- Page 1 MDSC-8231 31” UHD 4K surgical display User Guide MDSC-8231 12G ENABLING BRIGHT OUTCOMES...
- Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
-
Page 3: Table Of Contents
VESA mount installation ................................21 4 Daily operation ......................................23 On/Off switching ....................................24 Keyboard locking/unlocking ..............................24 Power status LED ..................................25 OSD menu activation..................................25 OSD menu navigation ..................................25 Shortkey functions..................................26 4.6.1 Main source selection...............................26 4.6.2 Brightness adjustment..............................26 Control lock: OSD menu locking/unlocking........................27 R5911692 /01 MDSC-8231... - Page 4 DVI output ..................................42 5.5.6 Operating hours ................................42 6 Troubleshooting ......................................43 Troubleshooting list..................................44 7 Important information..................................45 Safety information...................................46 Environmental information.................................49 Biological hazard and returns ..............................51 Cleaning and disinfection ................................51 Regulatory compliance information ............................51 EMC notice ......................................52 Explanation of symbols................................56 R5911692 /01 MDSC-8231...
- Page 5 Legal disclaimer....................................59 Technical specifications................................60 R5911692 /01 MDSC-8231...
- Page 6 R5911692 /01 MDSC-8231...
-
Page 7: Welcome
Welcome! R5911692 /01 MDSC-8231... -
Page 8: About The Product
(BLOS), the surgical display also ensures a long lifetime and low power consumption. Ease of installation The MDSC-8231 comes with a smart cable management system that hides the cables for a clutter-free set-up. Equipped with VESA 100 and VESA 200 interface to allow easy mounting on surgical booms and spring arms. -
Page 9: About This User Guide
1.3 About this user guide Overview This manual provides support to the user during the installation, set up and utilization of the MDSC-8231 display. Depending on the specific version that has been purchased, some of the features and options described in this document may not apply to the display in user’s hands. - Page 10 Welcome! R5911692 /01 MDSC-8231...
-
Page 11: Parts, Controls And Connectors
Parts, controls and connectors R5911692 /01 MDSC-8231... -
Page 12: Front View
Keyboard lock/unlock button (membrane switch at the bottom of the display) The keyboard lock/unlock button may be activated accidentally when placing the display on a flat surface with the bottom facing downwards. Persistent key pressures will automatically be ignored by the keyboard control SW however. R5911692 /01 MDSC-8231... -
Page 13: Rear View
DVI-D in DVI-D out Potential Equalization pin (POAG) (Left) DisplayPort in 24 VDC power in The BNC SDI connectors match the characteristic impedance of 75 ohm cables. See “SDI config”, page 35 about the possible SDI configuration modes. R5911692 /01 MDSC-8231... -
Page 14: Connector Pin Assignments
D0_Rx+ (T.M.D.S.) GND (data 0 shield) Not connected Not connected GND (clock shield) CK_Rx+ (T.M.D.S.) CK_Rx- (T.M.D.S.) (*) +5 VDC output selectable on either pin 14 or 16 via the OSD menu. (+5V ± 10% @ 500mA (max)) R5911692 /01 MDSC-8231... -
Page 15: Usb Type A Connector
Overview (sink side pin-out) 19 17 15 13 11 9 20 18 16 14 12 10 8 Image 2-9 ML_Lane 3 (n) ML_Lane 3 (p) ML_Lane 2 (n) ML_Lane 2 (p) ML_Lane 1 (n) ML_Lane 1 (p) ML_Lane 0 (n) R5911692 /01 MDSC-8231... -
Page 16: Hdmi Connector
T.M.D.S. Data1+ T.M.D.S. Data1 Shield T.M.D.S. Data1- T.M.D.S. Data0+ T.M.D.S. Data0 Shield T.M.D.S. Data0- T.M.D.S. Clock+ T.M.D.S. Clock Shield T.M.D.S. Clock- Not connected DDC_SCL DDC_SDA DDC/CEC GND +5VDC POWER 2.4.8 DC out connector Overview Image 2-11 +5 VDC R5911692 /01 MDSC-8231... -
Page 17: Installation
Installation R5911692 /01 MDSC-8231... -
Page 18: Cover Removal
Picture input”, page 37 and “Picture in Picture input”, page 38 for more information. Beside the video input connections, the MDSC-8231 also has video output capabilities allowing you to loop- through or duplicate all video inputs connected with the MDSC-8231 to another display, projector, video recorder, ... -
Page 19: Power Supply Connection
