PCS-XG100/XG77 System Integration Manual
1.6. Connecting Monitor
Up to 3 monitors can used with the PCS-XG100S, and up to 2monitors with PCS-XG77S.
Setup Menu Settings:
Setup Menu
Video 1
Monitor Output
DVI-I
Output Format
Item
HDMI 1
DVI-I OUT
HDMI 1 +
DVI-I OUT
HDMI 1 +
HDMI 2
Triple
Monitors
Monitor
XGA
WXGA
SXGA
1080i
1080p
Setting
Outputs the video signal to the external equipment
connected to the HDMI-1 OUT connector in the single
monitor mode
Outputs the video signal to the external equipment
connected to the DVI-I OUT connector in the single
monitor mode
Outputs the video signal to the external equipment
connected to the HDMI-1 OUT and DVI-I OUT
connectors in the dual monitor mode
Outputs the video signal to the external equipment
connected to the HDMI-1 OUT and HDMI-2 OUT
connectors in the dual monitor mode
Outputs the video signal to the external equipment
connected to the HDMI-1 OUT and DVI-I OUT
connectors, and the external equipment connected to
the HDMI-2 OUT connector in the triple monitor mode
Select video format for the DVI-I OUT connector output.
Notes
When "Monitor Output" is set to "HDMI 1 + HDMI 2,"
the "DVI-I Monitor Output Format" setting determines
the video format output for the monitor connected to the
HDMI-2 OUT connector.
