SAILORPC-12A Panel PC
IEI Technology Corp.
MODEL:
SAILORPC-12A
Waterproof Panel PC 1.6GHz Intel® Atom CPU
802.11b/g/n Wireless, Gigabit Ethernet, USB, RS-232
RS-232/422/485, CAN Bus, RoHS Compliant, IP 67
Rev. 1.12 – 25 September, 2009
WARNING
Tighten air pressure release screw to 7 kg-cm prior to use. This
screw is loosened prior to shipping. System is not waterproof until
this screw is tightened. Refer to diagram on page 14 for details.
User Manual
Page i
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology SAILORPC-12A
Summary of Contents for IEI Technology SAILORPC-12A
-
Page 1: User Manual
WARNING SAILORPC-12A Panel PC Tighten air pressure release screw to 7 kg-cm prior to use. This screw is loosened prior to shipping. System is not waterproof until this screw is tightened. Refer to diagram on page 14 for details. IEI Technology Corp. - Page 2 SAILORPC-12A Panel PC Revision Date Version Changes 25 September, 2009 1.12 Changed pressure screw tightening torque to 7 kg-cm 31 August, 2009 1.11 Added pressure release screw warning and explanation 15 July, 2009 1.00 Initial release Page ii...
- Page 3 SAILORPC-12A Panel PC Copyright COPYRIGHT NOTICE In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 4: Table Of Contents
SAILORPC-12A Panel PC Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 F ........................3 EATURES 1.3 F ......................3 RONT ANEL 1.4 R ....................... 3 ANEL 1.5 C ......................4 ONNECTORS 1.6 T ..................5 ECHNICAL PECIFICATIONS 1.7 D... - Page 5 SAILORPC-12A Panel PC 3.7.2 LAN Connection Cable ..................25 3.7.3 Serial Device Cable ..................26 3.7.4 USB Device Cable.................... 27 3.8 P ....................28 OWER ONNECTION 3.9 D ..................... 28 RIVER NSTALLATION 4 OSD ..........................29 4.1 OSD B ......................30 UTTONS 4.2 OSD S...
- Page 6 SAILORPC-12A Panel PC 5.5.4 Removable Drives .................... 67 5.5.5 CD/DVD Drives ....................68 5.6 S ......................... 69 ECURITY 5.7 C ........................70 HIPSET 5.7.1 Northbridge Configuration ................71 5.7.2 Southbridge Configuration ................74 5.8 E ......................... 74 6 SYSTEM MAINTENANCE ..................76 6.1 S...
- Page 7 SAILORPC-12A Panel PC List of Figures Figure 1-1: SAILORPC-12A......................2 Figure 1-2: Front Panel ........................3 Figure 1-3: Rear Panel........................4 Figure 1-4: Connectors ........................5 Figure 1-5: Dimensions (units in mm) ..................7 Figure 3–1: Pressure Release Screw..................14 Figure 3-2: Aluminum Back Cover Retention Screws ..............15 Figure 3–3: HDD Installation......................16...
- Page 8 SAILORPC-12A Panel PC List of Tables Table 1-1: Technical Specifications....................6 Table 2-1: Packing List.........................11 Table 2-2: Packing List.........................12 Table 3-1: Reset CMOS ........................17 Table 3-2: AT/ATX Power ......................18 Table 3-3: COM2 RS-232/422/485 Setup ..................18 Table 3-4: COM2 RS-232/422/485 Setup ..................18 Table 3-5: COM2 Serial Port Pinouts ..................19...
- Page 9 SAILORPC-12A Panel PC BIOS Menus BIOS Menu 1: Main ........................35 BIOS Menu 2: Advanced ......................36 BIOS Menu 3: CPU Configuration ....................37 BIOS Menu 4: IDE Configuration....................38 BIOS Menu 5: IDE Master and IDE Slave Configuration ............39 BIOS Menu 6: Super IO Configuration..................44 BIOS Menu 7: Hardware Health Configuration ................46...
