SBOX-100-QM87i Fanless Marine Computer
MODEL:
SBOX-100-QM87i
Fanless Marine Computer with Intel® Core™ i5-4400E
Dual-Core CPU, Intel® QM87 Express Chipset, GbE LAN,
HDMI, DVI-D, VGA, CAN Bus, CFast Slot, RS-232/422/485,
USB 2.0, USB 3.0, iRIS-2400, RoHS Compliant

User Manual

Page I
Rev. 1.00 – June 4, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBOX-100-QM87i and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology SBOX-100-QM87i

Summary of Contents for IEI Technology SBOX-100-QM87i

  • Page 1: User Manual

    SBOX-100-QM87i Fanless Marine Computer MODEL: SBOX-100-QM87i Fanless Marine Computer with Intel® Core™ i5-4400E Dual-Core CPU, Intel® QM87 Express Chipset, GbE LAN, HDMI, DVI-D, VGA, CAN Bus, CFast Slot, RS-232/422/485, USB 2.0, USB 3.0, iRIS-2400, RoHS Compliant User Manual Page I...
  • Page 2 SBOX-100-QM87i Fanless Marine Computer Revision Date Version Changes June 4, 2015 1.00 Initial release Page II...
  • Page 3 SBOX-100-QM87i Fanless Marine Computer Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    SBOX-100-QM87i Fanless Marine Computer Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 F ........................2 EATURES 1.3 F ......................3 RONT ANEL 1.4 R ....................... 3 ANEL 1.5 T ..................5 ECHNICAL PECIFICATIONS 1.6 D ....................... 7 IMENSIONS 2 UNPACKING .........................
  • Page 5 SBOX-100-QM87i Fanless Marine Computer 4.1 I ......................27 NTRODUCTION 4.1.1 Starting Setup....................27 4.1.2 Using Setup ...................... 27 4.1.3 Getting Help..................... 28 4.1.4 BIOS Menu Bar....................28 4.2 M ........................29 4.3 A ....................... 30 DVANCED 4.3.1 ACPI Settings ....................31 4.3.2 RTC Wake Settings ...................
  • Page 6 SBOX-100-QM87i Fanless Marine Computer 6 INTERFACE CONNECTORS ................... 68 6.1 P ..............69 ERIPHERAL NTERFACE ONNECTORS 6.2 I ..............71 NTERNAL ERIPHERAL ONNECTORS 6.2.1 Audio Connector (AUDIO1) ................72 6.2.2 Battery Connector (BAT1) ................72 6.2.3 Chassis Intrusion Connector (CHASSIS1)............72 6.2.4 Digital I/O Connector (DIO1) .................
  • Page 7 SBOX-100-QM87i Fanless Marine Computer A REGULATORY COMPLIANCE ................84 B SAFETY PRECAUTIONS ..................89 B.1 S ..................... 90 AFETY RECAUTIONS B.1.1 General Safety Precautions ................90 B.1.2 Anti-static Precautions ..................91 B.1.3 Product Disposal ..................... 92 B.2 M ............92...
  • Page 8 SBOX-100-QM87i Fanless Marine Computer List of Figures Figure 1-1: SBOX-100-QM87i Fanless Marine Computer............2 Figure 1-2: Front Panel ........................3 Figure 1-3: Rear Panel........................4 Figure 1-4: SBOX-100-QM87i Dimensions (mm) .................7 Figure 3-1: CFast Slot Cover Retention Screw ................14 Figure 3-2: CFast Card Installation .....................14 Figure 3-3: Bottom Cover Retention Screws ................15...
  • Page 9 SBOX-100-QM87i Fanless Marine Computer List of Tables Table 1-1: Technical Specifications....................6 Table 2-1: Package List Contents ....................11 Table 3-1: RS-232 Serial Port (COM1) Pinouts ................19 Table 3-2: RS-232/422/485 Serial Port Pinouts ................19 Table 3-3: CAN Bus Connector Pinouts ..................20 Table 3-4: CAN Bus Jumper Settings ..................21 Table 4-1: BIOS Navigation Keys ....................28...
  • Page 10 SBOX-100-QM87i Fanless Marine Computer Table 6-25: CAN Bus Connector (CAN1) Pinouts..............80 Table 6-26: DVI Connector (DVI) Pinouts ...................80 Table 6-27: VGA Connector (VGA1) Pinouts ................81 Table 6-28: HDMI Connector (HDMI1) Pinouts................81 Table 6-29: RJ-45 GbE Connector (LAN1/2-CN1) Pinouts ............82 Table 6-30: RS-232 Serial Port (COM1) Pinouts ................82 Table 6-31: USB 2.0 Connector (USB1) Pinouts................82...
  • Page 11 SBOX-100-QM87i Fanless Marine Computer List of BIOS Menus BIOS Menu 1: Main ........................29 BIOS Menu 2: Advanced ......................30 BIOS Menu 3: ACPI Configuration ....................31 BIOS Menu 4: RTC Wake Settings ....................32 BIOS Menu 5: Trusted Computing ....................33 BIOS Menu 6: CPU Configuration ....................34 BIOS Menu 7: SATA Configuration .....................37...

