} } } } key. Image Density Stamp Lighter Normal Darker 1 Make-Up Darker 2 Overlay Tint Skip Feed Edge Erase Economy Mode Press the { { { { Start} } } } key. Program Clear Modes Auto Cycle...

  • Page 48: Changing The Printing Speed

    OPERATION Changing The Printing Speed Use the {Speed} keys to adjust the printing speed. The relationship be- tween printing speed and print quali- ty depends on the type of paper you use. Press the { { { { V V V V } } } } key to increase the speed and press the { { { { W W W W } } } } key to re- duce the speed.

  • Page 49: Stopping The Machine During A Multi-Print Run

    Stopping The Machine During A Multi-print When You Want To Stop The Machine During A Multi-print Run And Print A Different Original Press the { { { { Clear/Stop} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop...

  • Page 50: Preset Reduce/Enlarge-Reducing And Enlarging Using Preset Ratios

    OPERATION Preset Reduce/Enlarge—Reducing And Enlarging Using Preset Ratios You can select a preset ratio for print- ing. Note The leading edge of the print im- age does not shift when a print im- age is made with this function. *…Paper feed direction a=10 mm, 0.4"...
  • Page 51 Press the [Ratio] key. Select the desired ratio with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key.

  • Page 52: Auto Magnification Selection-Having The Machine Choose The Reproduction Ratios

    OPERATION Auto Magnification Selection—Having The Machine Choose The Reproduction Ratios The machine can choose an appropriate reproduction ratio based on the paper and original sizes you use. Note You can change the reproduction ratio from 50 % to 200 % when you set an original on the exposure glass (contact glass).
  • Page 53 Auto Magnification Selection—Having The Machine Choose The Reproduction Ratios Set these originals in the optional document feeder. Inch version Original 11" 17"L " Paper 100 % 121 % 11" 17"L 77 % 100 % " 14"L 65 % 77 % "...
  • Page 54 OPERATION Press the { { { { Start} } } } key. Program Enter Clear/Stop Check the image position of the trial or proof print. Note If the image position is not correct, adjust it using the [Image =] keys (See P.25 “Adjusting Print Image Position”).

  • Page 55: Zoom-Reducing And Enlarging In 1 % Steps

    Zoom—Reducing And Enlarging In 1 % Steps You can change the reproduction ra- tio in 1 % steps. Note You can change the reproduction ratio from 50 % to 200 % when you set an original on the exposure glass (contact glass). You can change the reproduction ratio from 50 % to 155 % when you set originals in the optional docu-...
  • Page 56 OPERATION Using the number keys A Enter the ratio with the Num- ber keys. Program Enter Clear/Stop B Press the { { { { Enter} } } } key. Program Enter Clear/Stop Press the [OK] key. Make sure that the original and the print paper are the correct size.

  • Page 57: Directional Magnification-Stretching And Squeezing The Image In 1 % Steps

    Directional Magnification—Stretching And Squeezing The Image In 1 % Steps Directional Magnification—Stretching And Squeezing The Image In 1 % Steps Prints can be reduced or enlarged at different reproduction ratios horizon- tally and vertically. There are two ways to use this feature: Enter The Reproduction Ratios Adjust the reproduction ratio man- ually.

  • Page 58: Entering The Dimensions Of The Original And Print Paper

    OPERATION Enter the vertical and horizontal ratio. Note To change the value entered, press the {Clear/Stop} key and enter the new value. Adjusting ratios with the [ ], [ ], {~}, or {}} key A Adjust the vertical ratio with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key.
  • Page 59 Directional Magnification—Stretching And Squeezing The Image In 1 % Steps Press the [OK] key. Select [Direct. Mag. (size)] with the [ ] or { { { { } } } } } } } } key. Press the [OK] key. Enter the vertical original size with the Number keys and press the { { { { Enter} } } } key.

  • Page 60: Edge Erase-Erasing Edge Margins

    OPERATION Edge Erase—Erasing Edge Margins This function erases all four sides of the original image. Using Edge Erase mode When not using Edge Erase mode When printing from thick books, or similar originals, the binding margin at the center and the edges might appear on prints.
  • Page 61 Press the { { { { Start} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Check the image position of the trial or proof print. Note If the image position is not cor- rect, adjust it using the [Image =] key (see P.25 “Adjusting Print Image Position”).

  • Page 62: Printing On Various Kinds Of Paper

    OPERATION Printing On Various Kinds Of Paper Printing On Thick Paper When you make prints on thick (157 to 209.3 g/m , 42 to 55.6 lb) paper, perform the following steps. Press the [Ppr. Type] key. Select [Thick] with the [ ] or { { { { } } } } } } } } key.

  • Page 63: Printing On Envelopes

    Note If necessary, lower or lift the pa- per alignment wings. See P.15 “Preparation For Printing”. Set the side pads (move the side pad levers to as shown). Printing On Envelopes Press the [Ppr. Type] key. Select [Special] with the [ ], [ ], {~}, or { { { { } } } } } } } } key.
  • Page 64 OPERATION Press the [Ppr. Type] key. Select [User 1] or [User 2] with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key.

  • Page 65: Selecting A Mode To Match Your Original

    Selecting A Mode To Match Your Original Select one of the following four modes to match your originals: Photo mode Delicate tones of photographs and pictures can be reproduced with this mode. Letter mode Select this mode when your origi- nals contain only letters (no pic- tures).

  • Page 66: Letter/Photo Mode Printing

    OPERATION Adjust the lightness with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key. Set your original on the exposure glass (contact glass) or in the op- tional document feeder.

  • Page 67: Pencil Mode Printing

    Press the { { { { Start} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Check the image position of the trial or proof print. Note If the image position is not cor- rect, adjust it using the [Image =] key (see P.25 “Adjusting Print Image Position”).

  • Page 68: Economy Mode-Saving Ink

    OPERATION Economy Mode—Saving Ink When you want to save ink, select Economy mode. Note Prints will be lighter in this mode. Press the { { { { Economy Mode} } } } key. Stamp Make-Up Overlay Skip Feed Edge Erase Set your original on the exposure glass (contact glass) or in the op- tional document feeder.

  • Page 69: Auto Cycle-Making Master And Prints At One Stroke

    Auto Cycle—Making Master And Prints At One Stroke Use the {Auto Cycle} key to process masters and make prints at one stroke. Note When you use the optional docu- ment feeder, it is not necessary to place originals one by one. All originals are fed and prints are completed after you press the {Start} key.
  • Page 70 OPERATION If you set original in the option- al document feeder, originals are fed and prints are complet- ed automatically.

