ICEROCK3-T10 Tablet PC

6.1 System Maintenance Introduction

If the components of the ITCW1010 fail they must be replaced, such as the wireless
LAN module or the motherboard. Please contact the system reseller or vendor to
purchase the replacement parts.

6.2 Motherboard Replacement

In the case of motherboard failure, please contact an iTech sales representative, reseller or
system vendor. The motherboard is accessible after opening the rear cover.

6.3 Battery Replacement

This section covers the replacement of the battery pack.
Unlock the two battery latches on the rear panel by rotating the latches as
Step 1:
shown in Figure 6-1.

Figure 6-1: Unlock Battery Latches

Remove the battery pack.
Step 2:
Install a battery pack as shown in
Step 3: F igure 6-2.
4 7 4
