Page 1 SIMPLY CLEVER ŠKODA Octavia Owner's Manual...
Page 2 CAUTION Layout of this Owner's Manual (explanations) A Caution note draws your attention to the possibility of damage to your vehicle (e.g. damage to gearbox), or points out general risks of an accident. This Owner's Manual has been systematically designed to make it easy for you to For the sake of the environment search for and obtain the information you require.
Page 3 Documentation of vehicle delivery ŠKODA extended warranty Date of delivery/first registration (VIN)   Vehicle identification number Stamp of ŠKODA Partner Limitations of the ŠKODA extended warranty Years: ŠKODA Partner Stamp and signature of the vendor I confirm that I have taken delivery of the specified vehicle in good condi- tion, have received information on how to operate it correctly, and have had the terms of the warranty explained to me.
Page 4 Preface You have opted for a ŠKODA – our sincere thanks for your confidence in us. You have received a vehicle with the latest technology and range of amenities. Please read this Owner's Manual carefully, because operation in accordance with these instructions is a prerequisite for proper use of the vehicle.
Page 5: Never Operate The Button 6 In The Instrument Cluster » Fig
Terms used The on-board literature contains the following terms relating to the service work for your vehicle. › “Specialist garage” - a company that carries out specialist service tasks for ŠKODA vehicles. A specialist can be a ŠKODA Partner, a ŠKODA Service Partner, or an independent workshop.
Page 6: Table Of Contents
Anti-theft alarm system Airbag overview Starting and stopping the engine - KESSY Luggage compartment lid Brakes Deactivating airbags Electric luggage compartment lid (Octavia Manual shifting of gears and pedals Transporting children safely Estate) Automatic transmission Electrical power windows Child seat...
Page 7: Table Of Contents
General Maintenance Technical data Vehicle care Technical data Service intervals Vehicle data Service work, adjustments and technical Index alterations Washing your car Taking care of your vehicle exterior Taking care of the interior Inspecting and replenishing Fuel Engine compartment Engine oil Coolant Brake fluid Vehicle battery...
Page 8: Materials Defect Liability And Škoda Warranty For New Cars
If your ŠKODA vehicle was purchased from a ŠKODA Partner outside the European Materials defect liability and ŠKODA Economic Area and Switzerland, claims arising from the ŠKODA warranty must al- so be made through a ŠKODA Service Partner outside the European Economic warranty for new cars Area and Switzerland.
Page 9: Mobility Warranty And Škoda Extended Warranty
Note Mobility warranty and ŠKODA extended warranty The mobility warranty and optional ŠKODA extended warranty are only available for some countries.  Mobility warranty The mobility warranty provides a sense of security when travelling in your vehicle. As part of the mobility warranty, if your car breaks down when you are on the move as a result of an unexpected fault, you can access services to ensure your continued mobility.
Page 10: Abbreviations
Abbreviations Abbreviation Definition Engine revolutions per minute Anti-lock brake system Adaptive cruise control Adaptive headlights Traction control in g/km discharged quantity of carbon dioxide in grams per driven kilo- metre Diesel particle filter Automatic double clutch gearbox Active driver-steering recommendation Electronic differential lock Economic Commission for Europe EPC fault light...
Page 11 Fig. 1 Cockpit Using the system...
Page 12: Using The System
CD/DVD drive and memory card slot (in the passenger-side storage Using the system compartment) » owner's manual for the Infotainment radio and/or navigation Air outlet vent Cockpit Key switch for switching off the front passenger airbag (in front passenger storage compartment) Door opening lever Overview Power window in the front passenger door...
Page 13 ›  Parking aid ›  Tyre inflation pressure calibration Depending on equipment fitted: › USB/AUX input » Infotainment Manual, chapter USB/AUX In- puts › MEDIA IN input » Infotainment Manual, chapter MEDIA IN input Note The position of some of the controls on right-hand drive models may differ from that shown in »...
Page 14: Instruments And Warning Lights
WARNING Instruments and warning lights Concentrate fully at all times on your driving! As the driver you are fully re- ■ sponsible for road safety. Instrument cluster Never operate the button in the instrument cluster » Fig. 2 on page 11 ■...
Page 15: Instrument Cluster
 Bar with warning lights » page 15 First read and observe the introductory information and safety warn- ings on page 11. Button for: › Set hours/minutes » page 14 › The instrument cluster can have one of the following types of display »...
Page 16: Coolant Temperature Gauge
Coolant temperature gauge Fuel gauge Fig. 4 Fig. 5 Coolant temperature gauge Fuel gauge   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 11. ings on page 11.
Page 17: Counter For Distance Driven
Counter for distance driven Viewing the charge level vehicle battery  First read and observe the introductory information and safety warn- Fig. 6 ings on page 11. Segment display / MAXI DOT dis- › play Switch off the ignition. › Press and hold the button »...
Page 18: Warning Lights
The condition of some features and systems is shown by the warning icons on Warning lights the display » page The warning lights are at the following locations in the instrument cluster » Fig. 2  Introduction on page 11. ›...
Page 19: Automatic Transmission
Automatic Transmission    First read and observe the introductory information and safety warn- ings on page 15. The warning lights indicate a fault or the state of the automatic gearbox.   Warning light Message Meaning and Action Error: gearbox.
Page 20: Seat Belt Warning Light
Stop the vehicle, switch off the engine, and check the level of the brake flu- Power steering   » page 223 »  If the warning light lights up together with the warning light , there is a First read and observe the introductory information and safety warn- ...
Page 21: Traction Control System (Tcs) Off
› If the warning light does not illuminates after you switch the engine back on, Switch the ignition off and on again.  the ASR is fully functional again. If the indicator light does not illuminate after you switch the engine back on, ...
Page 22: Rear Fog Light
Seek assistance from a specialist garage immediately.  Rear fog light   First read and observe the introductory information and safety warn- Security Systems  ings on page 15.  First read and observe the introductory information and safety warn- The warning light comes on when the rear fog light is switched on.
Page 23: Tyre Inflation Pressure
WARNING Lane following system (Lane Assist)   If there is a fault in the safety system, have it checked immediately by a spe-  First read and observe the introductory information and safety warn- cialist garage. Otherwise, there is a risk of the systems not being activated in ings on page 15.
Page 24: Warning Icons In The Display
Warning icons in the display Fog lights   First read and observe the introductory information and safety warn-  Introduction ings on page 15. This chapter contains information on the following subjects: The warning light comes on when the fog lights are operating. ...
Page 25: Warning
While the operational faults remain unrectified, the messages are always indica- Seek assistance from a specialist garage immediately. ted again. After they are displayed for the first time, the symbols continue   to be indicated without any extra messages for the driver. CAUTION On vehicles with a colour MAXI DOT display some warning icons in the display are If the icon ...
Page 26: Engine Oil Pressure
WARNING  Engine oil level If you have to stop for technical reasons, then park the vehicle at a safe dis-  ■ First read and observe the introductory information and safety warn- tance from the traffic, switch off the engine and switch on the hazard warning ings on page 21.
Page 27: Lamp Failure
If the filter is not properly cleaned, the warning icon  does not go out and the WARNING warning icon begins to flash.  Do not continue your journey if for some reason it is not possible to top up ■...
Page 28 The following message is shown in the information cluster display.  Ice warning Top up washer fluid!   First read and observe the introductory information and safety warn- WASHER FLUID PLEASE TOP UP  ings on page 21. Top up with liquid »...
Page 29: Information System
› Door, boot lid and bonnet warning » page Information system › Eco tips » page › Compass display » page › Driving data (multifunction display) » page › Driver information system Warning against excessive speeds » page › Data relating to the Maxi DOT display »...
Page 30: Information System
Description of the operation Button / Operation Action wheel » Fig. 7 Select data Briefly push up or down Set data values Briefly push up or down Open main menu in the MAXI DOT display Press and hold button Show data Press briefly Confirm data Press briefly...
Page 31 When the system determines that a change in gear is required, the arrow symbol Eco tips and the recommended gear appear next to the current gear indication » Fig. 8 .  First read and observe the introductory information and safety warn- For instance, if ...
Page 32: Driving Data (Multifunction Display)
If the trip is interrupted for more than 2 hours, the memory is automatically Driving data (Multifunction display) erased. Long-term (MAXI DOT display) or “2” (segment display)  Introduction The memory gathers driving information from any number of individual journeys up to a total of 99 hours and 59 minutes driving or 9999 kilometres driven.
Page 33 Range Traffic sign recognition The range indicates the distance you can still drive with your vehicle based on the The display can show up to three of the following traffic signs simultaneously. level of fuel in the tank and the same style of driving as before. ›...
Page 34: Maxi Dot Display
Together with the consumption display, a list of three convenience consumers If the pre-set speed is exceeded, an acoustic signal appears as a warning tone with the highest consumption is also displayed. and a warning message appears in the display. Speed ...
Page 35: Maxi Dot Display
Main menu Lap timer (Stop watch)  First read and observe the introductory information and safety warn- Fig. 10 ings on page 31. Operating lever: Button to open the menu item wizard The Laptimer function offers the possibility of calculating the lap time, for exam- ple when driving on a race course.
Page 36: Service Interval Display
Abort lap - Cancel the timer (the aborted lap time is not stored) ■ Note Hang up - End timing (the aborted lap time is stored) ■ Information is retained in the Service Interval Display even after the vehicle bat- ■...
Page 37: Service Interval Display
› Oil change and inspection now! Release and then press again the button  OIL CHAN_ AND INSPECTION NOW  CAUTION Displaying the distance and days until the next service interval › Switch on the ignition. We recommend that you do not reset the service interval display yourself. Incor- ›...
Page 38: Unlocking And Opening
The following is true after locking Unlocking and opening › The doors, the boot lid and the fuel filler flap are locked. › The interior light operated via the door contact goes out. › The safe securing system is switched on. ›...
Page 39: Vehicle Key