CAUTION: To avoid risk of electric shock, the external DC power supply must be connected to a mains with protective earth. The ground connection on the display’s DC power input connector has no protective earth function. The MDSC-8231 display protective earth connection is provided via a dedicate pin (see next steps). -
Page 20: Cable Routing
Installation Protective earth Earth the MDSC-8231 by connecting the protective earth pin to a grounded outlet by means of a yellow/green AWG18 wire (maximum admitted cable length according to national regulation requirements). Image 3-4 CAUTION: The display must be earthed. -
Page 21: Vesa Mount Installation
Depending on the VESA plate thickness (T) and the thickness of possible washers (W), a different screw length (L) should be selected. Please respect the following rule to select an appropriate screw length: • = T + W + 15 mm • = T + W + 18 mm R5911692 /01 MDSC-8231... - Page 22 CAUTION: Use an arm that is in compliance with VESA requirements. CAUTION: The monitor VESA interface has been designed for a safety factor 6 (to support 6 times the monitor weight). In the medical system, use an arm with suitable safety factor (IEC60601–1). R5911692 /01 MDSC-8231...
-
Page 23: Daily Operation
Daily operation R5911692 /01 MDSC-8231... -
Page 24: On/Off Switching
Afterwards, release the key again (within 2 seconds) to avoid a keyboard re-lock. To lock the keyboard The keyboard will automatically lock after 10 seconds of inactivity, except while navigating the OSD menu, during which it remains unlocked. R5911692 /01 MDSC-8231... -
Page 25: Power Status Led
Below is an example of the OSD menu structure: Picture Picture 1024x768@100 Hz Profile Factory Picture Brightness advanced Contrast Input select Saturation Configuration Color temperature 6500K Color space ITU709 System Gamma Native Sharpness Image 4-2 Menu pages Sub-menus (menu items) Status bar R5911692 /01 MDSC-8231... -
Page 26: Shortkey Functions
27). 4.6.2 Brightness adjustment To quickly adjust the brightness Unlock the keyboard (see “Keyboard locking/unlocking”, page 24) While no OSD menu is on the screen, press the key to adjust the brightness as desired. Brightness Image 4-4 R5911692 /01 MDSC-8231... -
Page 27: Control Lock: Osd Menu Locking/Unlocking
OSD lock window appear. The OSD menu can only be accessed after pressing a sequence of keys. Image 4-5 To lock/unlock the menu Unlock the keyboard (see “Keyboard locking/unlocking”, page 24) Press the key. When the OSD lock window appears, press the following key sequence to unlock the OSD menu: , , , R5911692 /01 MDSC-8231... - Page 28 Daily operation R5911692 /01 MDSC-8231...
-
Page 29: Advanced Operation
Advanced operation Not all features described in the chapter “Advanced operation” are available. The features not available in specific software versions are grayed out in the OSD menu. R5911692 /01 MDSC-8231... -
Page 30: Picture Menu
Brightness level is adjusted by controlling the backlight illumination only. 5.1.3 Contrast To adjust the contrast level Bring up the OSD main menu. Navigate to the Picture menu. Enter the Contrast submenu. The command bar Contrast is highlighted. Set the contrast level as desired and confirm. R5911692 /01 MDSC-8231... -
Page 31: Saturation
Factory calibration – Color space: RGB primary calibration, according to the selected standard, is performed within the physical limitation of the LCD panel used. To select a color space preset Bring up the OSD main menu. Navigate to the Picture menu. R5911692 /01 MDSC-8231... -
Page 32: Gamma
To adjust the black level Bring up the OSD main menu. Navigate to the Picture advanced menu. Enter the Black Level submenu. The command bar Black Level is highlighted. Set the black level as desired and confirm. R5911692 /01 MDSC-8231... -
Page 33: Latency
In both Aspect and Native, the image may be displayed with black bars on top/bottom or left/right. To select the image size Bring up the OSD main menu. Navigate to the Picture Advanced menu. Enter the Image Size submenu. Select one of the available image sizes and confirm. R5911692 /01 MDSC-8231... -
Page 34: Image Flip
The available main sources for your display are: • • SDI 4K • • DisplayPort • HDMI–1 • HDMI–2 The main source can also be quickly selected through the Input selection key ( ), without the need to navigate through the OSD menu. R5911692 /01 MDSC-8231... -
Page 35: Displayport Mode
Dual SDI (Dual input: SDI 1 up to 12G-SDI, SDI 3 up to 3G-SDI) • Single SDI-1 (up to 12G-SDI) • Single SDI-3 (up to 12G-SDI) To select the SDI config mode Bring up the OSD main menu. Navigate to the Input Select menu. R5911692 /01 MDSC-8231... -
