PCS-XG100/XG77 System Integration Manual
1.3.5.
Supported Input Signals
Connector
CAMERA IN
Signal
DVI-D
HDMI
YPbPr
RGB
* 1: Connecting a camera with HDMI I/F: By using the camera cable supplied and DVI-HDMI Adaptor etc.,
only the video signal can be input
* 2: Connecting a camera with HDMI I/F: By using a DVI-HDMI Adaptor etc., only the video signal can be
input
* 3: Sending presentation data by connecting a PC with HDMI I/F: By using a DVI-HDMI Adaptor etc.,
only the video signal can be input
* 4: Connecting a camera with YPbPr I/F: DVI-to-YPbPr conversion cable etc., is required
* 5: Connecting a camera with RGB I/F: DVI-to-RGB conversion cable etc., is required
* 6: Sending presentation data by connecting a PC with RGB I/F: DVI-to-RGB conversion cable etc., is
required
DVI-I IN
Yes *1
Yes *2
No
No
No
Yes *4
No
No
DVI-I 2 (PC) IN
Yes *2 *3
No
No
Yes *5 *6
8
HDMI IN
(PCS-XG100S only)
No
Yes
No
No