  • Page 13: Introduction

    SBOX-100-QM87i Fanless Marine Computer Chapter Introduction Page 1...

  • Page 14: Overview

    1.1 Overview Figure 1-1: SBOX-100-QM87i Fanless Marine Computer The SBOX-100-QM87i series is a fanless marine computer with Intel® Core™ i5-4400E processor and Intel® QM87 Express Chipset. The SBOX-100-QM87i is preinstalled 4 GB of DDR3 SO-DIMM and can accommodate up to 16 GB of DDR3 memory. Storage in the system is handled by two 2.5”...

  • Page 15: Front Panel

     Three audio jacks: line-out, line-in and mic-in  RoHS compliant design 1.3 Front Panel The front panel of the SBOX-100-QM87i provides access to the following external I/O connectors and LED indicators:  4 x RS-232/422/485 serial port  1 x Power LED indicator (on: green; off: amber) ...

  • Page 16: Rear Panel

    SBOX-100-QM87i Fanless Marine Computer 1.4 Rear Panel The SBOX-100-QM87i rear panel provides access to the following external I/O connectors:  1 x 18 V–36 V DC input terminal block  1 x Audio line-in jack  1 x Audio line-out jack ...

  • Page 17: Technical Specifications

    SBOX-100-QM87i Fanless Marine Computer 1.5 Technical Specifications The specifications for the SBOX-100-QM87i are listed below. SBOX-100-QM87i 22nm 4th generation dual-core Intel® Core™ i5-4400E CPU (2.7GHz, 3M cache) System Chipset Intel® QM87 Express Chipset System Memory Two 1600 MHz 2 GB DDR3 SDRAM SO-DIMM preinstalled (system max.

  • Page 18: Table 1-1: Technical Specifications

    SBOX-100-QM87i Fanless Marine Computer 1 x PS/2 connector Keyboard/Mouse Storage 2 x 2.5” SATA 6GB/s SSD bay with RAID 0/1 function 1 x External CFast socket (with a screwed cover) Expansion Slot 1 x Full-size PCIe Mini slot 1 x Full-size/Half-size PCIe Mini slot...

  • Page 19: Dimensions

    SBOX-100-QM87i Fanless Marine Computer 1.6 Dimensions The physical dimensions of the SBOX-100-QM87i are shown in F igure 1-4. Figure 1-4: SBOX-100-QM87i Dimensions (mm) Page 7...

  • Page 20: Unpacking

    SBOX-100-QM87i Fanless Marine Computer Chapter Unpacking Page 8...

  • Page 21: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the SBOX-100-QM87i. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the SBOX-100-QM87i or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 22: Unpacking Checklist

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the SBOX-100-QM87i from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com.

  • Page 23: Table 2-1: Package List Contents

    SBOX-100-QM87i Fanless Marine Computer One Key Recovery CD Table 2-1: Package List Contents Page 11...

  • Page 24: Installation

    SBOX-100-QM87i Fanless Marine Computer Chapter Installation Page 12...

  • Page 25: Installation Precautions

    Electric shock and personal injury might occur if the rear panel of the SBOX-100-QM87i is opened while the power cord is still connected to an electrical outlet.