Page 36: Auto Search
During the transition from main to failover input and vice versa, a text message is visible to inform the user. The main source can be changed while the failover input remains unchanged. During the selection and synchronization of a new main source the failover function is temporary (7 sec) disabled. R5911692 /01 MDSC-8231... -
Page 37: Picture And Picture Input
(*) SDI 3 is only available if the SDI configuration mode is Dual SDI. To select Picture and Picture input Bring up the OSD main menu. Navigate to the Input Select menu. Enter the PaP Input submenu. Select one of the available PaP sources (or NONE) and confirm. R5911692 /01 MDSC-8231... -
Page 38: Picture In Picture Input
Bottom right • Top right To select Picture in Picture position Bring up the OSD main menu. Navigate to the Input Select menu. Enter the PiP Position submenu. Select one of the available PiP positions and confirm. R5911692 /01 MDSC-8231... -
Page 39: Picture In Picture Transparency
About OSD time-out The OSD menu can automatically close after a certain time of inactivity after the last selection was made. The available OSD time-out values for your display are: • 10 Sec. • 20 Sec. • 30 Sec. R5911692 /01 MDSC-8231... -
Page 40: Recall Profile
Select one of the available profiles to save and confirm. 5.5 System menu 5.5.1 Power on DVI About power on DVI This setting allows you to select the pin of the DVI connector on which the +5V DC supply is applied. R5911692 /01 MDSC-8231... -
Page 41: Power On Displayport
(are) missing. To enable/disable power saving Bring up the OSD main menu. Navigate to the System menu. Enter the Power Saving submenu. Enable/Disable power saving as desired and confirm. R5911692 /01 MDSC-8231... -
Page 42: Dvi Output
This information shows the operation hours of your display. To consult operating hours Bring up the OSD main menu. Navigate to the System menu. The operation hours of your display are shown at the bottom of the menu. R5911692 /01 MDSC-8231... -
Page 43: Troubleshooting
Troubleshooting R5911692 /01 MDSC-8231... -
Page 44: Troubleshooting List
(maximum 2 seconds). behavior. Half of the screen corrupt After switching from a profile with Reselect the input or reboot the HDMI UHD 4:2:0 input to another display. profile with the same input, half of the screen is corrupt. R5911692 /01 MDSC-8231... -
Page 45: Important Information
Important information R5911692 /01 MDSC-8231... -
Page 46: Safety Information
(no applied part). • The equipment shall not be used with life support equipment. • The user should not touch the equipment, nor its signal input ports (SIP)/signal output ports (SOP) and the patient at the same time. R5911692 /01 MDSC-8231... - Page 47 Moisture may condense on the surface or inside of the unit, or create a mist residue inside the protection plate, this is not a malfunction of the product itself, although it may cause damage to the monitor. • If condensation happens, let the monitor stand unplugged until there is no condensation. R5911692 /01 MDSC-8231...
- Page 48 Sufficient expertise is required for installing this equipment, especially to determine the strength of the wall for withstanding the display's weight. Be sure to entrust the attachment of this equipment to the wall to licensed contractors of Barco and pay adequate attention to safety during the installation and usage. •...
-
Page 49: Environmental Information
Electronic Products ” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”. - Page 50 Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products” of Chinese Mainland.
-
Page 51: Biological Hazard And Returns
Intended usage environment • Equipment primarily for use in a health care facility that is intended for use where contact with a patient is unlikely (no applied part). • The equipment shall not be used with life support equipment. R5911692 /01 MDSC-8231... -
Page 52: Emc Notice
The manufacturing country of the product is indicated on the product label (“Made in …”). Importers contact information To find your local importer, contact one of Barco’s regional offices via the contact information provided on our website (www.barco.com). FCC class B This device complies with Part 15 of the FCC Rules. - Page 53 Electromagnetic emissions The MDSC-8231 is intended for use in the electromagnetic environment (IEC 60601-1-2 4 edition) specified below. The customer or the user of the MDSC-8231 should assure that it is used in such an environment. Electromagnetic environment – Compliance...