CAUTION Vehicle key Each key contains electronic components; therefore it must be protected ■ against moisture and severe shocks. Keep the groove of the keys absolutely clean. Impurities (textile fibres, dust, ■ etc.) have a negative effect on the functionality of the locking cylinder and igni- tion lock.
Page 40: Unlocking/Locking With The Remote Control
WARNING Unlocking/locking with the remote control If the car is locked from the outside and the safelock system is switched on, Fig. 13 there must not be any person in the car as it is then not possible to open ei- ther a door or a window from the inside.
Page 41: Unlocking/Locking - Kessy
If you cover the sensor at the same time as the sensor » Fig. 14 when un- Unlocking/locking – KESSY locking the vehicle, it is not unlocked. If the vehicle is locked via the sensor , it will not be possible to unlock it again in the following 2 seconds via the sensor - prevents accidental unlocking.
Page 42: Individual Settings
If the vehicle is locked and the safe securing system is switched off, the door can Unlocking a vehicle side door be opened separately from the inside by a single pull on opening lever. This function enables you to unlock both doors on the driver's side. The other doors, the fuel filler flap and the boot lid remain locked and are only unlocked af- Switching off ter being opened again.
Page 43: Child Safety Lock
Unlocking Switching on › › Press / » Fig. 15 press. Turn the slot of the safety lock in the direction of the arrow » Fig. 16 (mirror- inverted on the right-hand door). The symbol  in the button is no longer illuminated. Switching off The following applies if your vehicle has been locked using the central locking ›...
Page 44: Kessy
Additionally, on vehicles which are fitted with the anti-theft alarm system, an au- WARNING dible signal sounds. Make sure that the door has closed correctly as it can open suddenly while ■ The system has not found a key driving – risk of death! Only open and close the door when there is no one in the opening/closing If the system has not found a key in the vehicle, the following message appears ■...
Page 45: Anti-Theft Alarm System
Activation after 90 hours Activating/deactivating › Unlock the vehicle using the symbol button  on the remote control key. › Unlocking the driver's door in an emergency » page 248.   First read and observe the introductory information and safety warn- ings on page 42.
Page 46: Luggage Compartment Lid
Luggage compartment lid Interior monitor and towing protection  Introduction Fig. 18 Button for interior monitor and towing protection This chapter contains information on the following subjects: Opening/closing Automatic locking WARNING Ensure that the lock is properly engaged after closing the luggage compart- ■...
Page 47: Electric Luggage Compartment Lid (Octavia Estate)
Delayed locking can be deactivated by a specialist garage at any time. Note More detailed information is available from your authorised ŠKODA Partner.  Electric luggage compartment lid (Octavia Estate)  First read and observe the introductory information and safety warn- ings on page 43.
Page 48 If you rapidly enter the vehicle during the opening or closing process of the boot Operating description lid, the whole vehicle may jerk and as a result the movement of the lid can be in- terrupted. Manual operation Manually opening and closing the lid is only possible in exceptional cases. It must be completed slowly and without sudden movements as close to the centre of the lid as possible »...
Page 49 The range of the area changes proportionally, depending on the setting of the Operating the lid with the button does not work if the vehicle was locked from top position of the lid » page the outside. If the lid is set in the uppermost position in the area , the area is not active.
Page 50: Electrical Power Windows
The top lid position is adjusted, for example, in the following situations. Force limit › When the space for opening the lid is limited (e.g. garage height). Window convenience operation › For a more convenient operation, such as by a person's height. Operational faults The top position which is reached when the lid opens automatically, is always The electrical power windows can only be operated when the ignition is switched...
Page 51: First Read And Observe The Introductory Information And Safety Warn
The window can be completely opened automatically by briefly pressing the but- For the sake of the environment ton as far as the stop. Renewed pressing of the button causes the window to stop immediately. At high speeds, you should keep the windows closed to prevent unnecessarily high fuel consumption.
Page 52: Force Limit
The window can be completely opened automatically by briefly pressing the but- Window convenience operation ton down as far as the stop. Renewed pressing of the button causes the window to stop immediately.  First read and observe the introductory information and safety warn- ings on page 47.
Page 53: Panoramic Sliding/Tilting Roof (Octavia)
Pull the relevant button upwards again for approx. 3 seconds, and keep it press- Fig. 25 ed down.  Control dial for the sliding/tilting roof Panoramic sliding/tilting roof (Octavia)  Introduction This chapter contains information on the following subjects:  First read and observe the introductory information and safety warn-...
Page 54: Panoramic Sliding/Tilting Roof (Octavia Estate)
– risk of injury! ture.  CAUTION Panoramic sliding/tilting roof (Octavia Estate) During the winter it may be necessary to remove any ice and snow in the vicinity of the sliding/tilting roof before opening it to prevent any damage to the opening ...
Page 55 WARNING Operation When closing the sliding/tilting roof proceed with caution to avoid causing Fig. 26 crushing injuries – risk of injury! Control dial for the sliding/tilting roof CAUTION During the winter it may be necessary to remove any ice and snow in the vicinity of the sliding/tilting roof before opening it to prevent any damage to the opening mechanism.
Page 56 Convenience operation of sliding / tilting roof  First read and observe the introductory information and safety warn- ings on page 51. The sliding / tilting roof can be operated by locking or unlocking using the key or using the KESSY system with the aid of the sensor »...
Page 57: Lights And Visibility
WARNING Lights and visibility The activation of the lights should only be undertaken in accordance with ■ national legal requirements. Lights The driver is always responsible for the correct settings and use of the ■ lights. The automatic driving lamp control  only operates as a support and does ■...
Page 58: Side Lights And Low Beam
Note Side lights and low beam We recommend you adjust the headlight beam when the low beam is switched ■ Fig. 28 The Bi-Xenon bulbs adapt automatically to the load and driving state of the ve- Light switch and control dial for ■...
Page 59: Turn Signal And Main Beam
The daytime running lights are switched on automatically if the following condi- On vehicles with Headlight assist, when the lever is put into position , the As- tions are met: sistant is activated » page The ignition is switched on. ...
Page 60: Automatic Driving Lamp Control
Automatic driving lamp control Adaptive headlights (AFS)  First read and observe the introductory information and safety warn- Fig. 30 ings on page 54. Light switch The AFS system works in tandem with automatic driving lamp control , please read the following »...
Page 61: Headlight Assist
 The mode is active at speeds of 15 – 70 km/h and if the rear fog light is switched First read and observe the introductory information and safety warn- on for a period of time longer than 10 seconds. The mode is deactivated when the ings on page 54.
Page 62: Fog Lights
Information message Fog lights The messages and information are indicated in the instrument cluster display. Fault: Light Assist  Fig. 32 LIGHT ASSIST FAULT  Light switch Seek help from a specialist garage. Light Assist: clean the windscreen!  WINDSCREEN PLEASE CLEAN ...
Page 63: Rear Fog Light
The vehicle is stopped or moves at a speed of no more than 40 km/h.  COMING HOME / LEAVING HOME The low beam is switched on or the light switch is in the position  and the  low beam is switched on. ...
Page 64: Interior Lights
Note Parking lights If this function is activated constantly, the battery will be heavily discharged par-  First read and observe the introductory information and safety warn- ticularly in short-haul traffic.  ings on page 54. Parking light  switching on Hazard warning light system ›...
Page 65: Switching On/Off
If light operation with the door contact switch is enabled, the light will come on Front interior light when one of the following events occurs: › The vehicle is unlocked. › One of the doors or the luggage compartment lid is being opened. ›...
Page 66: Rear Interior Light
Switching lamp without reading lights on/off Front door warning light › Press the button » Fig. 36 - . Switching the reading light on/off Fig. 38 › Press the button  or  » Fig. 36 - .  Warning light Rear interior light Applies to vehicles with a panoramic sliding roof.
Page 67: Visibility
 First read and observe the introductory information given on page 64. WARNING If the entry light is on, do not touch its cover – risk of burns! Explanation of graphic » Fig. Switching the windscreen heater on/off  Note Switch the rear window heater on/off ...
Page 68: Windscreen Wipers And Washers
Sun visors Sun screen Fig. 41 Sun screen  First read and observe the introductory information given on page 64. Fig. 40 Sun visor: left/right  First read and observe the introductory information given on page 64. The sun screen is located in a housing on the luggage compartment cover. Extending The sun visor for the driver or front passenger can be pulled out of the fixture and ›...
Page 69 The rear window is wiped once automatically if the windscreen wipers are on Note when reverse gear is selected. Each time the ignition switches off for the third time, the position of the wind- ■ Automatic rear window wiping can be activated or deactivated in the Infotain- screen wipers changes.
Page 70 The operating lever remains in position To ensure the proper operation of the cleaning system during the winter, any Automatic rear window wipe (Octavia Estate) snow should be removed from the washer nozzle fixtures and ice should be If the lever is in position »...
Page 71: Rear Mirror
Note Rear mirror Automatic mirror dimming operates only properly if the sun screen for the rear ■  Introduction window in the housing on the boot cover is not in use or the light striking the in- terior rear-view mirror is not affected by other objects. This chapter contains information on the following subjects: If the automatic interior mirror dimming is switched off, the exterior mirror dim- ■...
Page 72 If automatic dimming is activated, the mirror dims automatically depending on Interior mirror the light striking the mirror from the rear. When the interior lights are switched on or the reverse gear is engaged, the mir- Fig. 43 ror always moves back into the basic position (not dimmed). Manual dimming mirror Do not attach external navigation devices on to the windscreen or in the vicinity of the automatic dimming interior mirror...
Page 73 The synchronous setting of both mirrors can be activated or deactivated in the In- fotainment » Operating instructions for Infotainment, chapter Vehicle settings (CAR button). Folding-in both of the exterior mirrors with the rotary knob It is only possible to fold in both exterior mirrors when the ignition is switched on and at a speed of up to 50 km/h.