  • Page 26: Cfast Card Installation

    3.2 CFast Card Installation The SBOX-100-QM87i series has a CFast card slot on the rear panel. To install the CFast card into the system, please follow the steps below.

  • Page 27: Hdd Installation

    Step 3: retention screw. 3.3 HDD Installation The SBOX-100-QM87i has two 2.5” HDD bays inside the bottom cover. To install HDDs, follow the steps below. Remove the bottom cover by removing the 11 retention screws on the bottom Step 1: panel.

  • Page 28: Figure 3-5: Inserting The Hdd

    SBOX-100-QM87i Fanless Marine Computer Insert an HDD into the bracket until the HDD is firmly connected with the SATA Step 3: cable connector. Secure the HDD to the bracket using four retention screws (two screws on each side). See Figure 3-5.

  • Page 29: At/Atx Mode Selection

    SBOX-100-QM87i Fanless Marine Computer 3.4 AT/ATX Mode Selection AT and ATX power modes can both be used on the SBOX-100-QM87i panel PC. The selection is made through an AT/ATX switch on the I/O interface panel. The switch is shown below.

  • Page 30: Serial Device Connection

    SBOX-100-QM87i Fanless Marine Computer 3.6 Serial Device Connection The SBOX-100-QM87i series has five serial ports, including four RS-232/422/484 ports on the front panel and one RS-232 port on the rear panel. The port locations are shown in Figure 3-9. The pinouts of the serial ports are listed in the following sections.

  • Page 31: Serial Port (Com1)

    SBOX-100-QM87i Fanless Marine Computer 3.6.1 RS-232 Serial Port (COM1) The pinouts of the RS-232 serial port are listed in the following table. PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 3-1: RS-232 Serial Port (COM1) Pinouts 3.6.2 RS-232/422/485 Serial Port (COM2–COM5) The RS-232/422/485 mode selection of COM2–COM5 is made through the system BIOS.

  • Page 32: Can Bus Connection And Configuration

    SBOX-100-QM87i Fanless Marine Computer 3.7 CAN Bus Connection and Configuration The SBOX-100-QM87i has a CAN bus connector for CAN-bus connection. The pinouts for the CAN bus connector are listed in the figure and table below. Figure 3-10: CAN Bus Connector PIN NO.

  • Page 33: Powering On The System

    SBOX-100-QM87i Fanless Marine Computer Figure 3-11: CAN Bus Jumper Locations JP1 & JP2 DESCRIPTION Short Long wire transmitting Open Normal Table 3-4: CAN Bus Jumper Settings 3.8 Powering On the System To power on the system, follow the steps below: Connect the power cable to the 3-pin power input terminal block.

  • Page 34: Clear Cmos

    Figure 3-13: Power Connector and Power Button 3.9 Clear CMOS If the SBOX-100-QM87i fails to boot due to improper BIOS settings, the clear CMOS button clears the CMOS data and resets the system BIOS information. To do this, push the clear CMOS button for three seconds, and then restart the system. The clear CMOS button location is shown in Figure 3-14.

  • Page 35: Ipmi Setup Procedure

    SBOX-100-QM87i Fanless Marine Computer All the drivers for the SBOX-100-QM87i are on the utility CD that came with the system. The utility CD contains drivers for Windows 7 and Windows 8 operating systems. Please select the corresponding drivers for the system and follow the step-by-step procedure to install each driver.

  • Page 36: Using The Iei Iman Web Gui

    SBOX-100-QM87i Fanless Marine Computer Make sure the SBOX-100-QM87i is installed with an iRIS-2400 module. Step 1: Make sure at least one DDR3 SO-DIMM is installed in one of the SO-DIMM Step 2: sockets. If multiple SO-DIMMs are installed, all of the SO-DIMMs must be same size, same speed and same brand to get the best performance.

  • Page 37: Figure 3-16: Iei Iman Web Gui

    Figure 3-16: IEI iMAN Web GUI NOTE: To understand how to use the IEI iMAN Web GUI, please refer to the iRIS-2400 Web GUI user manual in the utility CD came with the SBOX-100-QM87i. The user manual describes each function in detail. Page 25...

  • Page 38: Bios Setup

    SBOX-100-QM87i Fanless Marine Computer Chapter BIOS Setup Page 26...

