PCS-XG100/XG77 System Integration Manual
Rear Panel (Photo: PCS-XG100S)
(1)
(2)
(9)
(10)
No
Connector
(1)
CAMERA IN
(2)
HDMI IN *Note
(3)
DVI-I 1 IN
(4)
DVI-I 2(PC) IN
(5)
MIC(A1) IN
(6)
AUDIO 1 IN
AUDIO 2 IN
(7)
AUDIO OUT
(8)
REC OUT
*Note: HDMI IN, HDMI-2 OUT, and LAN2 connectors are not available on the PCS-XG77S.
HDMI-1 OUT and LAN1 are called HDMI OUT and LAN respectively for the PCS-XG77S.

1.3. Camera Units

Camera unit is not supplied with the codec.
For details on operations and settings, refer to the operating instructions for the camera unit.
1.3.1.
First Camera Selection
Video signal
Horizontal field of view
Optical zoom (digital)
Interface
Others
*1 Even when 720 60p was selected by the EVI-H100V/PCSA-CXG100, the PCS-XG100S recognizes
the connected camera and automatically encodes signals to 720 30p.
*2 Turning on the IMAGE FLIP switch on the camera rear panel flips the image upside down.
(3)
(4)
(11)
Remarks
Refer to Sections 1.3.3
and 1.3.5
Refer to Sections 1.3.4
and 1.3.5
Refer to Section 1.3.5
Refer to Section 1.3.5
Refer to Section 1.5.1
PCSA-CXG100
/EVI-H100V
1080 30p/720 30p *1
55.4 degrees
20x (12x)
DVI-I
Exmor, Ceiling mountable *2
(5)
(6)
(12) (13) (14)
(15)
No
Connector
(9)
HDMI-1 OUT *Note
(10)
HDMI-2 OUT *Note
(11)
DVI-I OUT
(12)
LAN 1 *Note
(13)
LAN 2 *Note
(14)
ISDN UNIT
(15)
AUX CONTROL
(16)
MAINTENANCE
EVI-HD7V
1080 60p/720 60p
70 degrees
10x (4x)
DVI-I
4
(7)
(8)
(16)
Remarks
Refer to Section 1.6
Refer to Section 1.7
EVI-HD3V
720 60p
70 degrees
10x (4x)
DVI-I
