1: Introduction

Serverboard Features

4
At the heart of the SGI Rackable C2112-4GP3 server are dual-processor serverboards based on
®
the Intel C612 chipset and designed to provide maximum performance. Four of these
serverboards can be mounted in the server chassis.
serverboards.
Table 1-2 Serverboard Features
Feature Description
Processors Each serverboard supports single or dual Intel Xeon
processors.
Memory Each serverboard has 16 DIMM slots supporting up to 1024 GB of
LRDIMM or 512 of RDIMM DDR4-2133/1866/1600 MHz registered ECC
memory.
SATA subsystem A SATA controller is integrated into the C612 chipset to provide up to a
10-port 6 Gb/s SATA3 subsystem. The SATA3 subsystem supports RAID 0,
1, 5, and 10. The SATA drives are hot-swappable units.
Note: The operating system you use must have RAID support to enable the
hot-swap capability and RAID function of the SATA drives.
PCI expansion For each node, the server has one PCIe
slots use with a riser card.
Onboard A serverboard can include the following:
controllers/ports – An Intel i350 gigabit (10/100/1000 Mb/s) Ethernet dual-channel controller
or an Intel X540 10 gigabit Ethernet dual-channel controller
– One 9-pin RS-232 port
– One Mellonox
connector One COM port
– One VGA (monitor) port
– Two USB 2.0 ports (Additional internal USB headers are included on the
serverboard.)
– One IPMI-dedicated LAN port
– Two Ethernet ports
Graphics Each serverboard features an integrated ASPEED
controller integrated VGA/2D graphics controller.
Table 1-2
®
3.0 x16 slot (Slot 1) available for
® ®
Connect-X3 InfiniBand supporting a single QSFP
describes the major features of the
®
E5-2600 v3 Series
®
2400 BMC with an
