  • Page 1 MDSC-8258 User Guide (451920611502) K5902088/01 08/09/2014...
  • Page 2 Barco nv President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/esupport Visit us at the web: www.barco.com Printed in Belgium...

  • Page 3: Table Of Contents

    Legal disclaimer ....................34 (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 4 RS-232 protocol ....................39 (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 5: Welcome

    The MDSC-8258 shall provide 8 MP screen resolution, high luminance and accept digital inputs, according to the DVI standard, with the native panel resolution of 3840 x 2160. The MDSC-8258 can operate in Dual Link. Other important features like the very large viewing angle, the high brightness level, the backlight stabiliza- tion, the grayscale correction and the compliance with the DICOM standards, will help the users avoiding misinterpretation in medical diagnosis.

  • Page 6: About This User Guide

    About this user guide Overview This manual provides a support to the user during the installation, set up and utilization of the MDSC-8258 display. Depending on the specific version that has been purchased, some of the features and options described in this document may not apply to the display in user’s hands.

  • Page 7: Parts, Controls And Connectors

    2. Parts, controls and connectors 2. PARTS, CONTROLS AND CONNECTORS Front view Overview Image 2-1 Power On/Off Enter key Down key Up key Esc key A 5-key keypad is located on the bottom of the display. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 8: Rear View

    2. Parts, controls and connectors Rear view Overview Image 2-2 VESA mount screw holes Connector location Connector view Overview Image 2-3 Protective earth pin Input power connector DVI-D dual link connector 4 +5Vout connector DVI-D dual link connector 3 (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 9: Connector Pin Assignments

    D2_Rx+ (T.M.D.S.) GND (data 2 shield) D4_RX- (T.M.D.S.) D4_RX+ (T.M.D.S.) SCL (for DDC) SDA (for DDC) N.C. D1_Rx- (T.M.D.S.) D1_Rx+ (T.M.D.S.) GND (data 1 shield) D3_RX- (T.M.D.S.) D3_RX+ (T.M.D.S) +5V input (form the video source system) (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 10: Dvi-2 Connector

    GND (data 1 shield) D3_RX- (T.M.D.S.) D3_RX+ (T.M.D.S) +5V input (form the video source system) +5V Power for DVI extenders D0_Rx- (T.M.D.S.) D0_Rx+ (T.M.D.S.) GND (data 0 shield) D5_RX- (T.M.D.S.) D5_RX+ (T.M.D.S.) GND (clock shield) CK_Rx+ (T.M.D.S.) CK_Rx- (T.M.D.S.) (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 11: Dvi-3 Connector

    +5V Power for DVI extenders D0_Rx- (T.M.D.S.) D0_Rx+ (T.M.D.S.) GND (data 0 shield) D5_RX- (T.M.D.S.) D5_RX+ (T.M.D.S.) GND (clock shield) CK_Rx+ (T.M.D.S.) CK_Rx- (T.M.D.S.) 2.4.4 DVI–4 connector Overview Image 2-7 Function D2_Rx- (T.M.D.S.) D2_Rx+ (T.M.D.S.) GND (data 2 shield) (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 12: Rs232 Connector

    D5_RX+ (T.M.D.S.) GND (clock shield) CK_Rx+ (T.M.D.S.) CK_Rx- (T.M.D.S.) 2.4.5 RS232 connector Overview Image 2-8 Function Not connected Rx (driven by host) Tx (driven by display) Not connected Ground Not connected Not connected Not connected Not connected (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 13: Display Installation

    1. Mount the brackets to the display using the screws provided in the accessory kit. Verify that the screwing operation is well done using a torque value of 4N/m. 2. Move your display as shown on the picture below. (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 14 3. Display installation 3. After transportation, you can remove the brackets and the 8 mounting holes can be closed with 8 plastic caps. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 15: Vesa Mount Installation

    (IEC60601–1). To mount the display to an arm stand 1. Attach the mounting arm or stand firmly to the panel using 6 screws (M6) Screw insert can be maximum 11 mm and minimum 8 mm. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 16: Video Input Connection

    To connect the video inputs 1. Connect the available video source(s) to the corresponding video inputs using the appropriate video cable(s). Image 3-2 2. Select the input via OSD or RS-232 (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 17: Power Supply Connection

    2. Plug the power connector of the adapter into the power port of the display. Image 3-3 3. The MDSC-8258 display is provided with an additional protective earth pin, if necessary connect the earth pin to a grounded outlet by means of an AWG18 (max. 6ft / 1,8m long) wire.
  • Page 18 3. Display installation (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 19: Daily Operation

    Led is ORANGE: (blinking): Incorrect video timing (at least one of four inputs) • Led is RED: Stand By • Led is RED (blinking): Diagnostic error (PWS, Panel Temperatures) In this case of warning please contact the service assistance. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 20: Brightness Adjustment

    When the desired Menu page is highlighted, press the enter key to select the top menu item that will be highlighted. • Use the up/down key to move to other Menu Items, then press the enter key to select it. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 21: Enter Password

    OSD menu (see "Time-out OSD", page 24). The OSD menu position can be adjusted in the OSD menu (see "Horizontal/Vertical po- sition", page 24). The OSD menu can be password protected, see "Key lock", page 26. (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 22 4. Daily operation (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 23: Advanced Operation