  • Page 39: Introduction

    SBOX-100-QM87i Fanless Marine Computer 4.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 40: Getting Help

    SBOX-100-QM87i Fanless Marine Computer Function Decrease the numeric value or make changes Page Up key Increase the numeric value or make changes Page Dn key Decrease the numeric value or make changes Esc key Main Menu – Quit and not save changes into CMOS...

  • Page 41: Main

    SBOX-100-QM87i Fanless Marine Computer 4.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.

  • Page 42: Advanced

    SBOX-100-QM87i Fanless Marine Computer The System Overview field has two user configurable fields:  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 43: Acpi Settings

    SBOX-100-QM87i Fanless Marine Computer 4.3.1 ACPI Settings The ACPI Settings menu (BIOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced ACPI Settings Select ACPI sleep state...

  • Page 44: Rtc Wake Settings

    SBOX-100-QM87i Fanless Marine Computer 4.3.2 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 4) configures RTC wake event. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm event.

  • Page 45: Trusted Computing

    SBOX-100-QM87i Fanless Marine Computer  If selected, the following appears with values that Enabled can be selected: *Wake up every day *Wake up date *Wake up hour *Wake up minute *Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off.

  • Page 46: Cpu Configuration

    SBOX-100-QM87i Fanless Marine Computer  Security Device Support [Disable] Use the Security Device Support option to configure support for the security devices.  Security device support is disabled. Disable EFAULT  Security device support is enabled. Enable 4.3.4 CPU Configuration Use the CPU Configuration menu (BIOS Menu 6) to view detailed CPU specifications and configure the CPU.
  • Page 47 SBOX-100-QM87i Fanless Marine Computer  CPU Signature: Lists the CPU signature value.  Microcode Patch: Lists the microcode patch being used. Max CPU Speed: Lists the maximum CPU processing speed.  Min CPU Speed: Lists the minimum CPU processing speed.

  • Page 48: Intel Virtualization Technology [Disabled]

    SBOX-100-QM87i Fanless Marine Computer  Intel Virtualization Technology [Disabled] Use the Intel Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.

  • Page 49: Sata Configuration

    SBOX-100-QM87i Fanless Marine Computer 4.3.5 SATA Configuration Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced...

  • Page 50: Intel Rapid Start Technology

    SBOX-100-QM87i Fanless Marine Computer 4.3.6 Intel Rapid Start Technology The Intel Rapid Start Technology menu (BIOS Menu 8) configures Intel® Rapid Start Technology. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced Intel(R) Rapid Start Technology [Disabled] Enable or disable...

  • Page 51: Amt Configuration

    SBOX-100-QM87i Fanless Marine Computer 4.3.7 AMT Configuration The AMT Configuration menu (BIOS Menu 9) allows advanced power management options to be configured. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced Intel AMT [Enabled] Enable/Disable Intel(R) Un-Configure ME...

  • Page 52: Usb Configuration

    SBOX-100-QM87i Fanless Marine Computer  Enable ME unconfigure Enabled 4.3.8 USB Configuration Use the USB Configuration menu (BIOS Menu 10) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.

  • Page 53: Iwdd H/W Monitor

    SBOX-100-QM87i Fanless Marine Computer  Legacy USB support enabled Enabled EFAULT  Legacy USB support disabled Disabled  Legacy USB support disabled if no USB devices are Auto connected 4.3.9 iWDD H/W Monitor The iWDD H/W Monitor menu (BIOS Menu 11) displays operating temperature and system voltages.

  • Page 54: F81866 Super Io Configuration

    SBOX-100-QM87i Fanless Marine Computer +5VSB +3.3V +3.3VSB 4.3.10 F81866 Super IO Configuration Use the F81866 Super IO Configuration menu (BIOS Menu 12) to set or change the configurations for the serial ports. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.