  • Page 71: All Class Mode-Making Variable Numbers Of Prints From The Same Original Using All Stored Data

    All Class Mode—Making Variable Numbers Of Prints From The Same Original Using All Stored Data All Class Mode—Making Variable Numbers Of Prints From The Same Original Using All Stored Data Preparation You have to store the number of students in each class with the user tools.
  • Page 72 OPERATION Press the { { { { Start} } } } key. Program Enter Clear/Stop Check the image position of the trial or proof print. Note If the image position is not cor- rect, adjust it using the [Image =] key (see Print Image Position”).

  • Page 73: Auto Class Mode- Making Variable Numbers Of Prints From The Same Original Using Stored Data

    Auto Class Mode— Making Variable Numbers Of Prints From The Same Original Using Stored Data Auto Class Mode— Making Variable Numbers Of Prints From The Same Original Using Stored Data Preparation You have to store the number of students in each class with the user tools.
  • Page 74 OPERATION Press the [OK] key. Select the desired classes for each grade. Selecting classes with the {~}, {}}, {|}, or {{} key A Select the desired class for the grade with the { { { { } } } } } } } } key. You will find the number of stu- dents is displayed on the counter.
  • Page 75 Auto Class Mode— Making Variable Numbers Of Prints From The Same Original Using Stored Data key and press the [Cancel] key. Repeat steps A and B until you have finished selecting all the desired classes. Press the [OK] key. Set one original on the exposure glass (contact glass) or in the op- tional document feeder.

  • Page 76: Manual Class Mode With One Original-Making Variable Numbers Of Prints From The Same Original

    OPERATION Manual Class Mode With One Original— Making Variable Numbers Of Prints From The Same Original Use the {Class} key to make sets of prints from the same original. Vari- ous numbers of prints are made for each set. Note When you set Manual Class mode, Job Separation mode is automati- cally turned on.
  • Page 77 Manual Class Mode With One Original—Making Variable Numbers Of Prints From The Same Original Press the { { { { Enter} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Enter the desired number of prints for the second set with the Number keys.

  • Page 78: Manual Class Mode With 2 Or More Originals-Making Variable Numbers Of Prints From Different Originals

    OPERATION Manual Class Mode With 2 Or More Originals—Making Variable Numbers Of Prints From Different Originals Preparation To use this function, you have to select “by each original” with the “Class Manual Set” user tool. See “Class Manual Set” in Mode Setting”.
  • Page 79 Manual Class Mode With 2 Or More Originals—Making Variable Numbers Of Prints From Different Originals Press the { { { { Enter} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Enter the desired number of prints for the second original with the Number keys.
  • Page 80 OPERATION Press the { { { { Print} } } } key. Program Enter Clear/Stop After the first set is completed, set the second original on the expo- sure glass (contact glass) and press the { { { { Start} } } } key. Program Enter Clear/Stop...

  • Page 81: Class Mode-Making Fixed Numbers Of Prints From The Same Original

    Class Mode—Making Fixed Numbers Of Prints From The same Original Use the {Class} key to make sets of prints from the same original. The same numbers of prints are made for each set. Note When you set Class mode, Job Sep- aration mode is automatically turned on.
  • Page 82 OPERATION With the Number keys, enter the number of sets you wish to make. Program Enter Clear/Stop Note Up to 99 sets can be selected for an original. Press the [OK] key. Set one original on the exposure glass (contact glass) or in the op- tional document feeder.

  • Page 83: Combine Originals-Combining Originals Into One Print

    Combine Originals—Combining Originals Into One Print You can combine originals in two ways: 2 One-sided Originals 1 One-sided Print Of 2 Images Combine two single-sided originals onto one single-sided print with the two images placed side-by-side. 2 One-sided Originals 1 One-sided Print Of 4 Images Combine two single-sided originals onto one single-sided print with each im- age duplicated (total of four images).
  • Page 84 OPERATION Metric version Paper Size A3L Inch version Paper Size The following tables list the combinations that can be used in 2 one-sided originals 1 one-sided print of 4 images mode: Metric version Original Size Paper 50 % Size Original Size 100 % 115 % 141 %...
  • Page 85 Inch version Paper Size 11" 17"L " 14"L " 11"L " "L If the proper reproduction ratio is not selected, images might not completely appear on prints. Reference When you use the optional document feeder with this function, see “Combine Originals Printing With The Document Feeder”. Set the first original face down.
  • Page 86 OPERATION Note To have the machine choose a suitable ratio automatically, use Auto Mag- nification Selection mode. See ing The Machine Choose The Reproduction Ratios”. Press the { { { { Combine} } } } key. Speed Combine Class Slow Select [combine 2] or [Quadruple] with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key.
  • Page 87 The beeper sounds after the first original has been stored. Set the second original face down. Press the { { { { Start} } } } key. Check the image position of the trial or proof print. Note If the image position is not correct, adjust it using the [Image =] key (see P.25 “Adjusting Print Image Position”).

  • Page 88: Auto Combine Mode-Having Images Repeated On One Print

    OPERATION Auto Combine Mode—Having Images Repeated On One Print Preparation To use this function, you have to select Auto Combine mode with the user tools. See “Combine” in P.139 “4. Mode Setting”. You can have images repeated in two ways: 1 One-sided Originals Print Of 2 Images The original image is duplicated...
  • Page 89 Select [Repeat 2] or [Repeat 4] with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key. Press the { { { { Start} } } } key.

  • Page 90: Skip Feed Printing

    OPERATION Skip Feed Printing If the backs of prints are dirty, you can increase the time between two prints using the {Skip Feed} key. By default, when one sheet of paper is fed the drum rotates once. However, you can select the number of rotations of the drum.
  • Page 91 Press the { { { { Start} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Check the image position of the trial or proof print. Note If the image position is not cor- rect, adjust it using the [Image =] key (see P.25 “Adjusting Print Image Position”).

  • Page 92: Program-Storing Your Print Settings In Memory

    OPERATION Program—Storing Your Print Settings In Memory You can store up to 9 frequently used print job settings in machine memory and recall them for future use. Note The stored programs are not cleared when you turn off the main switch.

  • Page 93: Recalling A Program

    Recalling A Program Press the { { { { Program} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Make sure that [Recall] is selected. Press the [OK] key. Note Programs that have been stored beforehand are represented by a number.