    6. Select one of the available profiles and confirm. 5.2.2 Out power About out power This allows to enable or disable the 5Vdc output on pin 16 of each DVI connector to power, i.e. external signal conversion dongles. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 24: Out Mode Menu

    In this menu, COLOR is replaced with the current color temperature (e.g. 6500°K (FAC- TORY)) To change the transfer function 1. Bring up the OSD main menu. 2. Navigate to the Out Mode menu. 3. Enter the Out Mode submenu. 4. Select the desired setting and confirm. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 25: User Setting Menu

    To change the COLOR user settings: 1. Bring up the OSD main menu. 2. Set the Out Mode to COLOR (User), see "Out Mode menu", page 22. 3. Navigate to the User Setting menu. 4. Enter the User Setting submenu. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 26: User Setting (Rgb Set)

    It is possible to choose among the following values: 10”, 20”, 30”, 45”, 60”, 90” or disable. When the time-out is set to disable, the OSD menu won’t disappear until the user exit the OSD menu pressing the Esc key. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 27: Time-Out Lcd

    • F/W: Firmware release • FDL: FPGA Dual Link firmware release To view the product info: 1. Bring up the OSD main menu. 2. Navigate to the Product info menu. 3. Enter the Product info submenu. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 28: Service Menu

    FULL: Password is required entering at Main menu level. To change key lock: 1. Bring up the OSD main menu. 2. Navigate to the Service menu. 3. Enter the Service submenu. 4. Change the status of key lock as desired and confirm. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 29: Important Information

    This equipment must be earthed. • Power requirements: The equipment must be powered by the AC mains voltage. • The equipment should be installed near an easily accessible outlet. • The equipment is intended for continuous operation. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 30: Power Cords

    Sufficient expertise is required for installing this equipment, especially to determine the strength of the wall for withstanding the display’s weight. Be sure to entrust the attachment of this equipment to the wall to licensed contractors of Barco and pay adequate attention to safety during the installation and usage.

  • Page 31: Environmental Information

    For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 32 (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section "Limit Requirements of toxic substances in Electronic Information Products".

  • Page 33: Biological Hazard And Returns

    “Electronic Information Products Pollution Control Labeling Standard” of Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “Standard of Electronic Information Products Environmental Friendly Use Period”...

  • Page 34: Regulatory Compliance Information

    • 0.5 percent Chiorhexidine in 70 percent isopropyl alcohol. • Like Cleansafe® optical cleaning liquid Explanation of symbols Symbols on the device On the device or power supply, you may find the following symbols (nonrestrictive list): (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 35 Indicates the temperature limitations for the device to safely operate within specs. Indicates the device serial no Warning: dangerous voltage Caution Consult the operating instructions 1. Values for xx and yy can be found in the technical specifications paragraph. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 36: Legal Disclaimer

    Barco software products are the property of Barco. They are distributed under copyright by Barco N.V. or Barco, Inc., for use only under the specific terms of a software license agreement between Barco N.V. or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized.
  • Page 37 Operating temperature 10-35°C for performance / 0-40°C for safety Storage temperature -20 ÷ +60°C Operating humidity 10 ÷ 90% (non-condensing) Storage humidity 10 ÷ 90% (non-condensing) Operating altitude 3000 m max. Storage altitude 12000 m max. (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 38 6. Important information Dimensions 1318.5 459.25 459.25 Image 6-2 Dimensions MDSC-8258 (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 39: Open Source License Information

    Open source license usage This product contains software components released under an Open Source license. A copy of the source code is available on request by contacting your Barco customer support representative. EACH SEPARATE OPEN SOURCE SOFTWARE COMPONENT AND ANY RELATED DOCUMENTA- TION ARE PROVIDED "AS IS"...
  • Page 40 You acknowledge living up to the conditions of each separate Open Source Software license. A list of the Open Source Software components used is available in the applicable EULA, through the (customer section of the) Barco website or through other (online) means. (451920611502) K5902088 MDSC-8258 08/09/2014...

  • Page 41: A. Appendix A

    “string” is a 3 character ASCII string with the desired backlight brightness in the range from 40 to 700 (cd²/m). 2) Input Management: PC > monitor: <ESC>i “crt” where “crt” has the following meaning: (character) Action <CR> Query Select DVI Input 1-3 Select DVI Input 2-4 (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 42 T° from 2000° to 12000° the character O in the command sequence is the letter “o” in uppercase. 4b) Set Transfer Function: PC > monitor: <ESC> O (character) monitor > PC: <ACK> where (character) has the following meaning: (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 43 6a) Get Monitor Power Status: PC > monitor: <ESC> S <CR> monitor > PC: “crt” <ACK> where (character) has the following meaning: (character) Monitor on / off 0 (zero) 6b) Switch Monitor ON/OFF: PC > monitor: <ESC> S (character) (451920611502) K5902088 MDSC-8258 08/09/2014...
  • Page 44 “?” character ENTER ▼ ▲ Escape 9) Working hours of the monitor: PC > monitor: <ESC> rWH <CR> monitor > PC: “string” <CR> <LF> where “string” is: an ASCII string with the working hours number (example “67”). (451920611502) K5902088 MDSC-8258 08/09/2014...
