Silicon Graphics Rackable C2112-4GP3 User Manual page 21

007-6363-001
Table 1-2 Serverboard Features (continued)
Feature Description
InfiniBand A serverboard includes an FDR (fourteen data rate) speed InfiniBand QSFP
connector. InfiniBand is a scalable serial communications link intended for
connecting processors with high-speed peripherals.
Other features Other onboard features that promote system health include onboard voltage
monitors, a chassis intrusion header, auto-switching voltage regulators,
chassis and CPU overheat sensors, virus protection, node manager software,
and BIOS rescue.
Figure 1-4 shows a block diagram of the serverboard.
Note: Figure 1-4 is a general block diagram and may not represent the exact features on your
serverboard. See Table 1-2
is intended for your reference only.
for the actual specifications of your serverboard. This block diagram
Serverboard Features
5