  • Page 94: Removing Program Protection

    OPERATION Select the program number you want to protect with the [ ], [ ], {~}, or { { { { } } } } } } } } key. Note You can also select the program number with the Number keys. Press the [Select] key.

  • Page 95: Security Mode-Printing Secret Documents

    Security Mode—Printing Secret Documents This function prevents others from making prints of secret documents from the master. For example, if you want to print some documents with sensitive information, use this func- tion after making your prints so that nobody can access that master again. Make your prints.

  • Page 96: Quality Start Mode- Regaining The Image Density When The Ink On The Drum Dries

    OPERATION Quality Start Mode— Regaining The Image Density When The Ink On The Drum Dries If the machine is not used for a long period of time or you change the color drum unit, the ink on the drum might dry causing print quality to deterio- rate.

  • Page 97: Job Separation-Separating Printing Sets On The Paper Delivery Tray

    Job Separation—Separating Printing Sets On The Paper Delivery Tray The print on the top of each print set on the paper delivery tray is pulled by the job separator. This function is useful when you make 2 or more print sets. R CAUTION: •...
  • Page 98 OPERATION Press the { { { { Job Separator} } } } key. Stamp Make-Up Overlay Skip Feed Edge Erase Make your prints. Note After the last page of each printing set is fed out to the paper delivery tray, the job separator pulls the last sheet of each group in Job Separation mode.

  • Page 99: Saving Master

    Saving Master The machine automatically changes the master length depending on the paper size you use. This saves both master and ink. a = Images on the master b = Masters c = Area that you can save master and Limitation The optional document feeder is required.

  • Page 100: On Line Printing

    OPERATION On Line Printing The images on a personal computer can be printed using this machine. Limitation The PC controller is required. For details, refer to the PC controller manual. Note When you use A5, 5 or paper of non-standard size, you need to select the paper size with the [Ppr.

  • Page 101: Optional Functions

    2. OPTIONAL FUNCTIONS Printing Using The Optional Document Feeder Insert a stack of originals in the docu- ment feeder. It will be fed automati- cally. Originals Setting the following originals in the document feeder might cause origi- nal misfeeds or damage to the origi- nals.

  • Page 102: Setting Originals In The Document Feeder

    OPTIONAL FUNCTIONS Basically, set originals as shown be- low. When you have an optional memory board and the original is set in a dif- ferent direction from the print paper, the machine automatically rotates the original image by 90 to match the print paper direction.

  • Page 103: Combine Originals Printing With The Document Feeder

    Make your prints. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Note If the next original has been set in the document feeder before the machine stops, that original is fed automatically and a trial print is delivered to the paper delivery tray after the print of the first original is completed.

  • Page 104: Manual Class Mode With 2 Or More Originals Using The Document Feeder

    OPTIONAL FUNCTIONS Select [Combine 2] or [Quadruple] with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key.
  • Page 105 Press the { { { { Enter} } } } key. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Enter the desired number of prints for the second original with the Number keys. Program Clear Modes Auto Cycle Proof Print Enter...
  • Page 106 OPTIONAL FUNCTIONS Press the { { { { Print} } } } key. Program Enter Clear/Stop Clear Modes Auto Cycle Proof Print Start TPES070N...

  • Page 107: Color Printing Using The Optional Color Drum

    Color Printing Using The Optional Color Drum Color drum units (red, blue, green, and brown) are available as options in addition to the standard black unit. For making color prints, a separate drum unit is necessary for each color. Note If the ink on the color drum dries, use the Quality Start function.

  • Page 108: Printing In Two Colors

    OPTIONAL FUNCTIONS out the drum unit while holding handle B2 and drum stay B3. Important Be careful not to let the drum unit fall. Lower lock lever B1 of the option- al color drum. Insert the color drum unit along the guide rail.
  • Page 109 Prepare the two originals. Set the first original on the exposure glass (contact glass). Enter the number of prints with the Number keys. Program Clear Modes Auto Cycle Proof Print Enter Start Clear/Stop Press the { { { { Start} } } } key. Program Clear Modes Auto Cycle...

  • Page 110: Changing The Drum Size

    OPTIONAL FUNCTIONS Changing The Drum Size To save costs on master rolls and ink, you can shorten the length of each master by changing to an optional smaller drum. Printing Area (at 23 C/73 F, 65 % RH) Metric version A3 drum More then 290 11.4"...

  • Page 111: Image Rotation-Rotating Original Images

    Image Rotation—Rotating Original Images When the direction in which your original is set is different from that of the pa- per, and your machine is equipped with the optional memory board, the ma- chine automatically rotates the original image by 90 to match the paper direction.
  • Page 112 OPTIONAL FUNCTIONS It takes longer than usual to make masters in Image Rotation mode. You can cancel Image Rotation mode with the user tools. See “Auto Rotation” P.139 “4. Mode Setting”.

  • Page 113: Make-Up Printing Features

    Make-up Printing Features Make-up mode enables you to do more than just make an exact copy of the orig- inal. A variety of editing and image processing functions allow you to quickly and easily customize your prints. Limitation The memory board option is required for this feature. Main Features The use of command sheets allows you to create special effects without cutting and pasting - up to 4 commands can be given for an original.

  • Page 114: Make-Up Modes For Outside Designated Areas

    OPTIONAL FUNCTIONS Mode Designated Area P./N. mode (Positive Negative mode) Solid mode (Image Pat- tern mode) All Page Pattern mode (Area Pattern mode) All + Outline (Image Outline and Area Pat- tern mode) Make-up Modes For Outside Designated Areas Mode Undesignated Area Letter mode: The area outside designated ar-...
  • Page 115 Mode Undesignated Area Save Area mode: The area outside the desig- nated areas is deleted. Outline mode: The area outside the designated area is printed in Out- line mode. Note In Make-up mode, commands must be given for both designated areas and outside the designated area.

  • Page 116: Background Patterns

    OPTIONAL FUNCTIONS Background Patterns There is a total of 164 background patterns for Make-up mode: • 40 basic patterns • 40 patterns similar to the basic patterns but with patterns elements at 4 times the size. • 90 rotations of all the basic and enlarged patterns. •...
  • Page 117 Make-up Printing Features Note The basic patterns are numbered 1 to 40. You can make your own make-up background patterns with the user tools. P.161 “5-15 Make/Chg. Pattern”.