Page 74: Seats And Useful Equipment
WARNING (Continued) Seats and useful equipment Each occupant must correctly fasten the seat belt belonging to the seat. ■ Children must be fastened » page 193, Transporting children safely with a Adjusting the seats suitable restraint system. At all times, the front seats and head restraints must be adjusted to match ■...
Page 75 Adjusting the angle of the seat backrest Note › Relieve any pressure from the seat backrest (do not lean on it) and turn the handwheel » Fig. 46 in the direction of the arrow. After a certain time, play can develop within the adjustment mechanism of the ■...
Page 76: Head Restraints
Set the height of the seat cushion Electric front seat adjustment › Push the switch in the direction of one of the arrows 3 » Fig. Adjusting the angle of the seat backrest › Push the switch in the direction of one of the arrows»...
Page 77 › Hold the rear head restraints on the sides with both hands and move them up- Memory function of the electrically adjustable seat wards » Fig. › To move the head restraint downwards, press and hold the safety button with one hand and press the head restraint downwards with the other hand. Fig.
Page 78 › Engage reverse gear. › Adjust the front passenger's mirror to the desired position » page › Press down on the desired memory button when the ignition is switched on › Disengage reverse gear. and the driver's door is closed. The adjusted position of the exterior mirror is stored in the remote control key Stopping the ongoing adjustment memory.
Page 79: Seat Features
With repeated pressing of the switch, the level of the seat heating is down-regu- Seat features lated up to the switch-off. The level of the seat heating is indicated by the num- ber of illuminated warning lights underneath/in the switch. ...
Page 80: Front Armrest
Front armrest Rear armrest Fig. 52 Fig. 53 Adjust armrest Fold the armrest forwards   First read and observe the introductory information given on page 76. First read and observe the introductory information given on page 76. The armrest is adjustable for height and length. Folding forward ›...
Page 81: Seat Backrests
The locking mechanism must audibly snap into place. Seat backrests Folding backwards › Place the lever in position » Fig. › Fold the seat backrest in the opposite direction of the arrow The locking mechanism must audibly snap into place. WARNING The front passenger airbag should be switched off when transporting ob- ■...
Page 82: Practical Equipment
If the front seats are too far back, we recommend that you have the rear head restraints removed before the seat backrests are folded forward. Store the removed head restraints in such a way that they are not be damaged or soiled. Applies to the Octavia Estate. Seats and useful equipment...
Page 83: Car Park Ticket Holder
Storage pockets on the front seats WARNING Storage compartment in rear centre console The attached note has to always be removed before starting off in order not 230-volt power to restrict the driver's vision. Rear seat backrest with long-cargo channel ...
Page 84: Storage Compartments In The Doors
Storage compartments in the doors Holder for reflective vest Fig. 60 Driver seat: Holder for reflex vest  First read and observe the introductory information and safety warn- Fig. 59 Storage compartment: in the front door/in the rear door ings on page 79.
Page 85: Storage Compartment In The Front Center Console - Not Lockable
Closing takes place in reverse order. storage compartment in the front center console - not lockable The storage compartment is provided for storing small items, such as a mobile phone. Fig. 61 The roof antenna signal can be amplified and “fed” to the storage compartment The open storage compartment to improve the functions of your mobile phone »...
Page 86: Cigarette Lighter
WARNING Note Never put hot beverage containers in the cup holder. If the vehicle moves, The cigarette lighter socket cannot be used as a 12Volt socket. ■ ■ they may spill – risk of scalding! Further information » page 200, Service work, adjustments and technical alter- ■...
Page 87: 12-Volt Power Outlet
CAUTION CAUTION When removing do not hold the ashtray at the cover on the front – risk of break- The power socket can only be used for connecting approved electrical accesso- ■ age. ries with a total power uptake of up to 120 watt. ...
Page 88: Waste Container
Closing takes place in reverse order. Waste container Replace bags › Remove the waste container from the slot. › Push the two catches of the inner frame out of the container body in the direc- tion of the arrow » Fig. ›...
Page 89: Storage Compartment Under The Front Armrest
You can use this holder to store e.g. a mobile phone, MP3 player or similar devi- Glasses storage box ces. WARNING Fig. 71 Opening the glasses storage box Never use the holder as an ashtray or for storing flammable objects – risk of fire! ...
Page 90: Storage Compartment On The Passenger Side
Note Storage compartment on the passenger side When the stowage compartment is opened, a light lights up.  Storage compartment under the passenger seat Fig. 73 Front passenger seat: Opening the storage compartment Fig. 72 Open storage compartment/control cooling of storage compartment ...
Page 91: Clothes Hook
WARNING Clothes hook Never put heavy items in the map pockets – risk of injury!  First read and observe the introductory information and safety warn- ings on page 79. CAUTION The clothes hooks are located on the middle door pillars of the vehicle and on the handle of the headliner above each of the rear doors.
Page 92: 230-Volt Power
WARNING 230-volt power The power socket can only be used for connecting approved electrical ac- ■ Fig. 76 cessories with a two-pin 230V plug, with a total power uptake of up to 150 watt. Centre console at rear: 230-Volt power socket The power socket and the connected electrical devices only work if the igni- ■...
Page 93: Rear Seat Backrest With Long-Cargo Channel
Rear seat backrest with long-cargo channel Removable ski bag Fig. 78 Securing the through-loading  First read and observe the introductory information and safety warn- Fig. 77 Rear seats: Cover handle/boot: Unlock button ings on page 79.  First read and observe the introductory information and safety warn- The removable through-loading bag is solely used for transporting skis.
Page 94: Luggage Compartment
Luggage compartment cover ing eyes. The items carried in the luggage compartment must be stored in such a way Roll-up luggage compartment cover (Octavia Estate) ■ that no objects are able to slip forward if any sudden driving or braking ma- Stowing roll-up luggage compartment cover and roof racks noeuvres are undertaken –...
Page 95: Class N1 Vehicles
Rear window heater. ■ Rear window with an integrated antenna. ■ Integrated antenna in the rear side windows (Octavia Estate). ■ Note Tyre pressure must be adjusted to the load » page 229, Service life of tyres.
Page 96: Fixing Nets
CAUTION Fixing nets The maximum permissible load of the fixing nets is 1.5 kg. ■ Do not place any sharp objects in the nets – risk of damaging the net. ■  Folding double hooks Fig. 83 Folding double hooks Fig.
Page 97: Foldable Hooks (Octavia Estate)
CAUTION The maximum permissible load of the hook is 7 kg.  The floor covering can be fixed with the Octavia Estate vehicle only if the variable loading floor is folded in the upper position » Fig. 99 on page 101.
Page 98: Luggage Net
CAUTION Luggage compartment cover The double sided floor covering can only be used in vehicles without the variable loading floor » page 99 - There is a risk of damage to the variable loading floor. Note For easier turning of the covering, use the loop attached. ...
Page 99: Roll-Up Luggage Compartment Cover (Octavia Estate)
Opening the boot lid also lifts up the boot cover.  No objects should be placed on the foldable boot cover.  Roll-up luggage compartment cover (Octavia Estate) Fig. 89 Pull out and remove the roll-up luggage compartment cover/roll up roll-up luggage compartment cover Using the system...
Page 100: Stowing Roll-Up Luggage Compartment Cover And Roof Racks
› Replace the side trims of the luggage compartment in the opposite direction of Stowing roll-up luggage compartment cover and roof racks the arrow › Fold out the variable loading floor to the upper position » page 100. Stowing the roll-up luggage compartment cover ›...
Page 101: Storage Compartment In The Luggage Compartment
Note Storage compartment in the luggage compartment We recommend you use the cargo element to secure items of luggage behind the rear seats.  Storage compartments under the floor covering Fig. 92 Removing stowage compartment and cargo element/example of at- taching an item of luggage using the cargo element ...
Page 102: Compartment (Estate)
› Place the rear bar against the front bar and press them together at both ends Multifunction box (Octavia Estate) › Fold back the front hooks on both sides of the luggage compartment. Removing/inserting › Remove the roll-up luggage compartment cover »...
Page 103: Positions Of The Variable Loading Floor
The room under the variable loading floor can be used to store away objects. Positions of the variable loading floor Set into the lower position › Check that there are no objects in the space under the variable loading floor. ›...
Page 104: Net Partition (Octavia Estate)
The variable loading floor is secured against movements in the grooves  Fig. 99 Variable load floor when folded: in the lower position / in the upper Net partition (Octavia Estate) position   First read and observe the introductory information and safety warn-...
Page 105  First read and observe the introductory information and safety warn- WARNING ings on page 101. Check that the crossbar of the net partition is hung firmly into the recepta- ■ Extending cles » Fig. 101 on page 102 and »...
Page 106: Roof Rack System
Using the net partition behind the front seats Removing and refitting the net partition housing Fig. 103 Fig. 104 Net partition behind the front Rear seats: Removing the net seats in the pulled-out state partition housing   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 101.
Page 107: Roof Rack System
WARNING Note The items which you transport on the roof rack must be reliably attached – The removed roof rack for the Octavia Estate can be stowed in the stowage com- ■ risk of accident! partment under the variable loading floor »...
Page 108 Roof load  First read and observe the introductory information and safety warn- ings on page 103. The maximum permissible roof load (including roof rack system) of 75 kg and the maximum permissible total weight of the vehicle should not be exceeded. The full permissible roof load cannot be used if a roof rack system with a lower load carrying capacity is used.
Page 109: Heating And Air-Conditioning
Note Heating and air-conditioning The used air streams out through the vents in the luggage compartment. ■ We recommend that you do not smoke in the vehicle when the recirculating air ■ Heating, ventilation, cooling mode is operating since the smoke which is drawn at the evaporator from the in- terior of the vehicle forms deposits in the evaporator of the air conditioning sys- tem.
Page 110 The direction of airflow can be adjusted using the air outlet vents 3, 4 » Fig. 106 Air outlets and 6 » Fig. 107 - the outlets can be opened and closed individually. Changing the air flow direction › To change the height of the air flow, swivel the horizontal fins with the movable adjuster »...
