Removing the Chassis Cover and Protective Film

007-6363-001
To provide proper ventilation and cooling, remove the protective film covering the top of the
chassis before operating the server for the first time.
Figure 5-1
Removing the Chassis Cover
To do so, perform the following steps:
1. Remove the two screws which secure the top cover onto the chassis as shown in
2. Lift the top cover up and off the chassis.
3. Peel off the protective film covering the top cover and the top of the chassis.
4. Check that all ventilation openings on the top cover and the top of the chassis are clear and
unobstructed.
Caution: Except for short periods of time, do not operate the server without the cover in place.
The chassis cover must be in place to allow proper airflow and prevent overheating.
Removing the Chassis Cover and Protective Film
Figure 5-1.
33
