3.1 Charge the System

WARNING:
When charging the system, make sure a power supply with the correct
input voltage is being fed into the system. Incorrect voltages applied to
the system may cause damage to the internal electronic components
and may also cause injury to the user.
To charge the ITCW1010, follow the steps below.
Install the charging adapter to the ITCW1010. Secure the charging adapter
Step 1:
by tightening the two retention screws on either side of the adapter.

Figure 3-1: Install Charging Adapter

Connect the ITCW1010 with a power source through the power adapter
Step 2:
came with the package.
The system starts to charge the battery and the charge status LED lights up
Step 3:
indicating the battery is being charged. When the battery is fully charged, the
power status LED turns off. Please refer to Section 1.4.1: Status Indicators.
Page 16
ICEROCK3-T10 Tablet PC