Page 111: Heating
It recommended to open the windows or the doors of a vehicle for which the inte- Control elements rior has been strongly heated through the effect of direct sunlight in order to al- low the heated air to escape. The cooling system should not be on if the windows are open. For the sake of the environment Pollutant emissions are also reduced when fuel is saved »...
Page 112: Heating
Adjusting  First read and observe the introductory information given on page 108. Recommended basic settings of the heating controls. Control dial settings » Fig. 108 on page 108 Air outlet vents 4 » Fig. 106 Adjustment Button  page 107 Defrosting the windscreen and side To the right up to the Open and align with the side win-...
Page 113: Air Conditioning System (Manual Air Conditioning System)
Air conditioning system (manual air conditioning Control elements system)  Introduction This chapter contains information on the following subjects: Control elements adjusting Recirculated air mode The cooling system only operates if the following conditions are met. The cooling system is switched on »...
Page 114: Recirculated Air Mode
adjusting  First read and observe the introductory information and safety warnings on page 110. Recommended basic settings of the air conditioning controls. Control dial settings » Fig. 109 on page 110 Button » Fig. 109 on page 110 Air outlet vents 4 »...
Page 115: Climatronic (Automatic Air Conditioning System)
WARNING Control elements Never leave recirculated air mode switched on over a longer period of time, as “stale air” can cause driver and passenger fatigue, reduce attention levels and also cause the windows to mist up. The risk of having an accident increases. Switch off recirculated air mode as soon as the windows start to mist up.
Page 116: Setting Temperature
Switching the windscreen heater on/off » page 64 The warning light in the button lights up.  Climatronic set in the Infotainment » Operating instructions for Infotain- ›  Press the symbol button  again. ment The warning light in the button goes out. Switch the temperature setting in Dual mode on/off »...
Page 117: Controlling Blower
CAUTION WARNING Lengthy and uneven distribution of the air flow out of the vents (especially Never leave recirculated air mode switched on over a longer period of time, as around the feet) and large differences in temperature, for example, when getting “stale air”...
Page 118: Auxiliary Heating (Auxiliary Heating And Ventilation)
The auxiliary heating (parking heating) warms up the coolant by combusting fuel Defrosting windscreen from the vehicle tank. The coolant heats air flowing into the passenger compart- ment (as long as the blower fan speed » Fig. 108 on page 108 or »...
Page 119 Switching off automatically Switching on/off Turning off the auxiliary heating (auxiliary heating) occurs in the following cases. › The set switch-off has been achieved » Operating instructions for Infotainment, chapter Vehicle settings. › The fuel level has reached the reserve area (the warning icon  illuminates). ›...
Page 120 After pressing the button, the warning light in the remote control gives the user different kinds of feedback: Display warning light » Fig. 112 Meaning The auxiliary heating has been switch- Lights up green for around 2 seconds. ed on. The auxiliary heating has been switch- Lights up red for around 2 seconds.
Page 121: Driving
WARNING (Continued) Driving Adjust the steering wheel so that the distance » Fig. 113between the ■ steering wheel and your chest is at least 25 cm. Adjust the distance between the legs and the dash panel in the knee airbag area so that there is a distance Starting-off and Driving of at least 10 cm .
Page 122: Starting And Stopping The Engine Using The Key
WARNING Power steering When driving without the engine running, the ignition key must always be in  ■ First read and observe the introductory information and safety warn- the position » Fig. 115 on page 120 (ignition switched on). This position is ings on page 118.
Page 123: Ignition Switch
 First read and observe the introductory information and safety warn- For the sake of the environment ings on page 119. Do not warm up the engine while the vehicle is stationary. If possible, start your Petrol engines » Fig. 115 journey as soon as the engine has started.
Page 124: Starting And Stopping The Engine - Kessy
› Depress and hold the clutch pedal (vehicles with a manual gearbox) or brake Note pedal (vehicles with an automatic gearbox) until the engine starts. › Turn the key into position as far as it will go - the engine's starting proce- For vehicles with automatic transmission, the ignition key can only be removed if dure will commence (do not touch the accelerator).
Page 125: Steering Lock / Unlock
After switching off the ignition, the radiator fan may intermittently continue to ■ WARNING operate for approx. 10 minutes. Under certain circumstances (e.g. after switching off the ignition and opening Never leave the engine running in unventilated or closed rooms. The ex- ■...
Page 126: Switching On The Ignition
› If the steering is still not unlocked, then the following message is displayed on Press the starter button » Fig. 116 on page 122 briefly – the engine starts auto- the display of the instrument cluster. matically. › Release the handbrake. Move the steering wheel! ...
Page 127: Brakes
› The engine and the ignition are switched off simultaneously. Press the starter button » Fig. 116 on page 122 for longer than 1 second or twice  within 1 second. After emergency stop of the ignition, the steering is unlocked. ...
Page 128: Brakes
Low brake fluid level Information on braking An insufficient level of brake fluid may result in problems in the brake system. The level of the brake fluid is monitored electronically » page Brake system.   First read and observe the introductory information and safety warn- ings on page 124.
Page 129: Manual Shifting Of Gears And Pedals
WARNING WARNING Please note that the handbrake must be fully released. A handbrake which is Never engage reverse gear when driving – risk of accident! only partially released can result in the rear brakes overheating. This can have a negative effect on the operation of the brake system – risk of accident! ...
Page 130 WARNING Modes and use of selector lever Do not depress the accelerator if changing the forward driving mode – risk ■ of accident! Never move the selector lever to mode R or P when driving – risk of an acci- ■...
Page 131 Before moving into mode R from mode P or N, depress the brake pedal while si- Defective selector lever lock multaneously pressing the lock button » Fig. 121. If the selector lever lock is defective or its power supply is interrupted (e.g. dis- charged vehicle battery, blown fuse), the selector lever can no longer be moved –...
Page 132 › Pull the right-hand paddle » Fig. 122 briefly towards the steering wheel. The selector lever position N does not have to be selected when stopping for a short time, such as at a cross roads. Shifting down gears › Push the selector lever backwards »...
Page 133: Running In
The gearbox does not shift up into the highest gear until the engine has reached During the first operating hours the engine has higher internal friction than later its maximum revolutions for this gear range. until all of the moving parts have harmonized. The driving style which you adopt during the first approx.1500 kilometres plays a decisive part in the success of run- WARNING ning in your car.
Page 134: Economical Driving And Environmental Sustainability
Fuel consumption is also be influenced by external factors which are beyond the New brake pads driver's control. Consumption increases during the winter or under difficult condi- tions, on poor roads, etc.  First read and observe the introductory information given on page 130. Fuel consumption can vary considerably from the manufacturer's data, as a result of outside temperatures, the weather and driving style.
Page 135 Economical gear changing Avoiding full throttle Fig. 123 Fig. 124 Principle sketch: Fuel consump- Principle sketch: Fuel consump- tion in litres/100 km depending tion in litres/100 km. and speed on the selected gear in km/h   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 131.
Page 136 If an engine is only idling it takes much longer for it to reach its normal operating Convenience consumers temperature. Wear-and-tear and pollutant emissions, though, are particularly high in the warming-up phase. Therefore, start driving as soon as the engine has ...
Page 137: Environmental Compatibility
For the sake of the environment Avoiding unnecessary ballast Additional improvements to the fuel economy can be made by using synthetic  ■ First read and observe the introductory information and safety warn- high-lubricity oils. ings on page 131. Regularly check the ground under the vehicle. Have your vehicle inspected by a ■...
Page 138: Avoiding Damage To Your Vehicle
Choice of materials General information › Extensive use of recyclable material. › Air conditioning filled with CFC-free refrigerant.  First read and observe the introductory information given on page 135. › No cadmium. › No asbestos. › Reduction in the “vaporisation” of plastics. Pay attention to low-slung parts of the vehicle, such as the spoiler and exhaust, particularly in the following situations.
Page 139: Driving Abroad
› Never stop in the water, do not reverse and do not switch the engine off. In certain countries it is also possible that the ŠKODA Partner network is limited › Deactivate the START-STOP system before driving through water » page 158.
Page 140: Assist Systems
Electronic Stability Control (ESC) Assist systems Fig. 127 Brake assist systems ESC button  Introduction This chapter contains information on the following subjects: Electronic Stability Control (ESC) Antilock Braking System (ABS) Traction Control System (TCS)  First read and observe the introductory information and safety warn- Electronic Differential Lock (EDL and XDS) ings on page 137.
Page 141 Activate/deactivate TCS CAUTION Within the ESC system, the TCS can be activated or deactivated in the Infotain- ment » Infotainment manual, chapter Vehicle settings (key CAR) or with the sym- By activating ESC Sport, TCS is automatically deactivated. As a result of this, some bol key ...
Page 142 During an intervention of the system, the TCS warning light flashes in the in-  Driver Steering Recommendation (DSR) strument cluster.  The TCS should normally always be enabled. The system should be deactivated First read and observe the introductory information and safety warn- only in the following situations, for example.
Page 143: Parking Aid
CAUTION Multicollision brake If a warning signal sounds for about 3 seconds after activating the system and  ■ First read and observe the introductory information and safety warn- there is no obstacle close to your car, this indicates a system fault. The fault is ings on page 137.
Page 144: Parking Aid
Image Description - approximate range of sensors (in cm) Function Range » Fig. 129 12 sensors 8 sensors 4 sensors The interval between the acoustic signals becomes shorter as the clearance is re- duced. A continuous tone sounds from a distance of approx. 30 cm - danger area. From this moment on do not continue driving! The length of the vehicle can be increased with an installed detachable towing Fig.
Page 145: Park Assist
Park assist Automatic system activation when moving forward  First read and observe the introductory information and safety warn-  Introduction ings on page 140. This chapter contains information on the following subjects: Automatic activation takes place at a speed below around 10 km/h under the fol- lowing conditions.
