SPECIFICATIONS*
VIDEO
Image Sensor
Active Pixels
Scanning System
Frequency
Synchronization
Horizontal Resolution
Minimum Illumination
S/N Ratio
Video Output
Alarm Output
LENS
Focal Length
IR Distance
OPERATIONAL
Shutter Speed
Backlight
Star-Light (Sense-Up)
3D-DNR
White Balance
1/3" Sony 1 3 Mega Pixel CMOS Sensor
1280 (H) x 1024 (V)
2 : 1 Interlace
15.734KHz (H), 59.95Hz (V)
Internal
820 TV Lines [B/W], 800 TV Lines [Color]
F1.2 (30IRE): 0.0 Lux
55dB (AGC off)
CVBS: 1 0Vp-p / 75 Ω
1 Alarm Output
2.8 ~ 12mm [DWC-B5661TIR]
5 ~ 50mm [DWC-B5661TIR550]
100ft Range IR [DWC-B5661TIR]
150ft Range IR [DWC-B5661TIR550]
50(60) ~ 60,000s
OFF / HME / BLC / WDR
OFF / x2 ~ x64
OFF / Low / Middle / High
ATW /AWB/ PUSH / MANUAL
29