  • Page 118: Making A Command Sheet For Make-Up Printing

    OPTIONAL FUNCTIONS Making A Command Sheet For Make-Up Printing Command sheets are fed first so that the machine can recognize the areas of the original which are to be edited as designated areas. Command sheet The command sheet is a sheet of pa- per for designating areas to be edited.

  • Page 119: How To Make A Command Sheet

    How To Make A Command Sheet There are two ways of designating areas: the diagonal line method and the closed area method. - Features • You can combine up to 4 command sheets when making a master. • You cannot use both the closed and diagonal line method on the same com- mand sheet.
  • Page 120 OPTIONAL FUNCTIONS - Notes about drawing a command sheet The image might differ depending on how the designated area is drawn, so re- member the following when making the command sheet: Designated area Part of the designated area is surrounded by 3 sides of the entire area.
  • Page 121 When using the diagonal line method Note A diagonal line must be drawn through the area that you wish to edit. Put the command sheet on top of the original. Draw a line using a felt tip pen (black, red or blue) with a thickness of at least 1 mm.
  • Page 122 OPTIONAL FUNCTIONS a, b, c = 2 mm, 0.08" When using the closed area method Note The line designating the area must be a closed loop. Put the command sheet on top of the original. Using a black, red, or blue felt tip pen, draw a line around the area to des- ignate.
  • Page 123 a = Line marking the designated area b = 2 mm, 0.08" c = Image within the designated area The line marking the designated area should be more than 2 mm, 0.08", from any neighboring image. a = 2 mm, 0.08" b = Neighboring image c = Line marking the designated area d = image within the designated area...

  • Page 124: Command Sheets And Finished Prints

    OPTIONAL FUNCTIONS Command Sheets And Finished Prints The following illustrations will help you understand how to draw a command sheet. When drawing a command sheet using a diagonal line The diagonal line method is easy to use for designating rectangular areas. It is also more precise, but it is difficult to use for designating complex areas.

  • Page 125: Make-Up Printing

    Make-up Printing Press the { { { { Make-Up} } } } key. Image Density Stamp Lighter Normal Darker 1 Make-Up Darker 2 Overlay Tint Skip Feed Edge Erase Economy Mode Make sure that [1] is selected. Then press the [OK] key. Select the frame shape with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key.
  • Page 126 OPTIONAL FUNCTIONS To change the value entered, press the {Clear/Stop} key and enter the new value. After you have finished designat- ing modes for all the command sheets, select [Outside Area] with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Then press the [OK] key.

  • Page 127: Make-Up Printing With The Optional Document Feeder

    Make-up Printing With The Optional Document Feeder Under the following conditions, you should set command sheets and the original on the exposure glass (con- tact glass). • When using paste-up originals. • When the command sheets and original are of different size. With the optional document feeder, you can designate areas to be edited in Make-up mode within the follow-...
  • Page 128 OPTIONAL FUNCTIONS Select the mode for the first com- mand sheet with the [ ], [ ], {~}, { { { { } } } } } } } } , { { { { | | | | } } } } , or { { { { { { { { } } } } key. Press the [OK] key.
  • Page 129 density with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Note Four coarseness settings are available: •...

  • Page 130: Make-Up Samples

    OPTIONAL FUNCTIONS Make-up Samples - Sample 1 Command Sheet No. 1, Frame shape Outside area: Letter mode Print Original Command sheet No.1 Print , Designated area: Delete Area mode ZM-50...
  • Page 131 - Sample 2 Command Sheet No. 1, Frame shape/, Designated area: All + Outline No. 30 Command Sheet No. 2 Frame shape Outside area: Fn1 Print Original Command sheet No.1 Command sheet No.2 Print , Designated area: All page pattern No.   BB C P P RR S...
  • Page 132 OPTIONAL FUNCTIONS - Sample 3 Print the original as it is Change the drum unit for color printing Command Sheet No. 1, Frame shape No. 39 Outside area: Letter mode Print BIRTHDAY PARTY Original Command sheet No.1 Print , Designated area: All page pattern BIRTHDAY PARTY ZM-52...

  • Page 133: Image Overlay-Merging Images

    Image Overlay—Merging Images The machine can merge two different originals onto the same print paper. Two types of merging are available: Overlay ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE...
  • Page 134 OPTIONAL FUNCTIONS Setting originals on the exposure glass (contact glass) A Set the first original on the ex- posure glass (contact glass). B Press the { { { { Start} } } } key. Note When you select [Form] in step B, the original for the template should be set first.

  • Page 135: Stamping Date-Having The Date Stamped On Your Prints

    Stamping Date—Having The Date Stamped On Your Prints You can print the date on your prints. '98.7.25 Preparation Before you use this function, you have to set the machine's internal clock with the user tools. See P.148 “1-8 Time Setting”. Limitation The optional memory board is re- quired.
  • Page 136 OPTIONAL FUNCTIONS Make sure that [Date] is selected. Press the [OK] key. Select the desired Stamping Date position and direction with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key.

  • Page 137: Page Stamping-Having Page Numbers Stamped On Your Prints

    Page Stamping—Having Page Numbers Stamped On Your Prints You can print page numbers on your prints. Three numbering formats are avail- able: • P1, P2,..., P5 • 1/5, 2/5,..., 5/5 • -1-, -2-,..., -3- Limitation The optional memory board is re- quired.
  • Page 138 OPTIONAL FUNCTIONS Select the [Page] with the [ ] or { { { { } } } } } } } } key. Press the [OK] key. Select the desired format with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key.
  • Page 139 Select the desired orientation with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key. Select the [Yes] or [No] key.

  • Page 140: Stamping Function-Printing Preset Messages On Your Prints

    OPTIONAL FUNCTIONS Stamping Function—Printing Preset Messages On Your Prints One of the following 3 messages can be stamped on prints. Confidential Priority Preliminary Limitation The optional memory board is re- quired. This function cannot be used with User Stamping. Only one message can be stamped at a time.
  • Page 141 Select the page to be stamped with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key. Select the stamping position with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key.

  • Page 142: User Stamping-Printing Your Own Messages On Your Prints

    OPTIONAL FUNCTIONS User Stamping—Printing Your Own Messages On Your Prints Up to 4 messages which you use fre- quently can be stored in the machine memory. You can have these messag- es stamped on your prints. Preparation You have to store your message with the user tools.
  • Page 143 Select the page to be stamped with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [OK] key. Select the stamping position with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key.

