4C-8 Rear Brakes:

Tightening Torque Specifications

Fastening part
Rear brake pad mounting pin
Rear brake pad mounting pin plug
Rear brake caliper sliding pin A
Brake hose union bolt
Rear caliper sliding pin B
Brake disc bolt (Rear)
NOTE
The specified tightening torque is described in the following.
"Rear Brake Components" (Page 4C-1)
Reference:
For the tightening torque of fastener not specified in this section, refer to "Tightening Torque List" in Section 0C
(Page 0C-9).

Recommended Service Material

Material
Brake fluid
Grease
Thread lock cement
NOTE
Required service material is also described in the following.
"Rear Brake Components" (Page 4C-1)

Special Tool

09900–20205
Micrometer (0 – 25 mm)
(Page 4C-7)
09900–20701
Dial gauge chuck
(Page 4C-7)
email: info@motomatrix.co.uk / www.motomatrix.co.uk

Special Tools and Equipment

SUZUKI recommended product or Specification
DOT 4
SUZUKI SILICONE GREASE or
equivalent
THREAD LOCK CEMENT SUPER
"1322" or equivalent
THREAD LOCK CEMENT SUPER
"1360" or equivalent
Tightening torque
N⋅m kgf-m
17 1.7
2.5 0.25
27 2.7
23 2.3
12 1.2
35 3.5
—
P/No.: 99000–25100
P/No.: 99000–32110
P/No.: 99000–32130
09900–20607
Dial gauge
(Page 4C-7)
B947H14307002
Note
lbf-ft
12.5 (Page 4C-3)
2.0 (Page 4C-3)
19.5 (Page 4C-4)
16.5 (Page 4C-4)
8.5 (Page 4C-5)
25.5 (Page 4C-7)
B947H14308001
Note
(Page 4C-5) / (Page 4C-
5)
(Page 4C-3) / (Page 4C-
5)
(Page 4C-5)
(Page 4C-7)
B947H14308002
