10
SET MODE
Items in the Set mode (Continued)
■
Mode Select (SSB)
Disables the selection of the SSB (LSB/USB) modes,
to simplify operation.
For example, if you are operating mobile and plan on
using only the AM mode, set all other modes (SSB,
CW, RTTY) to OFF, thereby making selection of AM
quick and easy.
on : The SSB modes are selectable.
oF : The SSB modes are disabled.
Mode Select (CW)
Disables the selection of the CW/CW-R modes, to
simplify operation.
on : The CW modes are selectable.
oF : The CW modes are disabled.
Mode Select (RTTY)
Disables the selection of the RTTY/RTTY-R modes,
to simplify operation.
on : The RTTY modes are selectable.
oF : The RTTY modes are disabled.
Mode Select (AM)
Disables the selection of the AM mode, to simplify
operation.
on : The AM mode is selectable.
oF : The AM mode is disabled.
CI-V Baud Rate
Sets the CI-V data transfer rate to 300, 1200, 4800,
9600, 19200 bps or Auto.
When Auto is selected, the baud rate is automatically
set according to the controller or remote controller.
CI-V Address
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-7200's address is 76h.
When 2 or more IC-7200s are connected to an op-
tional CT-17 CI-V LEVEL CONVERTER, rotate [DIAL]
to select a different address for each IC-7200 in the
range 01h to 7Fh.
76 : Set address to 76h
10-16
ON (default)
ON (default)
ON (default)
ON (default)
Auto (default)
76h (default)
