Page 1: User Manual
DWC-B362DIR Digital Bullet Camera User Manual ABOUT MANUAL Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference. 01312011... - Page 2 PRECAUTIONS Do not open or modify. Do not open the case except during maintenence and installation, for it may be dangerous and can cause damages. Do not put objects into the unit. Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages.
- Page 3 TROUBLESHOOTING Before sending your camera for repair, check the following or contact our technical specialist. No VIDEO Check the coaxial cable and make sure it is connected securely. Check the lens’ iris adjustment at the menu setup of the camera. Check the power supply and make sure the camera has the proper voltage and current.
-
Page 4: Dimensions In Millimeters
DIMENSIONS IN MILLIMETERS*... -
Page 5: Control Board
CONTROL BOARD* CON 1 FUNCTIONAL OF CONTROL BOARD [1] SW : Functional control of OSD (On Screen Display) [2] CON 1 :Second Video Output Connector... - Page 6 CONNECTIONS* CAUTION : Check for polarity when using a DC 12V & AC 24V power supply.
-
Page 7: Camera Setting Angle
CAMERA SETTING ANGLE* ① ② ATTENTION Do not rotate ① more than 360° Do not unnecessarily twist ② too many times. -
Page 8: Osd Menu Settings
OSD MENU SETTINGS* EXPOSURE LENS DC / MANUAL SHUTTER 1/160, 1/100, FLC, 1/250 ~ 100000 OFF / ON BLC (Back Lignt Compensation) OFF ~ 36dB EXIT JUMP COLOR WB MODE AWC / ATW / PUSH LOCK / MANUAL (AWC is recommended.) R - Y GAIN 0 ~ 255 B - Y GAIN... - Page 9 MOTION MOTION OFF / ON SET WINDOW ALL SET (Set the Entire Screen) ALL CLEAR (Clear the Entire Screen) SENSITIVITY (0 ~ 55) SHOW INDICATOR (OFF / Icon / TRACE) DELAY OUT (1 ~ 15) Motion Alarm Zoom-In Delay EXIT JUMP PRIVACY MASK 1 OFF / ON...
- Page 10 SETUP CAMERA ID 0 ~ 255 TITLE EDIT TITLE RESET TITLE POS. TOP_L/TOP_R/BOT_L/BOT_R DPC SET OFF / ON WHITE THR. 0~255 BLACK THR. 0~255 DPC LEVEL. 0~255 LANGUAGE English, Chinese PC CONT. OFF / ON EXIT JUMP EXIT EXIT SAVE & EXIT FACTORY SET...
-
Page 11: Warranty Information
WARRANTY INFORMATION* Digital Watchdog (referred to as “the Warrantor”) warrants Camera Series against defects in materials or workmanship as follows. LABOR : For the initial two (2) years from the date of original purchase, if the camera is determined to be defective, the Warrantor will repair or replace the unit, with new or refurbished product at its option, at no charge. -
Page 12: Limits And Exclusions
LIMITS AND EXCLUSIONS* There are no express warranties except as listed above. The Warrantor will not be liable for incidental or consequential damages (including, without limitation, damage to recording media) resulting from the use of these products, or arising out of any breach of the warranty. -
Page 13: Specifications
SPECIFICATIONS* Specifications B362DIR Model Camera TYPE Color/BW Ture Day/Night Digital Bullet IR Camera 1/3" Super HAD II CCD Image Device Pixels-Total 811(H) x 508(V) 795(H) x 596(V) Pixels-Effective 768(H) x 494(V) 752(H) x 582(V) Scanning System 525 line, 2:1Interlace 625 line, 2:1Interlace Horizontal Frequency Internal Mode 15,734Hz( =NTSC ) 15,625Hz( =PAL ) - Page 14 5436 W Crenshaw St. Tampa, FL 33634 Tel : 866-446-3595 / 813-888-9555 Fax : 813-888-9262 www.Digital-Watchdog.com technicalsupport@dwcc.tv Technical Support Hours : Monday-Friday 8:30am to 8:00pm Eastern Time...