-
Page 11: Introduction
SAILORPC-12A Panel PC Chapter Introduction Page 1... -
Page 12: Overview
The SAILORPC-12A is a waterproof, IP67 compliant panel PC. The SAILORPC-12A can be submerged to 1 m and peripheral devices can be connected by using the waterproof M12 connectors on the rear panel. The SAILORPC-12A is designed for environments with extreme amounts of dust and water. -
Page 13: Features
M12 connectors on the rear panel, with serial ports and USB ports for peripherals and a Gigabit Ethernet slot for networking. 1.2 Features Some of the standard features of the SAILORPC-12A flat panel PC include: Fully self-contained, only power from the external power supply required Wireless LAN... -
Page 14: Connectors
SAILORPC-12A Panel PC Figure 1-3: Rear Panel 1.5 Connectors The bottom panel has the following slots, buttons and switches (Figure 1-4): 1 x Gigabit LAN 1 x Power input 1 x RS-232 1 x RS-232/422/485 1 x Dual USB port... -
Page 15: Technical Specifications
SAILORPC-12A Panel PC Figure 1-4: Connectors 1.6 Technical Specifications The technical specifications for the SAILORPC-12A systems are listed in Table 1-1. SPECIFICATION SAILORPC-12ASR SAILORPC-12A Mainboard SAILORMB-945GSE-R10 1.6GHz Intel® Atom LCD Panel 12.1" 12.1" Resolution 1024 x 768 1024 x 768... -
Page 16: Table 1-1: Technical Specifications
SAILORPC-12A Panel PC SPECIFICATION SAILORPC-12ASR SAILORPC-12A 2 x Gigabit LAN 1 x Line output (audio) 1 x Power input (9-28 V) 1 x RS-232 1 x RS-232/422/485 4 x USB ports 1 x VGA port Power Consumption 43 W 32 W Cover Screw Torsion 7 kg-cm (6 lb-ft/0.68 Nm) -
Page 17: Dimensions
SAILORPC-12A Panel PC 1.7 Dimensions Figure 1-5: Dimensions (units in mm) Page 7... -
Page 18: Unpacking
SAILORPC-12A Panel PC Chapter Unpacking Page 8... -
Page 19: Unpack The Panel Pc
SAILORPC-12A Panel PC WARNING: When installing the SAILORPC-12A, make sure to: Turn the power off: Chance of electrocution. Turn off the monitor and unplug it from the power supply. Only let certified engineers change the hardware settings: Incorrect settings can cause irreparable damage to the product. -
Page 20: Packing List
Lift the monitor out of the boxes. Step 5: Remove the peripheral parts box from the main box. Step 6: S t e p 0 : 2.2 Packing List The SAILORPC-12A flat panel PC is shipped with the following components: Quantity Item Image SAILORPC-12A Power cable... -
Page 21: Table 2-1: Packing List
SAILORPC-12A Panel PC Quantity Item Image Panel mounting screws Touch screen pen Utility CD Table 2-1: Packing List These optional items are also available. Quantity Item Image USB cable LAN cable Serial port cable CAN bus cable Page 11... -
Page 22: Table 2-2: Packing List
SAILORPC-12A Panel PC Quantity Item Image Audio cable Power adapter Table 2-2: Packing List Page 12... -
Page 23: Installation
SAILORPC-12A Panel PC Chapter Installation Page 13... -
Page 24: Tighten The Pressure Release Screw
SAILORPC-12A Panel PC 3.1 Tighten the Pressure Release Screw WARNING: Fasten the pressure release screw on the back panel before use. The pressure release screw is loosened before shipping, but must be tightened before use to ensure the system is completely watertight. -
Page 25: Hard Drive Installation
SAILORPC-12A Panel PC 3.2 Hard Drive Installation This section outlines the installation of the hard drive in the SAILORPC-12A. To install the hard drive, please follow the steps below: Remove the plastic back cover. Step 1: Unfasten the screws. Lift the cover to remove (Figure 3-2). -
Page 26: Compactflash® Installation
SAILORPC-12A Panel PC Slide the SATA hard drive into the slot indicated below. Step 3: Figure 3–3: HDD Installation Fasten the screws. Step 4: Make sure the outer seal is seated properly, then replace the cover.S t e p 0 : Step 5: 3.3 CompactFlash®... -
Page 27: Jumper Settings
SAILORPC-12A Panel PC Make sure the outer seal is seated properly, then replace the cover.S t e p 0 : Step 4: 3.4 Jumper Settings NOTE: A jumper is a metal bridge that is used to close an electrical circuit. It consists... -
Page 28: Com2 Rs-232/422/485 Selection
SAILORPC-12A Panel PC See Table 3-2 Jumper Settings: This jumper sets the power mode to AT or ATX. Description Closed Open Table 3-2: AT/ATX Power 3.4.3 COM2 RS-232/422/485 Selection Jumper Label: JP17 and JP18 3-pin and 12-pin headers Jumper Type:... -