  • Page 144: Memory Combine-Combining Originals Into One Print With The Memory Board

    OPTIONAL FUNCTIONS Memory Combine—Combining Originals Into One Print With The Memory Board You can combine originals in four ways: 4 One-sided Originals 4 one-sided pages are printed onto 1 one-sided sheet, 4 original images on one side. 8 One-sided Originals 8 one-sided pages are printed onto 1 one-sided sheet, 8 original images on one side.

  • Page 145: Combine 4, 8, Or 16 Originals - 4, 8, Or 16 One-Sided Originals

    Memory Combine—Combining Originals Into One Print With The Memory Board Combine 4, 8, or 16 Originals – 4, 8, or 16 One-sided Originals 1 One-sided Print Of 4, 8, or 16 Images 4 One-sided Originals 1 One-sided Print Of 4 Images 8 One-sided Originals 1 One-sided Print Of 8 Images 16 One-sided Originals...
  • Page 146 OPTIONAL FUNCTIONS If the calculated ratio is under the minimum ratio, it is corrected within the range of the ratio automatically. However, with some ratios, parts of the im- age might not be copied. The machine cannot copy originals different in size and direction. Note The number of originals printed (combined) can be 4, 8, or 16.
  • Page 147 Memory Combine—Combining Originals Into One Print With The Memory Board When you set originals on the exposure glass (contact glass) (Metric version) Original A3L Paper A4KL B5KL You can use these original and paper sizes in Combine 4, 8 Originals mode. You can use these original and paper sizes in Combine 4 Originals mode.
  • Page 148 OPTIONAL FUNCTIONS Press the [OK] key. Select one of the desired combine modes. Press the [OK] key. Set your originals. Setting your original (K) on the exposure glass (contact glass) A Set your original as shown in the illustration. Setting your originals (K) in the optional document feeder A Set your originals as shown in the illustration.

  • Page 149: Repeat-Repeating An Image Over The Entire Print

    Memory Combine—Combining Originals Into One Print With The Memory Board Note Even if the number of originals is less than the number required in the se- lected mode, prints can be made, as shown in the illustration. In this case, press the {Enter} key after all the originals have been scanned.
  • Page 150 OPTIONAL FUNCTIONS The original and paper setting direction and the number of repeated images are as follows: For example, when you use A4 L The number of repeated images For example, when you set A5L L paper. you use A3L The number of repeated images For example, when you use 8...
  • Page 151 Memory Combine—Combining Originals Into One Print With The Memory Board Press the { { { { Combine} } } } key. Speed Combine Class Slow Fast Select [Memory Combine] with the [ ] or { { { { ~ ~ ~ ~ } } } } key. Press the [OK] key.
  • Page 152 OPTIONAL FUNCTIONS Setting your original (K) on the exposure glass (contact glass) A Set your original as shown in the illustration. Setting your originals (K) in the optional document feeder A Set your originals as shown in the illustration. Press the { { { { Start} } } } key. TPEH270E TPEH281E...

  • Page 153: User Tools

    Accessing The User Tools This section is for the key operators in charge of this machine. You can change or set the machine's default settings. Press the { { { { User Tools} } } } key. User Tools Image Density Stamp Lighter Normal...
  • Page 154 USER TOOLS pressing the [OK] key. Then en- ter the new value. [Cancel]: Press to return to the previous menu without chang- ing any data. Press the { { { { User Tools} } } } key to re- turn to the Ready condition. User Tools Stamp Make-Up...

  • Page 155: User Tools Menu

    User Tools Menu Reference For how to access the user tools, see 1. System Mode Description Auto Reset The machine returns to its initial condition automatically after your job is finished. The automatic reset time can be set from 1 to 5 minutes or off (0 minute). R.

  • Page 156: Set Operation Modes

    USER TOOLS Mode Time Setting Auto Online Data Print 2. Set Operation Modes Mode Min. Quantity Max. Quantity Description Use to set the machine's internal clock. Note The clock must be adjusted if you change the clock to daylight saving time/summer time, or return to stan- dard time.

  • Page 157: Initial Setting

    Mode Description Copy Count The counter can be set to show the number of prints made Display (Up), or the number of prints remaining to be made (Down). Panel Beeper Turns the beeper on or off. LCD Contrast You can adjust the brightness of the panel display. 3.
  • Page 158 USER TOOLS Mode Reproduction Ratio Class Enter No. Before using All Class or Auto Class mode, register the Photo (Light- ness) Photo (Screen) Tint Mode ON/OFF Description Adjust a fixed reproduction ratio between 50 and 200 %. Note Default: • Metric version: 71 %, 82 %, 87 %, 93 %, 100 %, 115 %, 122 %, 141 % •...

  • Page 159: Mode Setting

    Mode Description Margin Erase Adjust the erase edges margin. Area Specifies the paper size when you press the {On Line} key. Ppr. Size [On- line] 4. Mode Setting Mode Description Auto Cycle Specifies whether Auto Cycle mode is selected at power on. ON/OFF Class Manual You can use one original or multiple originals in Manual...
  • Page 160 USER TOOLS Mode Background ON/OFF Longer Paper Combine Comb. Sep. Line Description When you make prints in Photo, Letter/Photo, or Tint mode, the background of the prints might become dirty. Turn Background On to improve the clarity of your prints. Note Default: w/o back.
  • Page 161 Mode Description Cancel Comb. Specifies whether Combine Originals or Memory Combine mode is cleared after finishing your print job. No. of Skip Specifies the number of drum rotations in Skip Feed mode Feed at power on. You can also select whether you can change the number of drum rotations temporarily when you press the {Skip Feed} key.
  • Page 162 USER TOOLS Mode Deflector Angle You can change the angle of the wing guide depending on Manual Class Auto Separate Description the paper type you use. Note Default: Auto Available settings: • Up (Select this setting when standard thickness or thin paper misfeeds at the paper exit section occur frequently.) •...
  • Page 163 Mode Description Ink/Master Specifies whether you can check the amount of ink and Left master. Type of Paper When one kind of paper misfeeds occur frequently, you can register its paper type in [User 1] or [User 2]. Auto Rotation When the direction in which your original is set is different from that of the paper, and your machine is equipped with the optional memory board, the machine automatically ro-...