Page 146 WARNING Finding a parking space The system does not exempt the driver from his/her responsibility for park- ■ ing in and manoeuvring out of the parking space. External sound sources can have a detrimental effect on parking in and ma- ■...
Page 147 › If the driver changes the parking mode while searching for a parking space, the As soon as the following message is shown in the display:  Steer. interv. symbol button  must be pressed again. Check area around veh.!, let go of the steering wheel. The steering will be tak- en over by the system.
Page 148: Information Messages
Automatic braking for preventing cancellations caused by excessive speeds Manoeuvring out of a parallel parking space To prevent the speed from exceeding 7 km/h and to subsequently prevent can- cellation of the parking procedure, automatic brake support is initiated. The park- ...
Page 149: Cruise Control System
The parking procedure was ended because TCS was deactivated during the park- Cruise Control System ing procedure. Trailer: Park Assist stopped.   Introduction The parking procedure cannot be carried out because a trailer is hitched. This chapter contains information on the following subjects: Time limit exceeded.
Page 150 The Cruise Control System may automatically switch off when some brake as- ■ Changing the stored speed sist systems (e.g. ESC) intervene, when the speed exceeds maximum permissible engine speed, or a similar event takes place.  First read and observe the introductory information and safety warn- The Cruise Control System also remains activated after shifting the gear! ■...
Page 151: Adaptive Cruise Control (Acc)
Briefly push the rocker button into the RES/+ position in order to resume the Stop/resume control stored speed after the clutch or brake pedal is released. Set/change the desired speed  Set time interval level Special driving conditions Information on the display Information messages Adaptive cruise control (From here on referred to only as ACC) can maintain the set speed or the proximity to the vehicle ahead consistently, without the need to...
Page 152 WARNING (Continued) Radar sensor If the ACC does not decelerate fast enough, immediately apply the vehicle's ■ footbrake. Fig. 135 Control may only be resumed if the stored speed is not too high for the cur- ■ Mounting location of the radar rent traffic conditions.
Page 153 WARNING Operation If you suspect that the sensor is damaged, deactivate the ACC. Have the ■ sensor checked by a specialist garage. The sensor can become misaligned by collisions or by damage to the front of ■ the vehicle, the wheel arch or the underside of the vehicle. This can lead to an impairment of the ACC function - risk of accidents! If this is the case, have the sensor checked by a specialist garage.
Page 154 Explanation of graphic » Fig. 137 Operation Overview Control deactivated (vehicle detected). Control activated (no vehicle detected). Fig. 138 Control deactivated (no speed stored). Operating lever Control activated (vehicle detected). The ACC can consistently maintain the set speed of 30-160 km/h, as well as the proximity to the vehicle ahead ranging from a very small to a very large time inter- val.
Page 155 Start control Stop/resume control   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 148. ings on page 148. Basic requirements for start of control Stop control ›...
Page 156 Change speed by adopting the current speed) - Requirements Special driving conditions ACC is enabled.  The vehicle is moving at a speed other than that which is stored.  Note If during control the speed is increased by pressing the accelerator, control is ■...
Page 157: Area Monitoring System (Front Assist)
Narrow vehicles or vehicles travelling side by side Information messages Narrow vehicles or vehicles travelling side by side are not detected by the radar sensor until they are within the sensor's range » Fig. 139 - . This is especially ...
Page 158 The area monitoring system (From here on only referred to as Front Assist) warns WARNING (Continued) you of the danger of a collision with an obstacle in front of the vehicle and tries to When the vehicle is on a rolling test bench. avoid a collision or mitigate its consequences by automatically applying the ■...
Page 159 The sensor function may be impaired in the events of one of the following. CAUTION › The sensor is covered by mud, snow or debris, for example. › The sensor or its immediate surroundings are covered by other objects, for ex- Remove the snow with a brush and the ice with a solvent-free de-icer.
Page 160 Advance warning Activating/deactivating If Front Assist detects a risk of collision with a vehicle ahead, a symbol appears in the display of the instrument cluster and an acoustic signal is heard » Fig. 142 - .  First read and observe the introductory information and safety warn- At the same time, the braking system is prepared for possible emergency braking.
Page 161: Start-Stop
The emergency brake function is automatically activated or deactivated together START-STOP with the Front Assist system. If the emergency brake function triggers an automatic brake action, the display of  Introduction the instrument cluster shows the symbol » Fig. 142 on page 156 - .
Page 162: Start-Stop
Automatic engine shut down (STOP phase) takes place. A check warning icon ap- Note pears in the display  » Fig. 143. If the driver's seat belt is removed for more than approx. 30 seconds or the driv- › ■ Depress the clutch pedal.
Page 163: Manually Activating/Deactivating The System
› The windscreen heater is switched on. Operating conditions of the system › The intensive windscreen heater (Climatronic) or windscreen heater/ventilation is switched on with the maximum air temperature setting (manual air condition- ing system). Fig. 144 › The brake pedal was pressed several times (the pressure in the braking system Instrument cluster display: En- is too low).
Page 164: Driving Mode
Normal Mode Sportmode Ecomode Individualmode Fig. 146 Button for selecting the driving mode: Octavia, Octavia Combi / Fa- bia RS Octavia RS Selecting the driving mode allows you to adjust a range of different driving pa- rameters for the vehicle.
Page 165 Normal.  Adaptive headlights (AHL) The headlights adapt to the driving style more dynamically than in mode Normal » page Applies to Octavia RS, Octavia RS. Driving...
Page 166: Proactive Passenger Protection
Note Function The Eco driving mode is not available when towing a trailer. When the vehicle is  ■ First read and observe the introductory information and safety warn- connected electrically to a trailer and is in the Eco driving mode, the Normal driv- ings on page 163.
Page 167: Lane Assist
WARNING (Continued) Lane Assist The camera is blinded by the sun. ■ The camera is blinded by the oncoming traffic.  ■ Introduction The viewing range of the camera is impeded by a vehicle traveling ahead. ■ The camera viewing range is obstructed by an obstacle. ■...
Page 168: Lane Assist
If the turn signal is switched on prior to driving over the boundary line (e.g. when Explanation of situations making a turn), no steering intervention takes place when the vehicle approaches the boundary line. The system regards the situation as an intended lane change. The system can intervene when the following basic conditions are present.
Page 169: Traffic Sign Recognition
Warning lights in the instrument cluster WARNING Illuminates Description Traffic sign detection only operates as a support. Real traffic signs always ■  have priority over electronic displays. The driver is always responsible for cor- The system is active, but not ready to intervene. rectly assessing the traffic situation.
Page 170: Traffic Sign Recognition
The system works on the basis of the data captured by the camera and is only Driving data ■ able to show traffic signs which are in the camera's “viewing range” » Fig. 150. Traffic sign ■ Data from the camera can be supplemented by information from the Infotainment Additional display Navigation.
Page 171: Fatigue Detection (Break Recommendation)
Infotainment Navigation is not currently providing any data. Check whether the If the system detects deviations from normal steering behaviour due to possible maps are up-to-date or the whether the vehicle is currently in a location for which fatigue of the driver, it recommends to take a break from driving. no navigation data are available.
Page 172: Towing A Trailer
If the trailer that is to be towed has a 7-pin connec- 13-pin power socket tor, you can use a suitable adapter from ŠKODA Original Accessories. Safety eye Maximum Trailer drawbar load weight is 75 kg, or 80 kg for the Octavia Estate Mounting recess 4x4 vehicles. Dust cap...
Page 173 Setting the ready position Installing the ball rod Fig. 153 Setting the ready position/ready position Fig. 154 Insert the ball rod/lock up the lock, and put the lock cover on   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 169.
Page 174 CAUTION Removing the ball rod After removing the key, always replace the cap on the lock of the operating lev- ■ er – there is a risk of dirt getting into the lock. Keep the mounting recess of the towing device clean at all times. Such dirt pre- ■...
Page 175: Trailer
CAUTION Trailer If the lever is held firm and not pushed downwards as far as it can go, it will go ■  Introduction back up after the ball rod is removed and will not latch into the ready position. The ball rod then needs to be brought into this position before the next time it is installed.
Page 176: Trailer
› The engine output falls as the height increases, as does the ability to climb. Place the protective cover » Fig. 152 on page 169 onto the tow bar. Therefore, for every additional 1000 m in height (or part), the maximum permissi- Safety eye ble towed weight must be reduced by 10%.
Page 177: Trailer Stabilisation
Function requirements for trailer stabilisation. WARNING The trailer was shipped from the factory or purchased from the ŠKODA genu-  Never use the safety eye to tow a vehicle! ■ ine accessories. Adapt your speed to the conditions of the road surface and to the traffic sit- ■...
Page 178 Conditions for including a trailer in the anti-theft alarm system. The vehicle is factory-fitted with an anti-theft alarm system and a towing de-  vice. The trailer is electrically connected to the towing vehicle by means of the  trailer socket. The electrical system of the vehicle and trailer is functional.
Page 179: Safety
Safety equipment Safety  First read and observe the introductory information and safety warn- ings on page 176. Passive Safety The following list contains only part of the safety equipment in your vehicle. › Three-point seat belts for all the seats. General information ›...
Page 180: Correct Seated Position
› Secure all items of luggage » page 91, Luggage compartment. WARNING › Ensure that no objects can obstruct the pedals. › Adjust the mirrors, the front seat and head restraint to your body size. General information › Advise your passengers to adjust the head restraints to their body size. At all times, the front seats and head restraints must be adjusted to match ■...
Page 181 › Adjust the head restraint so that the top edge of the head restraint is at the WARNING same level as the upper part of your head › Correctly fasten the seat belt » page 180, Using seat belts. Information for the front passenger Maintain a distance of at least 25 cm to the dash panel.