Page 29: Panel Resolution
SAILORPC-12A Panel PC RS-232 Desc. RS-422 Desc. RS-485 Desc. Table 3-5: COM2 Serial Port Pinouts 3.4.4 Panel Resolution Jumper Label: 8-pin header Jumper Type: See Table 3-6 Jumper Settings: This jumper selects the resolution of the display. Description Open 640 x 480, 18-bit... -
Page 30: I/O Connector Pinouts
SAILORPC-12A Panel PC 3.5 I/O Connector Pinouts All the connectors are M12 connectors, with different number of pins depending on Figure 3–5: Connectors 3.5.1 LAN Connector Connects to a network. Figure 3–6: LAN Port Description Description LAN-MDI0+ LAN-MDI2- Page 20... -
Page 31: Serial Port Connector
SAILORPC-12A Panel PC Description Description LAN-MDI2+ LAN-MDI3- LAN-MDI1- LAN-MDI3+ LAN-MDI0- LAN-MDI1+ Table 3-7: LAN Port 3.5.2 Serial Port Connector Allows serial communication. Figure 3–7: Serial Port Description Description Table 3-8: Serial Port Page 21... -
Page 32: Can & Audio Connector
SAILORPC-12A Panel PC 3.5.3 CAN & Audio Connector Connects to a CAN network and audio device. Figure 3–8: CAN & Audio Port Description Speaker right CAN+ CAN- Speaker left Speaker ground Table 3-9: CAN & Audio Port 3.5.4 USB Port Connector Connects to USB devices. -
Page 33: Power Connector
SAILORPC-12A Panel PC Description Description Power Power Data1- Data1+ Ground Data2+ Data2- Ground Table 3-10: Serial Port 3.5.5 Power Connector Connects to a CAN network and audio device. Figure 3–10: Power Connector Description Power Power Ground Ground Ground Table 3-11: Power Connector... -
Page 34: Mounting The System
SAILORPC-12A Panel PC 3.6 Mounting the System WARNING! The panel PC is very heavy. Two or more people should mount the panel PC. Dropping or bumping the panel PC during installation can cause serious or irreparable damage to the panel PC. -
Page 35: M12 Connection
SAILORPC-12A Panel PC 3.7.1 M12 Connection All the optional cables attach to the SAILORPC-12A with M12 connectors. The optional cables have M12 connectors at the one end and the standard connectors at the other end. To attach the M12 connector, align it with the slot and tighten by turning clockwise. -
Page 36: Serial Device Cable
SAILORPC-12A Panel PC Figure 3-13: LAN Connection Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN Step 3: cable RJ-45 connector into the onboard RJ-45 port. Step 0: 3.7.3 Serial Device Cable The serial device connectors are for connecting serial devices. Follow the steps below to connect a serial device to the panel PC. -
Page 37: Usb Device Cable
SAILORPC-12A Panel PC Figure 3-14: Serial Device Connector Secure the connector. Secure the serial device connector to the external Step 3: interface by tightening the two retention screws on either side of the connector. Step 0: 3.7.4 USB Device Cable To connect USB devices, please follow the instructions below. -
Page 38: Power Connection
Step 3: connector into the onboard connector. Step 0: 3.8 Power Connection The power supply connects to the SAILORPC-12A with an M12 connector. Connect the M12 connector to the SAILORPC-12A. Step 1: Connect the power plug end to the mains power. -
Page 39: Osd
SAILORPC-12A Panel PC Chapter Page 29... -
Page 40: Osd Buttons
SAILORPC-12A Panel PC 4.1 OSD Buttons Figure 4–1: OSD Buttons Power On/Off Toggles the power on and off Brightness Up Adjusts the screen brighter Brightness Down Adjusts the screen dimmer Volume Up Adjusts the volume louder Volume Down Adjusts the volume quieter Ambient Light Sensor On/Off Toggles the ambient light sensor. -
Page 41: Osd Software
SAILORPC-12A Panel PC 4.2 OSD Software The OSD options can be controlled through software. A description of the options is shown below. Figure 4–2: OSD Software Figure 4–3: OSD Software 1. Volume On: Sound can be heard and is adjusted using the slider to the right 2. -
Page 42: Bios Setup
SAILORPC-12A Panel PC Chapter BIOS Setup Page 32... -
Page 43: Introduction
SAILORPC-12A Panel PC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways. -
Page 44: Getting Help
SAILORPC-12A Panel PC Function F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. -
Page 45: Main
SAILORPC-12A Panel PC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset... -
Page 46: Advanced
SAILORPC-12A Panel PC The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year. -
Page 47: Cpu Configuration