  • Page 164: Stamp

    USER TOOLS 5. Stamp Note You can use these functions only when you have an optional memory board. Mode Type Size Stamp Density Stamp Position Size (User Stamp) Description You can change the message selected at power on in the Stamping function.
  • Page 165 Mode Description Density (User) You can select the style of the user stamps. Position (User) You can edit the preset user stamp position co-ordinates. Regist. (User) You can register user stamps. Date Style Set You can select the style of the date stamp. Date Position You can select the date stamp direction at power on in Stamping Date mode.

  • Page 166: Set User Code (S)

    USER TOOLS Mode Direction (Page) Position (Page) Make/Chg. Pattern 6. Set User Code (s) User Code If the machine is set to use the User Code function, operators must input their user codes before the machine can operate. The machine keeps count of the number of copies made under each user code.
  • Page 167 Reset Counters You can clear each or all user codes' counters. Reg. User Code You can register user codes. Chg. User Code You can change user codes. Del. User Code You can delete user codes. Key Operator Sets Key Operator Code mode. Code Reg/Chg Key- You can register or change key operator codes.

  • Page 168: User Tool Menus In Detail

    USER TOOLS User Tool Menus In Detail 1-8 Time Setting Press the { { { { User Tools} } } } key. User Tools Stamp Make-Up Overlay Make sure that 1 is selected. Then press the [OK] key. Enter 8 with the Number keys. Then press the [OK] or { { { { Enter} } } } key.

  • Page 169: Class Enter No

    Enter 4 with the Number keys. Then press the [OK] or { { { { Enter} } } } key. Select the ratio you want to adjust with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key.

  • Page 170: Margin Erase Area

    USER TOOLS Enter the number of students with the Number keys. Then press the { { { { Enter} } } } key. Program Enter Clear/Stop Note Repeat steps F and G until you have finished registering num- ber of students in each class. Press the [OK] key.

  • Page 171: No. Of Skip Feed

    Note You can also enter the ratio with the Number keys and the {Enter} key. If you selected * A Enter the erase edge margin with the Number keys. B Press the { { { { Enter} } } } key. C Enter the vertical length of pa- per you use with the Number keys.

  • Page 172: No. Of Q.start

    USER TOOLS 4-14 No. of Q.start Note The default settings are as follows: Temperature Low Tmp. (10 – 15 C, 50 – 59 F) Normal Tmp. (15 – 28 C, 59 – 82.4 F) High Tmp. (28 – 30 C, 82.4 – 86 F) Press the { { { { User Tools} } } } key.
  • Page 173 Select the temperature at which you use this machine with the [ ], [ ], {~}, or { { { { } } } } } } } } key. Press the [OK] key. Select the time period you want to change how many times the drum unit idles with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key.

  • Page 174: Type Of Paper

    USER TOOLS 4-19 Type of Paper Press the { { { { User Tools} } } } key. User Tools Stamp Make-Up Overlay Enter 4 with the Number keys. Then press the [OK] or { { { { Enter} } } } key. Enter 19 with the Number keys.
  • Page 175 Stamp po- Default Available sitions settings a = 24 mm, a = 8 – 104 0.96" mm, 0.32" – 4.16" b = 24 mm, 0.96" b = 8 – 144 mm, 0.32" – GRSPOS3E 5.76" a = 24 mm, a = 8 – 104 0.96"...

  • Page 176: Position (User)

    USER TOOLS Adjust the horizontal stamp posi- tion with the Number keys. Program Enter Clear/Stop Press the { { { { Enter} } } } key. Program Enter Clear/Stop Adjust the vertical stamp position with the Number keys. Press the { { { { Enter} } } } key. Press the [OK] key twice.
  • Page 177 Stamp po- Default Available sitions settings a = 0 mm, 0" a = – 52 – 52 mm, – 2.08" b = 0 mm, – 2.08" 0" b = – 72 – 72 c = center mm, – 2.88" line GRSPOS7E –...

  • Page 178: Regist. (User)

    USER TOOLS 5-8 Regist. (User) Press the { { { { User Tools} } } } key. User Tools Stamp Make-Up Overlay Enter 5 with the Number keys. Then press the [OK] or { { { { Enter} } } } key. Enter 8 with the Number keys.
  • Page 179 Stamp po- Default Available sitions settings a = 8 mm, a = 8 – 40 0.32" mm, 0.32" – 1.60" b = 20 mm, dd.mm.yy 0.80" b = 8 – 40 mm, 0.32" – 1.60" GRDPOS0E dd.mm.yy GRDPOS1E a = 20 mm, 0.80"...

  • Page 180: Position (Page)

    USER TOOLS Press the { { { { Enter} } } } key. Program Enter Clear/Stop Adjust the vertical date stamping position with the Number keys. Press the { { { { Enter} } } } key. Press the [OK] key twice. 5-14 Position (Page) Note The default position and available...

  • Page 181: Make/Chg. Pattern

    Select the page numbering direc- tion you want to adjust with the [ ], [ ], { { { { ~ ~ ~ ~ } } } } , or { { { { } } } } } } } } key. Press the [Change] key.

  • Page 182: Check Counter

    USER TOOLS Move the cursor to the position you wish to edit with the { { { { ~ ~ ~ ~ } } } } , {}}, { { { { | | | | } } } } , or { { { { { { { { } } } } key. Press the { { { { Enter} } } } or { { { { Clear/Stop} } } } key to edit the pattern.

  • Page 183: Reset Counters

    6-2 Reset Counters Press the { { { { User Tools} } } } key. User Tools Image Density Stamp Lighter Normal Darker 1 Make-Up Darker 2 Overlay Tint Enter 6 with the Number keys. Then press the [OK] or { { { { Enter} } } } key. Enter 2 with the Number keys.

  • Page 184: Del. User Code

    USER TOOLS Keep pressing the [ ] or { { { { } } } } } } } } key to display your user code. Press the [OK] key. Enter the new user code with the Number keys. Program Enter Clear/Stop Press the [OK] key.

  • Page 185: If Your Machine Does Not Operate As You Want

    4. What To Do If Something If Your Machine Does Not Operate As You Want If a malfunction or a misfeed occurs within the machine, the following messages will appear on the panel display. Message Drum unit is not set. Set Drum unit.
  • Page 186 What To Do If Something Goes Wrong - When a service call message is displayed in the panel display Press the [Exit] key. Then turn the main switch off and on. If a service code ap- pears again, contact your service representative. Note If a service code appears on the panel display after you turn the main switch off and on a few times, do not continue turning it on and off.

