Appendix A: Software Specifications; Software Features - Samsung iES4028F Management Manual

Appendix A: Software Specifications

Software Features

Management Authentication
Local, RADIUS, TACACS, Port Authentication (802.1X), MAC Authentication,
Web Authentication, HTTPS, SSH
General Security Measures
Access Control Lists (IP, MAC - 100 rules), Port Authentication (802.1X), Port
Security, DHCP Snooping (with Option 82 relay information), IP Source Guard
Power over Ethernet
DHCP Client
Port Configuration
1000BASE-T: 10/100 Mbps at half/full duplex, 1000 Mbps at full duplex (RJ-45)
1000BASE-SX/LX/LH - 1000 Mbps at full duplex
Flow Control
Full Duplex: IEEE 802.3-2005
Half Duplex: Back pressure
Broadcast Storm Control
Traffic throttled above a critical threshold
Port Mirroring
Multiple source ports, one destination port
Rate Limits
Input limit
Output limit
Port Trunking
Static trunks (Cisco EtherChannel compliant)
Dynamic trunks (Link Aggregation Control Protocol)
Spanning Tree Algorithm
Spanning Tree Protocol (STP, IEEE 802.1D)
Rapid Spanning Tree Protocol (RSTP, IEEE 802.1w)
Multiple Spanning Tree Protocol (MSTP, IEEE 802.1s)
VLAN Support
Up to 255 groups; port-based protocol-based, or tagged (802.1Q),
GVRP for automatic VLAN learning, private VLANs, voice VLANs, QinQ tunnel
Class of Service
Supports 4 levels of priority
Strict or Weighted Round Robin queueing
CoS configured by port or VLAN tag
Layer 3/4 priority mapping: IP DSCP
30. Supported duplex modes depend on the specific transceiver.
30
(SFP)
A-1