  • Page 55: Serial Port N Configuration

    SBOX-100-QM87i Fanless Marine Computer 4.3.10.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 13) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced Serial Port 1 Configuration...
  • Page 56 SBOX-100-QM87i Fanless Marine Computer  Serial Port I/O port address is 3E8h and the interrupt IO=3E8h; address is IRQ3, 4 IRQ=3, 4  Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3, 4 IRQ=3, 4 ...
  • Page 57 SBOX-100-QM87i Fanless Marine Computer  Serial Port I/O port address is 2C8h and the interrupt IO=2C8h; address is IRQ3, 4 IRQ=3, 4  Serial Port Mode [RS485] Use the Serial Port Mode option to set the Serial Port 2 signaling mode.
  • Page 58 SBOX-100-QM87i Fanless Marine Computer  Serial Port I/O port address is 2D0h and the interrupt IO=2D0h; address is IRQ10, 11 IRQ=10, 11  Serial Port I/O port address is 2D8h and the interrupt IO=2D8h; address is IRQ10, 11 IRQ=10, 11 ...
  • Page 59 SBOX-100-QM87i Fanless Marine Computer  Serial Port I/O port address is 2E8h and the interrupt IO=2E8h; address is IRQ10, 11 IRQ=10, 11  Serial Port I/O port address is 2D0h and the interrupt IO=2D0h; address is IRQ10, 11 IRQ=10, 11 ...

  • Page 60: Serial Port Console Redirection

    SBOX-100-QM87i Fanless Marine Computer  Serial Port I/O port address is 2C0h and the interrupt IO=2C0h; address is IRQ10, 11 IRQ=10, 11  Serial Port I/O port address is 2C8h and the interrupt IO=2C8h; address is IRQ10, 11 IRQ=10, 11 ...

  • Page 61: Console Redirection [Enabled]

    SBOX-100-QM87i Fanless Marine Computer Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced COM1 Console Redirection Console Redirection [Disabled] Enable/Disable > Console Redirection Settings COM2 Console Redirection [Disabled] > Console Redirection Settings COM3 Console Redirection [Disabled] > Console Redirection Settings...

  • Page 62: Iei Feature

    SBOX-100-QM87i Fanless Marine Computer 4.3.12 IEI Feature Use the IEI Feature menu (BIOS Menu 15) to configure One Key Recovery function. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced iEi Feature Auto Recovery Function Reboot and recover...

  • Page 63: Chipset

    SBOX-100-QM87i Fanless Marine Computer 4.4 Chipset Use the Chipset menu (BIOS Menu 16) to configure the system chipset. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Server Mgmt > PCH-IO Configuration PCH Parameters >...
  • Page 64 SBOX-100-QM87i Fanless Marine Computer  Azalia (HD Audio) [Enabled] Use the Azalia (HD Audio) option to enable or disable the High Definition Audio controller.  The onboard High Definition Audio controller is disabled Disabled  onboard High Definition Audio controller...

  • Page 65: System Agent (Sa) Configuration

    SBOX-100-QM87i Fanless Marine Computer 4.4.2 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 18) to configure the System Agent (SA) parameters. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Chipset VT-d Capability Supported...

  • Page 66: Graphics Configuration

    SBOX-100-QM87i Fanless Marine Computer 4.4.2.1 Graphics Configuration Use the Graphics Configuration submenu ( B IOS Menu 19) to configure the graphics settings. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Chipset Graphics Configuration Select which of Primary Display...

  • Page 67: Dvmt Total Gfx Mem [256M]

    SBOX-100-QM87i Fanless Marine Computer   128M  256M Default 512M   DVMT Total Gfx Mem [256M] Use the DVMT Total Gfx Mem option to select DVMT5.0 total graphic memory size used by the internal graphic device. The following options are available: ...

  • Page 68: Memory Configuration

    SBOX-100-QM87i Fanless Marine Computer 4.4.3 Memory Configuration Use the Memory Configuration submenu ( B IOS Menu 20) to display the memory information. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Chipset Memory Information Memory Frequency 1600 Mhz Total Memory...

  • Page 69: Bootup Numlock State [On]

    SBOX-100-QM87i Fanless Marine Computer  Bootup NumLock State [On] Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.  Allows the Number Lock on the keyboard to be EFAULT enabled automatically when the computer system boots up.

  • Page 70: Security

    SBOX-100-QM87i Fanless Marine Computer  Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.  Ignore all PXE Option ROMs Disabled EFAULT  Load PXE Option ROMs Enabled ...