  • Page 187: If You Cannot Make Prints As You Want

    If You Cannot Make Prints As You Want Problem Misfeeds occur frequently. Improper paper type is se- When you try to set several functions at a time, you cannot set some functions. Parts of the image are not printed in Edge Erase mode.

  • Page 188: Clearing Misfeeds

    What To Do If Something Goes Wrong x Clearing Misfeeds R CAUTION: • Be careful not to cut yourself on any sharp edges when you reach inside the machine to remove misfed sheets of paper or masters. Note After clearing the misfeeds, make sure that all the doors, covers, and units are closed and the x indica- tor is off.

  • Page 189: A + B" Paper Misfeed In The Paper Feed Section

    • When paper edges stick together or paper is not fed to the machine, shuffle the paper as shown. • When you use postcards or thick paper, lower the printing speed to setting 1 or 2. See P.28 “Chang- ing The Printing Speed”. Speed Combine Class...

  • Page 190: B" Paper Or Master Wrapped Around The Drum

    What To Do If Something Goes Wrong Set the drum unit and close the front door. - To prevent paper misfeeds: P.168 “”x + A” Paper Misfeed In The Paper Feed Section”. x + B” Paper Or Master ”x Wrapped Around The Drum When The Master Is Wrapped Around The Drum Open the front door.
  • Page 191 Take out the drum. Note For how to take out the drum unit, see P.87 “Changing The Color Drum Unit”. Remove the misfed paper from the drum. If you cannot find misfed paper in step D D D D , remove misfed paper from the pressure cylinder.

  • Page 192: C" Paper Misfeed In The Paper Exit Section

    What To Do If Something Goes Wrong - To prevent paper misfeeds: If the paper is curled or the original's leading edge margin is too narrow, the following action is necessary. • When you use curled paper, cor- rect the curl as shown. •...

  • Page 193: D" Master Misfeed In The Master Feed Section

    x + D” Master Misfeed In ”x The Master Feed Section Pull out the master feed unit until it stops. Open the master guide. Open the master feed unit cover (1). Remove the master roll (2). Reset the master roll (1). Note The master roll must be posi- tioned as shown in the illustra-...

  • Page 194: B + E" Master Misfeed In The Master Eject Section

    What To Do If Something Goes Wrong Take out the drum. Pull out the misfed master from the inside. Set the drum unit and close the front door. x + B + E” Master Misfeed in ”x The Master Eject Section Open the front door.

  • Page 195: E" Master Misfeed In The Master Eject Section

    Pull out lever E3 and remove the misfed master. Return lever E3 and the master eject unit to their original posi- tion. Set the drum unit and close the front door. x + E” Master Misfeed In The ”x Master Eject Section Open the front door.
  • Page 196 What To Do If Something Goes Wrong Pull the green knob towards you and remove the misfed original. Return the document feed sheet to its original position. Close the ADF cover until it clicks in position and if necessary, close the document feeder.

  • Page 197: When The Open Cover/Unit Indicator (M) Lights

    When The Open Cover/Unit Indicator (M) Lights MMake sure that the following door/ cover are closed. Front Door Close the front door completely. Document Feeder Cover (Option) Close the document feeder cover until it locks in position. When The Open Cover/Unit Indicator (M) Lights TPEH070E TPEH211E...

  • Page 198: When The Add Ink Indicator (J) Lights

    What To Do If Something Goes Wrong When The Add Ink Indicator (j) Lights The Add Ink indicator (j) lights when it is time to supply ink. R CAUTION: • If ink comes into contact with your eyes, rinse immediately in run- ning water.
  • Page 199 Remove the used ink cartridge. Remove the cap of the new ink cartridge. Insert the new cartridge into the ink holder. Note Always supply ink of the same color. Return the ink holder to its original position until it clicks. Close the front door.

  • Page 200: When The Master End Indicator (C) Lights

    What To Do If Something Goes Wrong When The Master End Indicator (C) Lights The Master End indicator (C) lights when it is time to replace the master roll or when you need to set the master roll. R CAUTION: •...
  • Page 201 Insert the paper edge of the master roll as shown in the illustration until the master edge reaches the arrow mark. Close the master guide. Push in the master feed unit until it stops. When The Master End Indicator (C) Lights...

  • Page 202: When The Master Eject Indicator (K) Lights

    What To Do If Something Goes Wrong When The Master Eject Indicator (k) Lights The Master Eject indicator (k) lights when it is time to empty the master eject unit or when you need to set the master eject unit. Note Ink is readily removed from skin by waterless hand cleaners fol-...

  • Page 203: When Other Indicators Are Lit

    When Other Indicators Are Lit Indicator Meaning and action The key counter (option) is not set. Insert the key counter. TPES270E • (Metric version) Color drum unit is installed. A3 A4 TPES280E • (Inch version) Color TPES280N • (Metric version) A3/11"...

  • Page 204: When The Prints Are Not Delivered In A Neat Stack

    What To Do If Something Goes Wrong When The Prints Are Not Delivered In A Neat Stack If you use small size paper, prints might not be delivered in a neat stack. In this case, follow the steps below. Lower the end plate a little. While holding the end plate, lift the an- gle adjustment screw.

  • Page 205: Poor Printing

    Poor Printing Dirty Background If the background of prints is dirty, the drum unit is dirty. R CAUTION: • If ink comes into contact with your eyes, rinse immediately in run- ning water. In the case of any abnormal symptoms, consult a doctor.
  • Page 206 What To Do If Something Goes Wrong Pull out the drum unit. Note For how to take out the drum unit, see Unit”. While pressing the drum lock, turn the drum until you can see the trailing edge of the master. With a dry soft cloth, remove any ink that has accumulated on the trailing edge of the drum unit.
  • Page 207 Insert the drum unit until it locks in position, then lower the drum unit lock lever. Close the front door. Turn on the main switch. TPEH091E TPEH021E Poor Printing...

  • Page 208: Black Line/Stain

    What To Do If Something Goes Wrong Black Line/Stain Check the platen cover and clean it if dirty. See P.196 “Platen Cover”. Check the exposure glass (contact glass) and clean it if dirty. See “Exposure glass (contact glass)”. Check the sheet of the optional docu- ment feeder and clean it if dirty.

