Skoda Octavia Workshop Manual

1.8 ltr./92 kw engine- motronic fuel injection and ignition system
Hide thumbs Also See for Octavia:
Table of Contents

Advertisement

Quick Links

See also: Workshop Manual , Owner's Manual
Service
Workshop Manual
OCTAVIA
1.8 ltr./92 kW Engine - Motronic Fuel
Injection and Ignition System
Service Department. Technical Information
S00.5107.50.20
Edition 08.96
