4. CARE AND MAINTENANCE

• Misapplication or negligence of the terms of service instruction can cause damage effect to your health.
• Avoid excessive vibration and shocks! Store the instrument and it's accessories only in carrying case.
• Optical level-is an accurate instrument, which should be stored and used with care.
• In high humidity and temperature you should dry out the instrument and clean it after usage.
• Do not store the instrument at a temperature below -25ºC and above 50ºC, otherwise the instrument can be out of
action.
• Do not put the instrument into the carrying case if the instrument or case are wet. To avoid moisture condensation
inside the instrument- dry out the case and the instrument.
• Check regularly instrument adjustment!
• Keep the lens clean and dry. To clean the lens use soft cotton cloth.
• Never place the instrument on the ground.
• If you leave the instrument on the tripod, close the lens with cover and cover the instrument.
• For cleaning plastic case use neutral detergents or water. Don't wipe the case with dissolvent.
• When you put your level into the case, place all accessories on their places,
5. PREPARATION BEFORE STARTING TO WORK

5.1. SET UP THE INSTRUMENT

1) Untie the belt around tripod legs and untwist clamping screws (Pic.1)
2) Without setting up the tripod, stretch out the legs till the tripod head will be at eye
level. Then tighten clamping screws.
3) The distance between legs should be equal to the equilateral triangle.
6
RUBER-X32
Pic.1
