PCS-XG100/XG77 System Integration Manual
Notes
･HDMI-2 OUT connector is not available on the PCS-XG77S. HDMI-1 OUT is called HDMI
OUT for the PCS-XG77S.
･The "HDMI 1 + HDMI 2" and "Triple monitors" settings are not available on the
PCS-XG77S.
･Connect a monitor that supports the 1080p video format to the HDMI-2 OUT connector.
･If "Monitor Output" is set to "HDMI 1 + DVI-I OUT", "HDMI 1 + HDMI 2", or "Triple monitors"
when no HDMI monitor is connected to the PCS, you cannot view the menus. Be sure to
connect any HDMI monitor.
･When you change the setting of "MonitorOutput" to an incorrect setting, no picture is
displayed on the screen. In this case, select the correct setting for "Monitor Output" using the
power switch on the PCS and the buttons on the Remote Commander.
When the power switch indicator on the PCS stays lit, perform the steps below.
(1) Press the power switch on the PCS.
(2) Within five seconds after you pressed the switch, press the buttons on the
Remote Commander described below depending on the desired "Monitor Output".
HDMI 1: VIDEO INPUT button (once) then Number button 3 (three times)
DVI-I OUT: VIDEO INPUT button (once) then Number button 4 (three times)
(3) The setting of "Monitor Output" is changed, and the picture will be displayed on the
screen.
To be displayed on each monitor by monitor mode
Monitor
Single
mode
Monitor
HDMI1 or
Status
DVI-I
Home
Near Video
Screen
During
Far Video
conference
Sending
Near Presen
H.239
Receiving
Far Presen
H.239
Dual Monitor
HDMI1
HDMI2 or
DVI-I
Near Video
Near Video
Far Video
Near Video
Far Video
Near Presen
Far Video
Far Presen
19
Triple Monitor
(PCS-XG100S only)
HDMI1
DVI-I
Near Video
Near Video
Far Video
Near Video
Far Video
Near Presen
Far Video
Far Presen
HDMI2
Near Video
Near Video
Near Video
Near Video