  • Page 71: Save & Exit

    SBOX-100-QM87i Fanless Marine Computer  User Password Use the User Password to set or change a user password. 4.7 Save & Exit Use the Save & Exit menu (BIOS Menu 23) to load default BIOS values, optimal failsafe values and to save configuration changes.

  • Page 72: Server Management

    SBOX-100-QM87i Fanless Marine Computer  Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults.  Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options.

  • Page 73: System Event Log

    SBOX-100-QM87i Fanless Marine Computer 4.8.1 System Event Log Use the System Event Log menu (BIOS Menu 25) to configure the system event log of the BMC. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Server Mgmt Enabling/Disabling Options...
  • Page 74 SBOX-100-QM87i Fanless Marine Computer  Erase system event log on every reset. Yes, On every reset  When SEL is Full [Do Nothing] Use the When SEL is Full option to select an reaction to a full SEL.  Do not do anything when SEL is full.

  • Page 75: Bmc Network Configuration

    SBOX-100-QM87i Fanless Marine Computer 4.8.2 BMC Network Configuration Use the BMC Network Configuration menu (BIOS Menu 26) to configure the BMC network parameters. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Server Mgmt BMC network configuration Select to configure LAN...

  • Page 76: Maintenance

    SBOX-100-QM87i Fanless Marine Computer Chapter Maintenance Page 64...

  • Page 77: System Maintenance Overview

    Failure to follow these instructions may lead to personal injury and system damage. To preserve the working integrity of the SBOX-100-QM87i, the system must be properly maintained. If internal components need replacement, the proper maintenance procedures must be followed to ensure the system can continue to operate normally.

  • Page 78: Figure 5-1: Bottom Cover Retention Screws

    SBOX-100-QM87i Fanless Marine Computer WARNING: Using incorrectly specified SO-DIMM may cause permanently damage the SBOX-100-QM87i. Please make sure the purchased SO-DIMM complies with the memory specifications of the SBOX-100-QM87i. To replace a SO-DIMM into a SO-DIMM socket, please follow the steps below.

  • Page 79: Figure 5-3: So-Dimm Installation

    SBOX-100-QM87i Fanless Marine Computer Remove the cable tie that secures the heatsink with the SO-DIMM. Then, Step 3: remove the heatsink. Release the arms on the SO-DIMM socket to remove the SO-DIMM. Step 4: Align the new SO-DIMM with the socket. The SO-DIMM must be oriented in...

  • Page 80: Interface Connectors

    SBOX-100-QM87i Fanless Marine Computer Chapter Interface Connectors Page 68...

  • Page 81: Peripheral Interface Connectors

    SBOX-100-QM87i Fanless Marine Computer 6.1 Peripheral Interface Connectors The SBOX-100-QM87i motherboard comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Figure 6-1 and Figure 6-2. The Pin 1 locations of the on-board connectors are also indicated in the diagrams below.

  • Page 82: Figure 6-2: Main Board Layout Diagram (Solder Side)

    SBOX-100-QM87i Fanless Marine Computer Figure 6-2: Main Board Layout Diagram (Solder Side) Page 70...

  • Page 83: Internal Peripheral Connectors

    Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the peripheral interface connectors on the SBOX-100-QM87i motherboard. Pinouts of these connectors can be found in the following sections.

  • Page 84: Audio Connector (Audio1)

    SBOX-100-QM87i Fanless Marine Computer Connector Type Label SMBus connector 4-pin wafer SMB1 SO-DIMM connectors SO-DIMM connector DIMM1, DIMM2 SPI Flash connector 6-pin wafer SPI1 SPI Flash connector (EC) 2-pin header TPM connector 20-pin header TPM1 Table 6-1: Peripheral Interface Connectors 6.2.1 Audio Connector (AUDIO1)

  • Page 85: Digital I/O Connector (Dio1)

    SBOX-100-QM87i Fanless Marine Computer 6.2.4 Digital I/O Connector (DIO1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION DOUT3 DOUT2 DOUT1 DOUT0 DIN3 DIN2 DIN1 DIN0 Table 6-5: Digital I/O Connector (DIO1) Pinouts 6.2.5 EC Debug Connector (LPT_DB1) PIN NO. DESCRIPTION PIN NO.