Page 182 Examples of an incorrect seated position  First read and observe the introductory information and safety warn- ings on page 177. The maximum protection which seat belts can offer is only achieved if your seat- belts are fastened correctly. Incorrect seated positions considerably reduce the protective functions of the seat belts and therefore increase the risk of injury due to an incorrect routing of the seat belt.
Page 183: Seat Belts
Particular safety aspects must be observed when transporting children in the ve- Seat belts hicle » page 193. WARNING Using seat belts Fasten your seat belt before each journey – even when driving in town! This ■ also applies to the people seated at the rear – risk of injury! ...
Page 184: Seat Belts
WARNING The physical principle of a head-on collision Observe the following instructions for the proper use of the seat belts. Never use one seat belt to secure two people (including children). The seat- ■ belt must not be placed over a child who is sitting on the lap of another pas- senger.
Page 185  It is also important that rear seat occupants fasten their seat belts as they will First read and observe the introductory information and safety warn- otherwise be thrown through the vehicle in an uncontrolled manner in the event ings on page 180.
Page 186: Inertia Reel And Belt Pretensioners
When pulling slowly on the seat belt, the belt can move freely. When pulling Belt height adjustment on the front seats sharply on the seat belt, the movement is locked by the inertia reel. The belts also block when during full braking, when the car accelerates, when Fig.
Page 187 Note Smoke is generated when the belt tensioners are deployed. This is not an indi- ■ cation of a fire in the vehicle. When disposing of the vehicle or parts of the belt tensioner system, it is impor- ■ tant to comply with national legal requirements. ŠKODA service partners are fa- miliar with these regulations and will be able to provide you with detailed infor- mation.
Page 188: Airbag System
System description Airbag system  First read and observe the introductory information and safety warn- ings on page 185. Description of the airbag system The functional status of the airbag system is indicated by the indicator light   the instrument cluster »...
Page 189: Airbag Overview
In certain accident situations, the several airbags may be deployed simultaneous- Airbag overview The airbags are not deployed in the case of minor frontal and side collisions, rear-  Introduction end collisions, tilting of the vehicle and vehicle rollover. Deployment factors This chapter contains information on the following subjects: It is not possible to generally determine which deployment conditions apply to Front airbags...
Page 190 WARNING Front airbags Correct seated position It is important that the driver and front passenger maintain a distance of at ■ least 25 cm to the steering wheel or dashboard » Fig. 165. Not maintaining this minimum distance will mean that the airbag system will not be able to properly protect you –...
Page 191 Driver’s knee airbag Side airbags Fig. 166 Driver's knee airbag below the steering column Fig. 167 Installation location of the side airbags front/rear  First read and observe the introductory information given on page 186. Fig. 168 Inflated side airbags The driver's knee airbag offers adequate protection for the driver's legs.
Page 192 The load of the occupants is cushioned when plunging into the fully inflated air- WARNING bag and the risk of injury to the entire upper body (chest, stomach and pelvis) is reduced on the side facing the door. Only hang light items of clothing on the hooks fitted in the vehicle. Never ■...
Page 193: Deactivating Airbags
In the event of a side collision the head airbag is deployed together with the rele- WARNING vant side airbag and the front seat belt tensioner on the side of the car on which the accident occurs. The airbag control unit operates using pressure sensors located in the front doors.
Page 194 Deactivating airbags Deactivating the front passenger airbag  First read and observe the introductory information given on page 190. Deactivating an airbag should be considered in cases such as the ones outlined below. › If using a rear-facing child seat on the front passenger seat (due to different le- gal regulations, the airbag must be deactivated if using a forward-facing child seat in some countries) »...
Page 195 WARNING The driver is responsible for whether the airbag is switched on or switched ■ off. Only switch off the airbag when the ignition is switched off! Otherwise a ■ fault can occur in the system for deactivating the airbag. If the warning light is flashing, the front passenger airbag will not be ■...
Page 196: Transporting Children Safely
WARNING (Continued) Transporting children safely Children are exposed to an increased risk of injury in the event of an acci- ■ dent if they lean forward or adopt an incorrect seated position when the vehi- Child seat cle is moving. This particularly applies to children who are transported on the front passenger seat as they can suffer severe, or even fatal injuries if the air- bag system is deployed! ...
Page 197: Child Seat
› If possible, move the front passenger seat backwards so that there is no con- Use of a child seat on the front passenger seat tact between the front passenger seat and the child seat behind it. › With child safety seats in groups 2 or 3, make sure that the loop-around fittings Never use a rearward-facing child restraint system on a seat which is protected attached to the child seat headrest is positioned in front of or at the same by an active airbag installed in front of it.
Page 198 Group Weight of the child Approximate age Child safety and side airbag up to 10 kg up to 9 months up to 13 kg up to 18 months 9-18 kg up to 4 years 15-25 kg up to 7 years 22-36 kg over 7 years ...
Page 199: Fastening Elements
 First read and observe the introductory information given on page 196. Fastening elements There are two locking eyes between the seat backrest and the seat cushion of  Introduction the outer rear seats and front passenger seat for fixing the ISOFIXsystem child seat in place »...
Page 200 Size class of Group Front passenger seat Rear seats outside Rear seat middle the child seat IL-SU 9-18 kg The size category is shown on the label attached to the child seat. If the front passenger seat is fitted with fixing eyes for the ISOFIX system, this suits installation of an ISOFIX child seat with the “Semi-Universal” approval. IL-SU The seat is suited for installation of an ISOFIX child seat with the “Semi- WARNING...
Page 201: General Maintenance
› Predominantly stop-and-go traffic as is often the case in city driving, for exam- General Maintenance ple; › Operation predominantly during winter. A service consultant at the specialist garage will tell you whether the operating Vehicle care conditions of your vehicle may make it necessary for service work to be carried out between the normal service intervals.
Page 202 In order to operate a vehicle with a variable service interval, it must only be fil- Note led and topped up with the prescribed engine oil. For diesel operation with a high sulphur content, the oil must be changed every If this engine oil is not available, the oil change is subject to a fixed service inter- 7500 km.
Page 203: Service Work, Adjustments And Technical Alterations
ŠKODA Service Partners feature modern, specially developed tools and equip- WARNING ment. Here, trained specialists have a comprehensive range of ŠKODA Genuine Parts and ŠKODA Genuine Accessories at their disposal. If work on your vehicle is not carried out properly, this can lead to operation- ■...
Page 204 ŠKODA Service Partners are therefore properly prepared to service your vehicle Tests required by law and to provide quality work. We therefore advise you to have all modifications, re- pairs and technical alterations to your vehicle carried out by a ŠKODA Service ...
Page 205 ŠKODA Genuine Accessories Spoiler   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 200. ings on page 200. If you wish to fit accessories to your vehicle, you should remember the following: If your new vehicle is fitted with a spoiler on the front bumper in combination with the spoiler on the luggage compartment lid, the following instructions must We recommend that you use ŠKODA Genuine Accessories in your vehicle.
Page 206: Washing Your Car
WARNING Airbags The airbag control unit operates using pressure sensors located in the front  First read and observe the introductory information and safety warn- doors. For this reason, no adjustments may be carried out to the doors or door ings on page 200.
Page 207: Washing By Hand
The longer insect residues, bird droppings, tree sap, road and industrial dust, tar, CAUTION soot particles, road salt and other aggressive deposits remain adhering to the paintwork of your vehicle, the more detrimental their destructive effect can be. When washing the car by hand, protect your hands and arms from sharp-edged ■...
Page 208: Taking Care Of Your Vehicle Exterior
We recommend using care products from ŠKODA Original Accessories that are WARNING available from ŠKODA Partners. The instructions for use on the package must be observed. Never use circular spray nozzles or dirt cutters! WARNING CAUTION Care products may be harmful to your health if not used according to the in- ■...
Page 209: Rubber Seals
Preserving the vehicle paintwork Rubber seals Thorough wax treatment is an effective way of protecting the paintwork from harmful environmental influences.  First read and observe the introductory information and safety warn- The vehicle must be treated with a high-quality hard wax polish at the latest, ings on page 205.
Page 210: Headlight Lenses
The following instructions must be followed when washing the vehicle with a When drying the windows after washing the vehicle, do not use window leathers high-pressure cleaner: that have been used to polish the bodywork. Residues of preservatives in the ›...
Page 211: Taking Care Of The Interior
CAUTION CAUTION When washing your vehicle, ensure as little water as possible gets into the lock- Severe layers of dirt on the wheels can also result in wheel imbalance. This may ing cylinders. show itself in the form of a wheel vibration which is transmitted to the steering ...
Page 212: Natural Leather
Regular and proper care helps to ensure efficiency and to maintain the value of Note your vehicle. Due to the special tools and knowledge required, and to avoid any potential prob- We recommend using vehicle care products from ŠKODA Original Accessories. lems with the cleaning and care of the interior of your vehicle, we recommend These are available from ŠKODA Partners.
Page 213 ® Sharp-edged objects on items of clothing such as zip fasteners, rivets, sharp- Alcantara ■ edged belts, jewellery and pendants may leave permanent scratches or signs of Dust and fine dirt particles in pores, creases and seams may chafe and damage rubbing on the surface.
Page 214 CAUTION Regularly remove dust from the seat covers using a vacuum cleaner. ■ Electrically heated seats must not be dried after cleaning by switching on the ■ heater. Do not sit on wet seats - risk of seat deformation. ■ Always clean the seats from “seam to seam”.
Page 215: Inspecting And Replenishing
Refuelling Inspecting and replenishing Fuel  Introduction This chapter contains information on the following subjects: Refuelling Unleaded petrol Diesel fuel Fig. 178 Open fuel filler flap/fuel filler flap with cap unscrewed The correct grades of fuel for your vehicle are stated on a sticker affixed to the inside of the fuel filler flap »...