- Page 54 (>95% dip in U < 5% U (>95% dip in U recommended that the for 5 seconds for 5 seconds MDSC-8231 be powered from an uninterruptible power supply or a battery. Power frequency (50/60 30 A/m 30 A/m Power frequency...
- Page 55 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the MDSC-8231 is used exceeds the applicable RF compliance level above, the MDSC-8231 should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the MDSC-8231.
-
Page 56: Explanation Of Symbols
Important information maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the MDSC-8231 as recommended below, according to the maximum output power of the communications equipment. Separation distance according to frequency of transmitter Rated maximum output... - Page 57 Indicates the DisplayPort connectors on the device. Indicates the legal manufacturer. Indicates the manufacturing date. Indicates the temperature limitations for the device to safely operate within specs. Values for xx and yy can be found in the technical specifications paragraph. R5911692 /01 MDSC-8231...
- Page 58 European WEEE (Waste Electrical and Electronic Equipment) directive. Indicates Direct Current (DC). Indicates Alternating Current (AC). Stand-by Equipotentiality Protective earth (ground) Symbols on the box On the box of the device, you may find the following symbols (nonrestrictive list): R5911692 /01 MDSC-8231...
- Page 59 Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized.
- Page 60 12G-SDI (10 bit): SMPTE ST-2082-10 QUAD LINK 3G-SDI (10 bit): SMPTE ST 425-5 (Level A) 3G-SDI (10 bit) : SMPTE ST 424/425 (Level A) HD-SDI (10 bit): SMPTE ST 292 DP 1.2 SST to HDMI 2.0 adapter available from Barco R5911692 /01 MDSC-8231...
- Page 61 -20 ÷ +60°C Operating humidity 10 ÷ 90% (non-condensing) Storage humidity 5 ÷ 90% (non-condensing) Protection level IP20 (IP45 front side only) Warranty 3 years Timings full-HD & 4MP Format HDMI DP 1.1 720x480p@59.94Hz 720x480p@60.00Hz 720x576p@50.00Hz 800x600p@56.25Hz R5911692 /01 MDSC-8231...
- Page 62 Important information 800x600p@60.317Hz 800x600p@72.19Hz 800x600p@75.00Hz 1024x768p@60.004Hz 1024x768p@70.069Hz 1024x768p@75.029Hz 1024x768p@85.00Hz 1152x864p@75.00Hz 1280x720p@29.97Hz 1280x720p@30.00Hz 1280x720p@50.00Hz 1280x720p@59.94Hz 1280x720p@60.00Hz 1280x1024p@60.013Hz 1280x1024p@75.025Hz 1280x1024p@85.00Hz 1400x1050p@60.00Hz 1600x1200p@60.00Hz 1680x1050p@59.95Hz 1920X1080i@50Hz 1920X1080i@59.94Hz 1920X1080i@60Hz 1920x1080p@25Hz 1920x1080p@29.97Hz 1920x1080p@30.00Hz 1920x1080p@50.00Hz 1920x1080p@59.94Hz 1920x1080p@60.00Hz 1920x1200p@60.00Hz 2048x1536p@60.00Hz 2560x1440p@60.00Hz 2560x1600p@60.00Hz R5911692 /01 MDSC-8231...
- Page 63 Important information Timings UHD / 4K Format HDMI DP 1.1 DP 1.1 DP 1.2 Quad-SDI 12G-SDI Dual 3840x2160@25.00Hz 3840x2160@30.00Hz 3840x2160@50.00Hz 3840x2160@60.00Hz 4096x2160@25.00Hz 4096x2160@30.00Hz 4096x2160@50.00Hz 4096x2160@60.00Hz (*) Accepted formats: Square-division & 2-sample interleave Dimensions 288.5 Image 7-1 R5911692 /01 MDSC-8231...
- Page 64 Barco NV President Kennedypark 35 8500 Kortrijk Belgium R5911692 /01 | 2020-03-09 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com...
