PCS-XG100/XG77 System Integration Manual
Echo Canceller (Setup→Audio1)
To enable the echo canceller, make settings as follows:
When the output from PCS-A1 microphone is input to MIC (A1) IN:
Setup Menu
Audio1
When the output from the external microphone is input to AUDIO 1 IN, or AUDIO 2 IN
*Note
through the mixer.
Setup Menu
Audio1
*Note:
・Refer to Section 1.5.2 Note on Using External Microphone.
・It is necessary to set "Audio Input" to "AUX" when the audio signal from external equipment like a DVD
player is input to
AUDIO 1 IN or AUDIO 2. In this case, note that the echo canceller does not work even
with the echo canceller set to "On" by the Setup menu. It is designed on the assumption that the input
level is aligned will the line level.
Item
Audio Input
Input Select (MIC)
Echo Canceller
Item
Audio Input
Input Select (MIC)
Echo Canceller
17
Setting
MIC
MIC(A1)
On
Setting
MIC
AUDIO 1 or
AUDIO 2
On