Page 216 › Place the filler cap onto the fuel filler neck and turn it clockwise until it securely Required fuel - unleaded petrol 95/91 or 92 or 93 RON engages. Use unleaded fuel with the octane rating 95 RON. Unleaded petrol with the oc- ›...
Page 217 CAUTION Diesel fuel If, in an emergency, the vehicle has to be refuelled with petrol of a lower octane  ■ First read and observe the introductory information and safety warn- number than the one prescribed, the journey must only be continued at medium ings on page 212.
Page 218: Engine Compartment
CAUTION WARNING Just filling the tank once with diesel fuel that does not comply with the stand- Before beginning work in the engine compartment, please read the following ■ ard, can cause severe damage to parts of the engine, the fuel and exhaust sys- advice.
Page 219: Engine Compartment
WARNING For the sake of the environment The following warning instructions must be followed at all times when work- In view of the requirements for the environmentally friendly disposal of fluids and ing in the engine compartment while the engine is running. the special tools and knowledge required for such work, we recommend that flu- Pay particular attention to moving engine parts (e.g.
Page 220 › Press the release lever in the direction of the arrow and the bonnet is un- Opening and closing the bonnet locked. › Grab hold of the bonnet and lift. › Take the bonnet support out of its holder » Fig. 181 in the direction of the arrow and secure the opened bonnet by inserting the end of the support into the opening...
Page 221 WARNING Engine compartment overview After switching off the ignition, the fan can intermittently continue to operate for approx. 10 minutes.  Windscreen washer system Fig. 183 Engine compartment: Wind- screen washer fluid reservoir Fig. 182 Principle sketch: Engine compartment  First read and observe the introductory information and safety warn- ...
Page 222: Engine Oil
CAUTION WARNING Under no circumstances must radiator antifreeze or other additives be added to The engine compartment of your car is a hazardous area. The following ■ ■ the windscreen washer fluid. warning instructions must be followed at all times when working in the en- If the vehicle is fitted with a headlight cleaning system, only cleaning products gine compartment »...
Page 223: Engine Oil
Specifications and capacity (in l) for vehicles with fixed service intervals Checking the oil level Ensure that the vehicle is positioned on a level surface and the engine has Petrol engines Specification Filling level reached its operating temperature. 1.2 l/63, 77 kW TSI ›...
Page 224: Coolant
If a higher concentration of antifreeze is required for climatic reasons, the amount Replenishing of coolant additive can only be increased up to a maximum of 60 % (antifreeze protection down to approx. -40 °C).  First read and observe the introductory information and safety warn- ings on page 219.
Page 225: Coolant
› Check the coolant level in the coolant expansion tank » Fig. 185. Capacity Coolant level above mark  First read and observe the introductory information and safety warn- No coolant must be refilled. ings on page 221. The level may also rise slightly above the marking when the engine is warm.
Page 226: Brake Fluid
Do not use an alternative additive if the specified coolant is not available in an Checking the brake fluid level emergency. In this case, use just water and have the correct mixing ratio of water and coolant additive restored by a specialist garage as soon as possible. ...
Page 227: Vehicle Battery
The brake fluid must comply with the following standards or specifications: WARNING › VW 50114; › FMVSS 116 DOT4. There is a risk of injuries, poisoning, chemical burns, explosions or fire when  carrying out any work on the battery and on the electrical system. The general applicable safety rules and the following warnings must be observed without Vehicle battery exception.
Page 228: Vehicle Battery
WARNING For the sake of the environment When you charge a battery, hydrogen is released, and a highly explosive gas A vehicle battery that has been removed is a special type of hazardous waste. ■ mixture is also produced. An explosion can be caused through sparkling over These must be disposed of in accordance with national legal regulations.
Page 229: Checking The Battery Electrolyte Level
CAUTION Checking the battery electrolyte level For technical reasons, on vehicles with the description “AGM”, the electrolyte lev- Fig. 188 el cannot be checked. Vehicle battery: Electrolyte level indicator Note The battery acid level is also checked regularly by a specialist garage as part of the inspection service.
Page 230: Automatic Load Deactivation
Operation Operating measure WARNING Electrical power window (operational faults) » page 49 “Quick-charging” the vehicle battery is dangerous and requires a special » Operating instructions for Info- charger and specialist knowledge. Enter the radio/navigation system code num- tainment Radio or »...
Page 231: Wheels
WARNING (Continued) Wheels Unusual vibrations or pulling of the vehicle to one side could be a sign of ■ tyre damage. If there is any doubt that a wheel is damaged, immediately re- Tyres and wheel rims duce your speed and stop! If no external damage is evident, drive slowly and carefully to the nearest specialist garage to have the vehicle checked.
Page 232: Wheels
WARNING (Continued) Service life of tyres The prescribed tightening torque of the wheel bolts for steel and light alloy ■ wheels is 120 Nm. If the wheel bolts are tightened to a too low tightening torque, the rim can ■ come loose when the car is moving –...
Page 233: Tyres And Wheel Rims
Always check the inflation pressure when the tyres are cold. Do not reduce the Tyre age higher pressure of warm tyres. Tyres age losing their original characteristics, even if they are not used. There- fore, we recommend not to use summer or winter tyres that are older than With greater payload, adjust the tyre inflation pressure accordingly.
Page 234: Unidirectional Tyres
690 kg Tyre control display 730 kg 775 kg Fig. 191 Speed symbol Button for setting the tyre infla- tion pressure control value This indicates the maximum permissible vehicle speed with mounted tyres for the respective category. 130 km/h 160 km/h 170 km/h 180 km/h 190 km/h...
Page 235 ›  The wheels of one axle are loaded more heavily (e.g. when towing a trailer or First read and observe the introductory information and safety warn- when driving uphill or downhill). ings on page 228. › Snow chains are mounted. ›...
Page 236 WARNING Wheel bolts Never use the temporary spare wheel if it is damaged. ■ If the dimensions or design of the temporary spare wheel differ from the fit- Fig. 193 ■ ted tyres, never drive faster than 80 km/h (or 50 mph). Remove the cap Avoid accelerating at full throttle, sharp braking and fast cornering.
Page 237: Winter Operation
Winter operation Snow chains  First read and observe the introductory information given on page 234.  Introduction This chapter contains information on the following subjects: When driving on wintry roads, snow chains improve not only traction, but also the braking performance.
Page 238: Do-It-Yourself
Emergency equipment, and self-help Emergency equipment  Introduction Fig. 195 Placing of the warning triangle: Octavia/Octavia Estate This chapter contains information on the following subjects:  First read and observe the introductory information given on page 235. First aid kit and warning triangle...
Page 239: Fire Extinguisher
Fire extinguisher Vehicle tool kit Fig. 196 Fire extinguisher  First read and observe the introductory information given on page 235. The fire extinguisher is attached by two straps in a holder underneath the driver's Fig. 197 Vehicle tool kit seat.
Page 240: Changing A Wheel
WARNING WARNING The factory-supplied lifting jack is only intended for your model of vehicle. Observe the following instructions for lifting the vehicle. ■ Under no circumstances attempt to lift heavier vehicles or other loads – risk of If the wheel has to be changed on a slope, first of all block the opposite ■...
Page 241: Changing A Wheel
› Have all of the occupants get out of the vehicle. While changing a tyre, the oc- Follow-up tasks cupants of the vehicle should not stand on the road (they should instead remain behind a crash barrier).  First read and observe the introductory information and safety warn- ›...
Page 242 Loosening/tightening wheel bolts Raising the vehicle Fig. 198 Fig. 199 Changing a wheel: Loosening Jacking points for positioning the wheel bolts lifting jack  First read and observe the introductory information and safety warn- ings on page 237. Release › Push the wheel wrench onto the wheel bolt to the stop ›...
Page 243: Tyre Repair
› Continue turning up the jack until the wheel is just about lifted off the ground. Note WARNING Make a note of the code number hammered into the rear side of the adapter or ■ the rear side of the anti-theft wheel bolt. This number can be used to purchase a Only raise the vehicle at the attachment points.
Page 244: Breakdown Kit
 First read and observe the introductory information and safety warn- WARNING ings on page 240. A tyre filled with sealant has the same driving characteristics as a standard ■ The kit is located in a box under the floor covering in the luggage compartment. tyre.
Page 245: Sealing And Inflating The Tyre
› › Check that you can carry out the repairs with the breakdown kit » page 240. Firmly screw the tyre inflation hose back onto the tyre valve and repeat the › Uncouple any trailers. inflation process. › › Remove the breakdown kit from the luggage compartment. If you cannot reach the required tyre inflation pressure here either, this means ›...
Page 246: Jump-Starting
› Continue driving carefully to the nearest specialist garage at a maximum speed CAUTION of 80 km/h (50 mph).  There must not be any contact between the two vehicles otherwise current ■ may flow as soon as the negative terminals are connected. Jump-starting The discharged battery must be properly connected to the system of the vehi- ■...
Page 247: Jump-Starting
Both batteries must have a rated voltage of 12 V. The capacity (Ah) of the battery Vehicles with manual transmission may be towed in with a tow bar or a tow rope supplying the power must not be significantly less than the capacity of the dis- or with the front or rear wheels raised.
Page 248 244. Removing/installing the cap › Press on the cover in area » Fig. 206 (for vehicles Octavia RS, Octavia Estate Removing/installing the cap › RS on the right edge of the cap press). Press on the cap in the area »...
Page 249: Remote Control
The detachable ball rod must always be in the vehicle so that it can be used for › Press on the lower side of the cap (for vehicles Octavia RS, Octavia RS on the towing, if necessary. ...
Page 250: Remote Control
Replacing the battery in the remote control key Synchronising the remote control  First read and observe the introductory information and safety warn- ings on page 246. If the vehicle does not unlock when pressing the remote control, the key may not be synchronised.
Page 251: Emergency Unlocking/Locking
Emergency unlocking/locking Locking a door  Introduction Fig. 210 Left rear door: Emergency lock- This chapter contains information on the following subjects: Unlocking/locking the driver's door Locking a door Unlocking the tailgate Selector lever-emergency unlocking  Unlocking/locking the driver's door ...