  • Page 86: Front Panel Connector (F_Panel1)

    SBOX-100-QM87i Fanless Marine Computer 6.2.7 Front Panel Connector (F_PANEL1) DESCRIPTION DESCRIPTION Power LED PWR_LED+ Speaker SPKR+ PWR_LED+ IPMI LED IPMI ID_LED+ PWR_LED- IPMI ID_LED- Power PWR_BTN+ Speaker SPKR- Button PWR_BTN- HDD LED HDD_LED+ RESET+ HDD_LED- RESET- Table 6-8: Front Panel Connector (F_PANEL1) Pinouts 6.2.8 IPMI LED Connector (IPMI_LED1)

  • Page 87: Power Connector (Pwr1)

    SBOX-100-QM87i Fanless Marine Computer PIN NO. DESCRIPTION PIN NO. DESCRIPTION CLK- CLK+ PCIRST# VCC3 PCIRST# PERN2 3VDual PERP2 1.5V SMBCLK PETN2 SMBDATA PETP2 USBD- USBD+ 1.5V VCC3 Table 6-11: PCIe Mini Slots (MINI-PCIE1, MINI-PCIE2) Pinouts 6.2.11 Power Connector (PWR1) PIN NO.

  • Page 88: Power Button Connector (Pwr_Btn1)

    SBOX-100-QM87i Fanless Marine Computer 6.2.12 Power Button Connector (PWR_BTN1) PIN NO. DESCRIPTION PWRBTN_SW# Table 6-13: Power Button Connector (PWR_BTN1) Pinouts 6.2.13 PS_ON Connector (PS_ON1) PIN NO. DESCRIPTION 5VSB EC_PSON# Table 6-14: PS_ON Connector (PS_ON1) Pinouts 6.2.14 RS-232/422/485 Connector (COM2, COM3, COM4, COM5) PIN NO.

  • Page 89: Sata Connector (S_Ata2)

    SBOX-100-QM87i Fanless Marine Computer Table 6-16: SATA Connector (S_ATA1) Pinouts 6.2.16 SATA Connector (S_ATA2) PIN NO. DESCRIPTION Table 6-17: SATA Connector (S_ATA2) Pinouts 6.2.17 SATA Power Connector (SATA_PWR1) Total +5V SATA power is 3A (SATA_PWR1plus SATA_PWR2) Total +12V SATA power is 3A (SATA_PWR1plus SATA_PWR2) PIN NO.

  • Page 90: Sata Power Connector (Sata_Pwr2)

    SBOX-100-QM87i Fanless Marine Computer 6.2.18 SATA Power Connector (SATA_PWR2) PIN NO. DESCRIPTION +12V Table 6-19: SATA Power Connector (SATA_PWR2) Pinouts 6.2.19 SMBus Connector, EC (SMB1) PIN NO. DESCRIPTION SMB_DATA SMB_CLK +V5S Table 6-20: SMBus Connector, EC (SMB1) 6.2.20 SPI Flash Connector (SPI1) PIN NO.

  • Page 91: Spi Flash Connector, Ec (Cn2)

    GLKRUN# LPCPD# LDRQ# Table 6-23: TPM Connector (TPM1) Pinouts 6.3 External Interface Panel Connectors The table below lists the rear panel connectors on the SBOX-100-QM87i motherboard. Pinouts of these connectors can be found in the following sections. Connector Type Label...

  • Page 92: Can Bus Connector (Can1)

    SBOX-100-QM87i Fanless Marine Computer Connector Type Label HDMI connector HDMI HDMI1 Keyboard/mouse and USB 2.0 combo connector PS/2 K/B_USB1 USB 2.0 port GbE connectors RJ-45 LAN1/2-CN1 RS-232 serial port DB-9 COM1 USB 3.0 connectors USB 3.0 port USB3_CN1 Table 6-24: Rear Panel Connectors 6.3.1 CAN Bus Connector (CAN1)

  • Page 93: Vga Connector (Vga1)

    SBOX-100-QM87i Fanless Marine Computer 6.3.3 VGA Connector (VGA1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION GREEN GROUND BLUE DDCDA GROUND HSYNC GROUND VSYNC GROUND DDCCLK GROUND Table 6-27: VGA Connector (VGA1) Pinouts 6.3.4 HDMI Connector (HDMI1) PIN NO. DESCRIPTION PIN NO.