SAILORPC-12A Panel PC 5.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 3) to view detailed CPU specifications and configure the CPU. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Configure Advanced CPU Settings Module Version:3F.12 ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯... -
Page 48: Ide Configuration
SAILORPC-12A Panel PC 5.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit IDE Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯... -
Page 49: Ide Master, Ide Slave
SAILORPC-12A Panel PC Only the IDE drives are enabled. SATA drives are PATA Only disabled Configure SATA as [IDE] Use the Configure SATA as option to configure SATA devices as normal IDE devices. Configures SATA devices as normal IDE device. -
Page 50: Type [Auto]
SAILORPC-12A Panel PC Type: Indicates the type of devices a user can manually select Vendor: Lists the device manufacturer Size: List the storage capacity of the device. LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a method of addressing data on a disk drive is supported or not. -
Page 51: Lba/Large Mode [Auto]
SAILORPC-12A Panel PC This option specifies an ATAPI Removable Media ARMD Device. These include, but are not limited to: LS-120 LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB. -
Page 52: Dma Mode [Auto]
SAILORPC-12A Panel PC BIOS auto detects the PIO mode. Use this value if the IDE disk Auto EFAULT drive support cannot be determined. PIO mode 0 selected with a maximum transfer rate of 3.3 MB/s PIO mode 1 selected with a maximum transfer rate of 5.2 MB/s PIO mode 2 selected with a maximum transfer rate of 8.3 MB/s... -
Page 53: Auto]
SAILORPC-12A Panel PC Ultra DMA mode 1 selected with a maximum data transfer UDMA1 rate of 25 MB/s Ultra DMA mode 2 selected with a maximum data transfer UDMA2 rate of 33.3 MB/s Ultra DMA mode 3 selected with a maximum data transfer... -
Page 54: Super Io Configuration
SAILORPC-12A Panel PC 5.3.3 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 6) to set or change the configurations for the FDD controllers, parallel ports and serial ports. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset... -
Page 55: Serial Port3 Address [3E8]
SAILORPC-12A Panel PC Serial Port3 Address [3E8] Selects the serial port base address. No base address Disabled I/O address 3E8 EFAULT I/O address 2E8 I/O address 2F0 I/O address 2E0 Serial Port3 IRQ [11] Selects the serial port interrupt address. -
Page 56: Hardware Health Configuration
SAILORPC-12A Panel PC IRQ address 11 EFAULT Serial Port5 Address [2F0] Selects the serial port base address. No base address Disabled I/O address 2F0 EFAULT Serial Port5 IRQ [10] Use the Serial Port5 IRQ option to select the interrupt address for serial port 5. -
Page 57: Mode Setting [Full On Mode]
SAILORPC-12A Panel PC Mode Setting [Full On Mode] Use the Mode Setting option to configure the second fan. Fan is on all the time Full On Mode EFAULT The fan adjusts its speed using these settings: Automatic mode Temp. Limit of OFF Temp. -
Page 58: Start Pwm [070]
SAILORPC-12A Panel PC Start PWM [070] This is the initial speed of the fan when it first starts spinning. PWM Minimum Mode: 0 PWM Maximum Mode: 127 Slope PWM [1 PWM] A bigger value will increase the fan speed in big amounts. A smaller value will increase the speed more gradually. -
Page 59: Power Configuration
SAILORPC-12A Panel PC SYS fan 2 speed The following core voltages are monitored: CPU core +1.05V +3.30V +5.00V +12.0V +1.5V +1.8V 5.3.5 Power Configuration The Power Configuration menu (BIOS Menu 8) allows the advanced power management options to be configured. -
Page 60: Acpi Settings
SAILORPC-12A Panel PC 5.3.5.1 ACPI Settings Use the ACPI Settings menu (BIOS Menu 9) to select the ACPI state when the system is suspended. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit ACPI Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Suspend Mode [S1 (POS)] Select Screen ↑... -
Page 61: Apm Configuration
SAILORPC-12A Panel PC 5.3.5.2 APM Configuration The APM Configuration menu (BIOS Menu 10) allows the advanced power management options to be configured. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit APM Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Power Off Restore on AC Power Loss... -
Page 62: Resume On Keyboard/Mouse [Disabled]
