Figure 1-2 Front Chassis View; Figure 1-3 Rear Chassis View - Silicon Graphics Rackable C2112-4GP3 User Manual

Ethernet LAN Ports
USB Ports
Infiniband Port
007-6363-001
Figure 1-2 shows the noteworthy components on the front of the server chassis.
Figure 1-2
Front Chassis View
Figure 1-3 shows the noteworthy components on the rear of the server chassis.
VGA Port
Figure 1-3 Rear Chassis View
IPMI LAN Port
Server Chassis Features