  • Page 94: Gbe Connectors (Lan1/2-Cn1)

    SBOX-100-QM87i Fanless Marine Computer 6.3.5 GbE Connectors (LAN1/2-CN1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDIA3- MDIA2+ MDIA3+ MDIA1+ MDIA1- MDIA0- MDIA2- MDIA0+ Table 6-29: RJ-45 GbE Connector (LAN1/2-CN1) Pinouts 6.3.6 RS-232 Serial Port (COM1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 6-30: RS-232 Serial Port (COM1) Pinouts 6.3.7 USB 2.0 Connectors (USB1)

  • Page 95: Usb 3.0 Connectors (Usb3_Cn1)

    SBOX-100-QM87i Fanless Marine Computer 6.3.8 USB 3.0 Connectors (USB3_CN1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ Table 6-32: USB 3.0 Connector (USB3_CN1) Pinouts Page 83...

  • Page 96: A Regulatory Compliance

    SBOX-100-QM87i Fanless Marine Computer Appendix Regulatory Compliance Page 84...
  • Page 97 SBOX-100-QM87i Fanless Marine Computer DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive 2004/108/EC  Low-Voltage Directive 2006/95/EC  RoHS II Directive 2011/65/EU  Ecodesign Directive 2009/125/EC  If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 98 SBOX-100-QM87i Fanless Marine Computer Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ...
  • Page 99 SBOX-100-QM87i Fanless Marine Computer Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 1999/5/CE. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
  • Page 100 SBOX-100-QM87i Fanless Marine Computer FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and  This device must accept any interference received, including interference that ...

  • Page 101: B Safety Precautions

    SBOX-100-QM87i Fanless Marine Computer Appendix Safety Precautions Page 89...

  • Page 102: Safety Precautions

    SBOX-100-QM87i is being installed, moved or modified.  Do not apply voltage levels that exceed the specified voltage range. Doing so may cause fire and/or an electrical shock. Electric shocks can occur if the SBOX-100-QM87i chassis is opened when  the SBOX-100-QM87i is running. ...

  • Page 103: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the SBOX-100-QM87i. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the SBOX-100-QM87i is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 104: Product Disposal

    Please follow the national guidelines for electrical and electronic product disposal. B.2 Maintenance and Cleaning Precautions When maintaining or cleaning the SBOX-100-QM87i, please follow the guidelines below. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the SBOX-100-QM87i, please read the details below. Page 92...

  • Page 105: Cleaning Tools

    Some components in the SBOX-100-QM87i may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the SBOX-100-QM87i. ...

  • Page 106: Cbios Menu Options

    SBOX-100-QM87i Fanless Marine Computer Appendix BIOS Menu Options Page 94...

  • Page 107: Bios Configuration Options

    SBOX-100-QM87i Fanless Marine Computer C.1 BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 4. 　 System Date [xx/xx/xx] ......................30 　 System Time [xx:xx:xx] .......................30 　 ACPI Sleep State [S1 only (CPU Stop Clock)]..............31 　...
  • Page 108 SBOX-100-QM87i Fanless Marine Computer 　 Serial Port Mode [RS485] ....................48 　 Console Redirection [Enabled]...................49 　 Auto Recovery Function [Disabled]...................50 　 Azalia (HD Audio) [Enabled] ....................52 　 Serial IRQ Mode [Continuous] ....................52 　 Power Saving Function (ERP) [Disabled]................52 　 VT-d [Disabled]........................53 　...

  • Page 109: D Watchdog Timer

    SBOX-100-QM87i Fanless Marine Computer Appendix Watchdog Timer Page 97...
  • Page 110 SBOX-100-QM87i Fanless Marine Computer NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.

  • Page 111: Example Program

    SBOX-100-QM87i Fanless Marine Computer NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 112: E Hazardous Materials Disclosure

    SBOX-100-QM87i Fanless Marine Computer Appendix Hazardous Materials Disclosure Page 100...

  • Page 113: Hazardous Material Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    SBOX-100-QM87i Fanless Marine Computer E.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 114 SBOX-100-QM87i Fanless Marine Computer Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 115 SBOX-100-QM87i Fanless Marine Computer 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

Table of Contents