SAILORPC-12A Panel PC When the power button is pressed the system goes into Suspend suspend mode Resume on Keyboard/Mouse [Disabled] Use the Resume on Keyboard/Mouse BIOS option to enable activity on either the keyboard or mouse to rouse the system from a suspend or standby state. That is, the system is roused when the mouse is moved or a button on the keyboard is pressed. -
Page 63: Remote Access Configuration
SAILORPC-12A Panel PC The real time clock (RTC) cannot generate a wake Disabled EFAULT event If selected, the following appears with values that Enabled can be selected: RTC Alarm Date (Days) System Time After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. -
Page 64: Serial Port Number [Com1]
SAILORPC-12A Panel PC Remote access is disabled. Disabled EFAULT Remote access configuration options shown below Enabled appear: Serial Port Number Serial Port Mode Flow Control Redirection after BIOS POST Terminal Type VT-UTF8 Combo Key Support These configuration options are discussed below. -
Page 65: Flow Control [None]
SAILORPC-12A Panel PC 19200 8,n,1 09600 8,n,1 NOTE: Identical baud rate setting musts be set on the host (a management computer running a terminal software) and the slave Flow Control [None] Use the Flow Control option to report the flow control method for the console redirection application. -
Page 66: Vt-Utf8 Combo Key Support [Disabled]
SAILORPC-12A Panel PC The target terminal type is VT-UTF8 VT-UTF8 VT-UTF8 Combo Key Support [Disabled] Use the VT-UFT8 Combo Key Support option to enable additional keys that are not provided by VT100 for the PC 101 keyboard. The VT100 Terminal Definition is the standard convention used to configure and conduct emergency management tasks with UNIX-based servers. -
Page 67: Usb Configuration
SAILORPC-12A Panel PC 5.3.7 USB Configuration Use the USB Configuration menu (BIOS Menu 12) to read USB configuration information and configure the USB settings. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit USB Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Disabled Module Version – 2.24.0-11.4... -
Page 68: Usb 2.0 Controller [Enabled]
SAILORPC-12A Panel PC USB 2.0 Controller [Enabled] Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller USB 2.0 controller disabled Disabled USB 2.0 controller enabled Enabled EFAULT Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. -
Page 69: Usb Mass Storage Device Configuration
SAILORPC-12A Panel PC 5.3.7.1 USB Mass Storage Device Configuration Use the USB Mass Storage Device Configuration menu (BIOS Menu 13) to configure USB mass storage class devices. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit USB Mass Storage Device Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯... -
Page 70: Pci/Pnp
SAILORPC-12A Panel PC Emulation Type [Auto] Use the Emulation Type BIOS option to specify the type of emulation BIOS has to provide for the USB device. BIOS auto-detects the current USB. Auto EFAULT The USB device will be emulated as a floppy drive. -
Page 71: Bios Menu 14: Pci/Pnp Configuration
SAILORPC-12A Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced PCI/PnP Settings Available: Specified IRQ ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ is available to be use the PCI/PnP devices IRQ3 [Reserved] Reserved: Specified IRQ IRQ4 [Reserved] is reserved for use by... -
Page 72: Dma Channel# [Available]
SAILORPC-12A Panel PC IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device. The specified DMA is available to be used by Available EFAULT... -
Page 73: Boot
SAILORPC-12A Panel PC 5.5 Boot Use the Boot menu (BIOS Menu 15) to configure system boot options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Boot Settings Configure settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ during system boot. > Boot Settings Configuration > Boot Device Priority >... -
Page 74: Quick Boot [Enabled]
SAILORPC-12A Panel PC Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. No POST procedures are skipped Disabled Some POST procedures are skipped to decrease Enabled EFAULT the system boot time Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots. -
Page 75: Boot From Lan Support [Disabled]
SAILORPC-12A Panel PC Allows the Number Lock on the keyboard to be enabled EFAULT automatically when the computer system boots up. This allows the immediate use of the 10-key numeric keypad located on the right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard is lit. -