Page 252: Replacing Windscreen Wiper Blades
Unlocking the tailgate Selector lever-emergency unlocking Fig. 211 Emergency unlocking: Octavia/Octavia Estate Fig. 212 Selector lever-emergency unlocking   First read and observe the introductory information given on page 248. First read and observe the introductory information given on page 248.
Page 253 Replacing the windscreen wiper blades Replacing the rear window wiper blade Fig. 213 Fig. 214 Windscreen wiper blade Rear window wiper blade   First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 249.
Page 254: Fuses And Light Bulbs
WARNING Fuses and light bulbs Always read and observe the warnings before completing any work in the en- gine compartment » page 215. Fuses CAUTION  Introduction “Never repair” fuses, and do not replace them with fuses of a higher amperage – ■...
Page 255 Fuses in the dash panel – LHD Fuses in the dash panel – RHD Fig. 215 Storage compartment on the driver's side: LHD  First read and observe the introductory information and safety warn- Fig. 216 Storage compartment on the front passenger's side: RHD ings on page 251.
Page 256 Power consumer Assignment of the fuses in the dash panel Not assigned KESSY control unit Fig. 217 Steering wheel module Schematic representation of the fuse box Not assigned Luggage compartment door opening Light - right Panorama roof Control unit for central locking front door right, power windows - left Heated front seats ...
Page 257  First read and observe the introductory information and safety warn- Power consumer ings on page 251. Control unit for control of seat adjustment 230-Volt power socket Replacing fuses › Press together the interlocks of the cover simultaneously in the direction of the Rear window wiper arrow »...
Page 258: Bulbs
Rear light (Octavia Estate) ist garage.  Replacing bulbs in rear light (Octavia Estate) Some manual skills are required to change a bulb. For this reason, we recommend having bulbs replaced by a specialist garage or seeking other expert help in the event of any uncertainties.
Page 259: Bulbs
Bulb arrangement in the headlights Replacing the low beam bulb Fig. 222 Headlight with halogen bulb: Bulb for low beam  First read and observe the introductory information and safety warn- Fig. 220 Principle sketch: Headlight with halogen bulb/with Xenon bulb ings on page 255.
Page 260 › Turn the bulb holder » Fig. 223 as far as it goes in the direction of the arrow Change bulb for additional parking light and remove it. › Replace the bulb, insert the bulb holder with the new bulb and turn in the oppo- site direction to that of the arrow as far as it goes.
Page 261 › Insert the bulb holder with the new bulb into the headlight and turn clockwise Replacing the bulb for the fog lights as far as the stop. › Attach the connector. › Replace the fog lamp by inserting it in the opposite direction of the arrow »...
Page 262: Rear Light (Octavia)
› Carefully remove the connector from the tail lamp assembly in the direction of Rear light (Octavia) the arrow Installing › Insert the connector into the lamp and lock it securely. › Insert the lamp into the mounts in the body »...
Page 263 Inner part of the light Replacing bulbs in rear light (Octavia) › Unscrew the lamp holder » Fig. 231 -  or  use the screwdriver from the car tool kit, and remove the lamp holder from the tail light assembly.
Page 264: Rear Light (Octavia Estate)
› Carefully remove the connector from the tail lamp assembly in the direction of Rear light (Octavia Estate) the arrow Installing › Insert the connector into the lamp and lock it securely. › Insert the lamp into the mounts in the body »...
Page 265 Replacing bulbs in rear light (Octavia Estate) Fig. 235 Outer part of the light: Basic light/light with LED diodes  First read and observe the introductory information and safety warn- ings on page 255. Outer part of the lamp ›...
Page 266: Technical Data
 First read and observe the introductory information given on page 263. Technical data Vehicle data sticker The vehicle data sticker » Fig. 236 -  is located underneath the floor covering in Technical data the boot. The vehicle data sticker contains the following data: Vehicle data Vehicle identification number (VIN) Vehicle type...
Page 267: Technical Data
Roof load including roof rack system › Equipment not included in the operating weight › Trailer hook weight when towing (up to 75 kg and 80 kg for the Octavia Combi 4x4 vehicles). Fuel consumption and CO emissions according to ECE regulations and EU directives The measurement of the intra-urban cycle begins with a cold start of the engine.
Page 268 1.2 ltr./63 kW TSI 1.2 ltr./77 kW TSI 1.4 ltr./103 kW TSI 1.8 ltr./132 kW TSI 2.0 ltr./162 kW TSI 15" 1549/1520 1549/1520 1543/1512 16" 1543/1514 (1541/1510) 17" 1535/1506 Does not apply to Octavia Estate 4x4 vehicles.  Technical data...
Page 269 1.6 ltr./77 kW TDI 1.6 ltr./81 kW TDI 2.0 ltr./105 kW TDI 2.0 ltr./110 kW TDI 2.0 ltr./135 kW TDI 1549/1520 15" 1549/1520 1549/1520 (1539/1508) 1543/1514 16" 1543/1514 (1541/1510) 17" 1535/1506  Does not apply to Octavia Estate 4x4 vehicles. Technical data...
Page 270 Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders / displacement (cm 63/4300-5300 160/1400-3500 4/1197 Driving performances OCTAVIA MG5 OCTAVIA Estate MG5 Top speed (km/h) Acceleration 0-100 km/h (s) 12.0 12.2 Permissible trailer load, braked (kg) 1100 / 1300...
Page 271 Max. torque (Nm per rpm) Number of cylinders/displacement (cm 103/4500-6000 250/1500-3500 4/1395 Driving performances OCTAVIA MG6 OCTAVIA DSG7 OCTAVIA Estate MG6 OCTAVIA Estate DSG7 Top speed (km/h) Acceleration 0-100 km/h (s) Permissible trailer load, braked (kg) 1500 / 1800 Permissible trailer load, unbraked (kg)
Page 272 Number of cylinders/displacement (cm 162/4500-6200 350/1500-4400 4/1984 Driving performances OCTAVIA RS MG6 OCTAVIA RS DSG6 OCTAVIA Estate RS MG6 OCTAVIA Estate RS DSG6 Top speed (km/h) Acceleration 0-100 km/h (s) Permissible trailer load, braked (kg) 1600 / 1800 Permissible trailer load, unbraked (kg) Applies to vehicles with a Green-tec package.
Page 273 Max. torque (Nm per rpm) Number of cylinders/displacement (cm 81/3250-4000 250/1500-3000 4/1598 Driving performances OCTAVIA MG6 OCTAVIA Estate MG6 Top speed (km/h) Acceleration 0-100 km/h (s) 10.6 10.7 2.0 ltr./105 kW TDI engine Output (kW per rpm) Max. torque (Nm per rpm)
Page 274 Number of cylinders/displacement (cm 135/3500-4000 380/1750-3000 4/1968 Driving performances OCTAVIA RS MG6 OCTAVIA RS DSG6 OCTAVIA Estate RS MG6 OCTAVIA Estate RS DSG6 Top speed (km/h) Acceleration 0-100 km/h (s) Permissible trailer load, braked (kg) 1600 / 1800 Permissible trailer load, unbraked (kg) Applies to vehicles with a Green-tec package.
Page 275 Assist systems Index Airbag Adaptive cruise control Deactivating Deactivating the front passenger airbag Cruise Control System Deployment Driving mode Front airbag Abroad Head airbag Driving abroad Knee airbag Unleaded petrol 18, 137 Modifications and damage to the airbag system 203 Side airbag Function Headlight assist...
Page 276 Avoiding damage to the vehicle Brake fluid Oil level Driving through water Handbrake Windscreen washer fluid Running in Avoiding damage to your vehicle Children and safety Braking Child safety Information on braking Side airbag Breakdown kit Child safety lock Ball head Break recommendation Child safety seat Check fitting...
Page 277 Operation in winter Convenience consumers Diesel particulate filter Economical driving information messages Convenience operation Ballast sliding / tilting roof (Octavia Estate) Digital Clock Driving at full throttle sliding / tilting roof (Octavia) Time Idling Coolant Dipstick Looking ahead...
Page 278 Force limit Brake fluid Glasses storage box Power windows Coolant Glow plug system Force limiter Overview Warning light electric luggage compartment lid (Octavia Estate) 44 Vehicle battery sliding/tilting roof (Octavia Estate) Engine oil sliding/tilting roof (Octavia) Capacity Front airbag Changing Handbrake...
Page 279 Inertia reel Replacing bulbs Information message Tourist light see KESSY KESSY Light bulbs Information system Information message Rear light (Octavia Estate) Compass point display lock Rear light (Octavia) Door warning Lock / unlock the steering lighting Eco tips Starting the engine...
Page 280 Luggage net Engine compartment Modes of the automatic transmission Multifunction box (Octavia Estate) Warning icons Modifications Roll-up luggage compartment cover (Octavia Es- Warning lights tate) Modifications and technical alterations Storage compartments under the floor covering Airbags Stowing roll-up luggage compartment cover...
Page 281 Park assist Practical Features Bulb in rear light (Octavia Estate) Finding a parking space Storage compartment in the front center console Bulbs Information messages - not lockable Bulbs in rear light (Octavia) Parking Fuses ProActive passenger protection Fuses – engine compartment...
Page 282 Inertia reels Sliding/tilting roof Seat belts Stop watch Closing the sun screen (Octavia Estate) The physical principle of a head-on collision Storage compartment in rear centre console Closing (Octavia Estate) Seat features Storage compartment on the passenger side...
Page 283 Cleaning the wheels Traffic signs Unlocking Decorative films see Traffic sign recognition Individual settings Door lock cylinders KESSY Trailer 169, 172 Headlight lenses 13-pin power socket High-pressure cleaner Remote control driving with a trailer Plastic parts Vehicle key loading Polishing the paintwork Safety eye Unlocking and locking Rubber seals...
Page 284 Safety instructions Chrome parts Windscreen washer fluid Warning icon High-pressure cleaner Checking Replenishing Vehicle care Waste container Warning icon Alcantara Water Winter Artificial leather Driving through Cloths Windscreen washers Water in the fuel filter Windscreen washers Vehicle condition indicator symbol see Auto-check control Windscreen washer system warning messages...
Page 285 ŠKODA AUTO a.s. pursues a policy of constant product and model development. Reprinting, duplicating, translating and any other use, either in whole or in part, is We trust that you will understand that changes to models in terms of shape, not permitted without the written consent of ŠKODA AUTO a.s..
Page 287 Also please pay attention to those parts in the Owner's Manual that are marked  below. Work with us – for the sake of the environment. Návod k obsluze Octavia anglicky 11.2013 S65.5610.10.20 5E0 012 720 AD...

Skoda Octavia Owner's Manual

Table of Contents

Materials Defect Liability and ŠKODA Warranty for New Cars

Mobility Warranty and ŠKODA Extended Warranty

Abbreviations

Using the System

Cockpit

Instruments and Warning Lights

First Read and Observe the Introductory Information and Safety Warn

Display

Warning Lights

Unlocking and Opening

Malfunctions

›

›

Unlocking and Opening

Lights and Visibility

Interior Lights

First Read and Observe the Introductory Information and Safety Warn

›



Practical Equipment

 Introduction

Variable Loading Floor in the Luggage Compartment (Estate)  Introduction

Heating and Air-Conditioning

Starting-Off and Driving

Driving

Assist Systems

Towing a Trailer

Passive Safety

Safety

Seat Belts

Airbag System

Transporting Children Safely

Vehicle Care

General Maintenance

Inspecting and Replenishing

Wheels

Do-It-Yourself



Quick Links

Chapters

Related Manuals for Skoda Octavia

Summary of Contents for Skoda Octavia