  • Page 209: Remarks

    Operation Notes General Cautions • While printing, do not turn off the main switch. • While printing, do not open the door or covers. • While printing, do not unplug the power cord. • While printing, do not move the machine. •...
  • Page 210 REMARKS • When making duplex prints or when using non-white printing paper, the pa- per end sensor might malfunction and fail to detect the paper. In this case, place a blank sheet under the printing paper on the paper feed tray. •...

  • Page 211: Print Paper

    • When you use originals with light lettering, edges of the letters might be printed clearly and the inside of the letters might be light. In this case, in- crease the image density. • When you use originals of fine letters, letters on prints might be skipped. In this case, increase the image density or use Letter mode.

  • Page 212: Pc Controller

    REMARKS PC Controller Important Make sure that m indicator on the PC controller operation panel is off before unplugging the power cord.

  • Page 213: Where To Put Your Machine

    Where To Put Your Machine Your machine's location should be carefully chosen because environmental con- ditions greatly affect its performance. Environmental Conditions Optimum environmental conditions R WARNING: • Do not put any metal objects or containers holding water (e.g. vases, flowerpots, glasses) on the machine. If the con- tents fall inside the machine, a fire or electric shock could occur.

  • Page 214: Power Connection

    REMARKS • Locations directly exposed to cool air from an air conditioner or heated air from a heater. (Sudden temperature changes might cause condensation with- in the machine.) • Places where the machine might be subjected to frequent strong vibration. •...
  • Page 215 Main Frame More than 10 cm, 4.0" More than 60 cm, 23.7" More than 60 cm, 23.7" More than 60 cm, 23.7" Where To Put Your Machine GRINST0E...

  • Page 216: Maintaining Your Machine

    REMARKS Maintaining Your Machine To maintain high print quality, clean the following parts and units regular- Important Do not use benzine, thinner, or other organic liquids. Otherwise, this machine might be damaged. Main Frame Exposure glass (contact glass) Lift the platen cover or document feeder.

  • Page 217: Optional Document Feeder

    Optional Document Feeder Sheet Lift the document feeder. Clean the sheet with a damp cloth and wipe it with a dry cloth. Note If you do not clean the sheet, marks on the sheet will be print- AM1D600 Maintaining Your Machine...

  • Page 218: Combination Chart

    REMARKS Combination Chart This combination chart shows which modes can be used together. means that these modes can be used together. means that these modes cannot be used together. means that these modes cannot be used together. Function to be specified later takes priority.
  • Page 219 Function to be specified later Memory Combine mode (4 Originals) Memory Combine mode (8 Originals) Memory Combine mode (16 Originals) Edge Erase All Class mode Auto Class mode Manual Class mode Class mode Job Separation Overlay Form Stamping Date Page Stamping Stamping mode User Stamping Repeat...
  • Page 220 REMARKS This page is intentionally blank.

  • Page 221: Specifications

    Main Frame Configuration: Desk top Printing Process: Full automatic one drum system Original Type: Sheet/Book Original Size: Maximum 304.8 mm 432 mm, 12.0" Pixel Density: 400 dpi Image Mode: Photo mode (Sand pattern) Letter mode (Standard mode) Letter/Photo mode Pencil mode Tint mode Reduction Ratios: •...
  • Page 222 SPECIFICATIONS From 50 % to 200 % in 1 % steps Printing Area: • A3 drum: • Inch version: More than 290 • Metric version: More than 290 mm • A4 drum: More than 290 mm Print Paper Size: Maximum 297 mm Minimum 70 mm Leading Edge Margin: Less than 10 mm, 0.4"...
  • Page 223 Master Eject Unit Capacity: • A3 drum More than 60 masters • A4 drum 90 masters Dimensions (W D H): Width Stored 625 mm, 24.6" Stored with docu- 625 mm, 24.6" ment feeder Set up 1,405 mm, 55.4" Set up with cabinet 1,405 mm, 55.4"...
  • Page 224 SPECIFICATIONS Noise Emission: Sound power level: The measurements are made according to ISO 7779. Printing Speed 60 rpm 90 rpm 120 rpm Power Source: See the inside front cover of this manual. Power Consumption: • Master Making: Less than 0.3 kW •...

  • Page 225: Document Feeder

    Document Feeder Original Type: Sheet Original Weight: 40.7 g/m to 127.9 g/m Original Size: Max. 297 mm 864 mm, 11.6" Min. 105 mm 128 mm, 4.2" First Copy Time (Master Process Time): Less than 19.5 seconds (A3, 11" 17") Less than 16 seconds (A4, 8 Second Copy Time (First Print Time): Less than 22.5 seconds (A3, 11"...

  • Page 226: Consumables

    SPECIFICATIONS Consumables Name Size Master: Length: 110 m, 410 ft/roll Width: 420 mm, 16.5" 2 Rolls/case Ink-Black 1,000 ml/pack, 600 ml/pack, 5 packs/case Environmental conditions: Ink-Red 1,000 ml/pack, 5 packs/case Ink-Blue 1,000 ml/pack, 5 packs/case Ink-Green 1,000 ml/pack, 5 packs/case Ink-Brown 1,000 ml/pack, 5 packs/case Note...

  • Page 227: Index

    INDEX 16 One-sided Originals 1 One-sided Print Of 16 Images , 124 1 One-sided Originals 1 One-sided Print Of 2 Images , 68 1 One-sided Originals 1 One-sided Print Of 4 Images , 68 2 One-sided Originals 1 One-sided Print Of 2 Images , 63 2 One-sided Originals 1 One-sided Print Of 4 Images , 63...
  • Page 228 Economy Mode , 48 {Economy Mode} key , 6 Edge Erase , 40 {Edge Erase} key , 6 {Enter} key , 7 Envelopes , 43 Environmental Conditions , 193 Erasing Edge Margins , 40 Exit , 9 Exposure Glass , 3 Flip-up Cover , 1 Form , 113 Front Door , 1...
  • Page 229 Monitors , 8 MSTR Makg. Density , 137 Next , 9 No. of Q.start , 141 , 152 No. of Skip Feed , 141 , 151 No Orig. Size , 139 No Orig. Size (ADF) , 139 Number keys , 7 OK , 9 Ppr.
  • Page 230 Safety Information , i Saving Ink , 48 Saving Master , 79 {Security} key , 6 Security Mode , 75 Select , 9 Separating Printing Sets , 77 service call , 166 Set Operation Modes , 136 Setting Q.start , 141 Setting Up The Paper Delivery Tray , 16 Set User Code , 135 , 146 Size , 144...

This manual is also suitable for:

5450

Table of Contents