Page 76: Boot Device Priority
SAILORPC-12A Panel PC 5.5.2 Boot Device Priority Use the Boot Device Priority menu (BIOS Menu 17) to specify the boot sequence from the available devices. The drive sequence also depends on the boot sequence in the individual device section. BIOS SETUP UTILITY... -
Page 77: Hard Disk Drives
SAILORPC-12A Panel PC 5.5.3 Hard Disk Drives Use the Hard Disk Drives menu to specify the boot sequence of the available HDDs. Only installed hard drives are shown. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Hard Disk Drives Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯... -
Page 78: Cd/Dvd Drives
SAILORPC-12A Panel PC 5.5.5 CD/DVD Drives Use the CD/DVD Drives menu to specify the boot sequence of the available CD/DVD drives. When the menu is opened, the CD drives and DVD drives connected to the system are listed as shown below:... -
Page 79: Security
SAILORPC-12A Panel PC 5.6 Security Use the Security menu (BIOS Menu 21) to set system and user passwords. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Security Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Supervisor Password :Not Installed User Password :Not Installed Change Supervisor Password... -
Page 80: Chipset
SAILORPC-12A Panel PC 5.7 Chipset Use the Chipset menu (BIOS Menu 22) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. -
Page 81: Northbridge Configuration
SAILORPC-12A Panel PC 5.7.1 Northbridge Configuration Use the Northbridge Chipset Configuration menu (BIOS Menu 23) to configure the Northbridge chipset. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Northbridge Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Memory Hole [Disabled] Internal Graphics Mode Select... -
Page 82: Dvmt Mode Select [Dvmt Mode]
SAILORPC-12A Panel PC Dedicates 1 MB of main memory for graphics Enable, 1 MB Dedicated 8 MB of main memory for graphics Enable, 8 MB EFAULT DVMT Mode Select [DVMT Mode] Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology (DVMT) operating mode. -
Page 83: Secondary Display Device [Auto]
SAILORPC-12A Panel PC Secondary Display Device [Auto] Select the second display device to try if the first display device is not available. EFAULT Disabled LFP Panel Type Use the Panel Type to determine the LCD panel resolution. Configuration options are... -
Page 84: Southbridge Configuration
SAILORPC-12A Panel PC 5.7.2 Southbridge Configuration The Southbridge Configuration menu (BIOS Menu 24) the Southbridge chipset to be configured. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Southbridge Configuration Options ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Auto Audio Controller [Azalia] Azalia AC'97 Audio Only... -
Page 85: Bios Menu 25:Exit
SAILORPC-12A Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Exit Options Exit system setup after ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ saving the changes. Save Changes and Exit F10 key can be used for Discard Changes and Exit this operation Discard Changes... -
Page 86: System Maintenance
SAILORPC-12A Panel PC Chapter System Maintenance Page 76... -
Page 87: System Maintenance Introduction
SAILORPC-12A Panel PC 6.1 System Maintenance Introduction If the components of the SAILORPC-12A fail they must be replaced, such as the wireless LAN module or the motherboard. Please contact the system reseller or vendor to purchase the replacement parts. Back cover removal instructions and jumper settings for the SAILORPC-12A are described below. -
Page 88: Memory Module Replacement
SAILORPC-12A Panel PC Figure 6-1: Back Cover Retention Screws 6.4 Memory Module Replacement The flat panel PC has a preinstalled memory module. If the memory module fails, take the steps below to replace it. Remove the back cover. See Section 6.3 above. -
Page 89: Hard Drive And Compactflash® Replacement
To replace the hard drive or CompactFlash® card, please refer to the hard drive and CompactFlash® installation sections. 6.6 Cover Replacement To ensure that the SAILORPC-12A remains water-tight, the instructions below must be followed exactly. Check the rubber seal is seated correctly. -
Page 90: Figure 6-3: Rubber Seal
SAILORPC-12A Panel PC Figure 6–3: Rubber Seal Check that the thermal pads are correctly placed on the back cover. The thermal Step 7: pads transfer the heat from the system chipset to the external casing. Figure 6–4: Thermal Pads Page 80... -
