CONTROL COMMAND
Controlling the radio with CI-V (Continued)
■

D Command table

Cmd. Sub cmd. Data
00 — —
01 00 —
01 —
02 —
03 —
04 —
07 —
08 —
02 — —
03 — —
04 — —
05 — —
06 00 —
01 —
02 —
03 —
04 —
07 —
08 —
07 — —
00 —
01 —
A0 —
B0 —
08 — —
0001− —
0201*
09 — —
0A — —
0B — —
0E 00 —
01 —
02 —
22 —
D0 —
D3 —
0F 00 —
01 —
10 00 —
01 —
02 —
03 —
04 —
05 —
11 — 0
20
13 00 —
01 —
02 —
Description
Send frequency data.
(for transceive operation)
Select LSB mode
(for transceive operation)
Select USB mode
(for transceive operation)
Select AM mode
(for transceive operation)
Select CW mode
(for transceive operation)
Select RTTY mode
(for transceive operation)
Select CW-R mode
(for transceive operation)
Select RTTY-R mode
(for transceive operation)
Read band edge frequencies
Read operating frequency
Read operating mode
Set operating frequency
Select LSB mode
Select USB mode
Select AM mode
Select CW mode
Select RTTY mode
Select CW-R mode
Select RTTY-R mode
Select VFO mode
Select VFO A
Select VFO B
Equalize VFO A and VFO B
Exchange VFO A and VFO B
Select memory mode
Select memory channel
*P1=0200, P2=0201
Memory write
Memory to VFO
Memory clear
Scan stop
Programmed/memory scan start
Programmed scan start
Memory scan start
Set scan resume OFF
Set scan resume ON
Turn the split function OFF
Turn the split function ON
Select 10 Hz (or 1 Hz) tuning steps
Select 100 Hz tuning steps
Select 1 kHz tuning step
Select 5 kHz tuning steps
Select 9 kHz tuning steps
Select 10 kHz tuning steps
Send/read attenuator OFF.
Send/read attenuator ON (20 dB).
Announce with voice synthesizer
( 00=all data 01=frequency and
S-meter; 02=receive mode)
Cmd. Sub cmd. Data
14 01 0 to 255 Send/read [AF] level setting
02 0 to 255 Send/read [RF] level setting
03 0 to 255 Send/read [SQL] level setting
06 0 to 255 Send/read NR level setting
07 0 to 255 Send/read Inside [PBT] setting (0= max.
08 0 to 255 Send/read Outside [PBT] setting
09 0 to 255 Send/read CW Tone Pitch setting
0A 0 to 255 Send/read RF power setting
0B 0 to 255 Send/read MIC gain setting
0C 0 to 255 Send/read Key speed level setting
0D 0 to 255 Send/read [MNF] setting (0=max. CCW,
0E 0 to 255 Send/read COMP level setting
0F 0 to 255 Send/read Break-IN delay setting
12 0 to 255 Send/read NB level setting
16 0 to 255 Send/read VOX gain setting
17 0 to 255 Send/read Anti VOX gain setting
15 01 —
02 —
11 —
12 —
13 —
16 02 0
1
12 0
1
2
22 0
1
40 0
1
41 0
1
44 0
1
46 0
1
47 0
1
2
48 0
1
4F 0
1
50 0
1
19 00 —
1A 00 See p. 11-6 Send/read memory contents
01 See p. 11-5 Send/read band stacking register con-
11-3
Description
(0=max. CCW to 255=max. CW)
(0=max. CCW to 255=11 o'clock)
(0=11 o'clock to 255=max. CW)
(0=0% to 255=100%)
CCW, 128=center, 255=max. CW)
( 0= max. CCW, 128=center,
255=max. CW)
(0=300 Hz to 255=900 Hz (5 Hz steps))
(0=minimum to 255=100%)
(0=0% to 255=100%)
(0=6 wpm to 255=60 wpm)
128=center, 255=max. CW)
(0=0 to 255=10)
(0=2.0 d to 255=13.0 dots)
(0=0% to 255=100%)
(0=0% to 255=100%)
(0=0% to 255=100%)
Read squelch status
Read S-meter level
Read RF power meter
Read SWR meter
Read ALC meter
Send/read Preamp OFF
Send/read Preamp ON
Send/read AGC OFF
Send/read AGC Fast
Send/read AGC Slow
Send/read Noise Blanker OFF
Send/read Noise Blanker ON
Send/read Noise Reduction OFF
Send/read Noise Reduction ON
Send/read Auto Notch function OFF
Send/read Auto Notch function ON
Send/read Speech compressor OFF
Send/read Speech compressor ON
Send/read VOX function OFF
Send/read VOX function ON
Send/read Break-IN function OFF
Send/read Semi Break-IN function ON
Send/read Full Break-IN function ON
Send/read Manual Notch function OFF
Send/read Manual Notch function ON
Send/read Twin Peak Filter OFF
Send/read Twin Peak Filter ON
Send/read Dial lock function OFF
Send/read Dial lock function ON
Read the transceiver ID
tents