Page 91: Figure 6-5: Rear Cover Screws
SAILORPC-12A Panel PC Replace the back cover. Step 8: Press down the cover firmly and tighten the screws to 7 kg-cm (6 lb-ft/0.68 Nm). Step 9: S t e p 0 : Figure 6–5: Rear Cover Screws Page 81... -
Page 92: A Safety Precautions
SAILORPC-12A Panel PC Appendix Safety Precautions Page 82... -
Page 93: Safety Precautions
Do not apply voltage levels that exceed the specified voltage range. Doing so may cause fire and/or an electrical shock. Electric shocks can occur if the SAILORPC-12A chassis is opened when the SAILORPC-12A is running. Do not drop or insert any objects into the ventilation openings of the SAILORPC-12A. -
Page 94: Anti-Static Precautions
A.2 Maintenance and Cleaning Precautions When maintaining or cleaning the SAILORPC-12A, please follow the guidelines below. A.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the SAILORPC-12A, please read the details below. Page 84... -
Page 95: Cleaning Tools
SAILORPC-12A Panel PC Except for the LCD panel, never spray or squirt liquids directly onto any other components. To clean the LCD panel, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth. The interior does not require cleaning. Keep fluids away from the interior. -
Page 96: Bbios Options
SAILORPC-12A Panel PC Appendix BIOS Options Page 86... - Page 97 SAILORPC-12A Panel PC Below is a list of BIOS configuration options in the BIOS chapter. System Overview .........................35 System Time [xx:xx:xx] .......................36 System Date [xx/xx/xx] ......................36 ATA/IDE Configuration [Compatible].................38 Legacy IDE Channels [SATA Pri, PATA Sec] ..............38 Configure SATA as [IDE].....................39 Auto-Detected Drive Parameters..................39...
- Page 98 SAILORPC-12A Panel PC Resume on Keyboard/Mouse [Disabled] ................52 Resume on Ring [Disabled] ....................52 Resume on PCI-Express WAKE# [Enabled]..............52 Resume On RTC Alarm [Disabled]..................52 Remote Access [Disabled]....................53 Serial Port Number [COM1]....................54 Base Address, IRQ [2F8h,3]....................54 Serial Port Mode [115200 8,n,1]..................54 Flow Control [None]......................55 Redirection After BIOS POST [Always] ................55...
- Page 99 SAILORPC-12A Panel PC DVMT Mode Select [DVMT Mode]..................72 DVMT/FIXED Memory [128 MB] ..................72 Boot Display Device [Auto]....................72 Secondary Display Device [Auto] ..................73 LFP Panel Type ........................73 LFP Current Jumper Setting ....................73 Audio Controller [Auto] .......................74 Save Changes and Exit .......................75 Discard Changes and Exit....................75...
-
Page 100: C Terminology
SAILORPC-12A Panel PC Appendix Terminology Page 90... - Page 101 SAILORPC-12A Panel PC Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® AC ’97 in 1997. Advanced Configuration and Power Interface (ACPI) is an OS-directed ACPI configuration, power management, and thermal management interface. Advanced Host Controller Interface (AHCI) is a SATA Host controller AHCI register-level interface.
- Page 102 SAILORPC-12A Panel PC Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. Dual Inline Memory Modules are a type of RAM that offer a 64-bit data DIMM bus and have separate electrical contacts on each side of the module.
- Page 103 SAILORPC-12A Panel PC Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. Low-voltage differential signaling (LVDS) is a dual-wire, high-speed LVDS differential electrical signaling system commonly used to connect LCD displays to a computer.
-
Page 104: D Watchdog Timer
SAILORPC-12A Panel PC Appendix Watchdog Timer Page 94... - Page 105 SAILORPC-12A Panel PC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
-
Page 106: Example Program
SAILORPC-12A Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;... -
Page 107: E Hazardous Materials Disclosure
SAILORPC-12A Panel PC Appendix Hazardous Materials Disclosure Page 97... -
Page 108: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury
SAILORPC-12A Panel PC E.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only. - Page 109 SAILORPC-12A Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
