DAY & NIGHT
CONTROL (CONT.)
- CDS: The camera's Day/ Night switch will be set according to the LED board in the camera.
* CDS Threshold: Marks he light level at which the camera will switch between color and B/W.
The lower the value, the camera will require less light (more darkness)
to switch to Night Mode.
* CDS Signal: The value added to the CDS Threshold. Adjust his value
based on the environment in which the camera is installed.
- Night Mode: Select what will the camera do when the light threshold is
met for "Night Model". Select to keep in color, or switch to B&W.
- At the bottom of the screen, the settings will be summarized for your
review. The information includes (according to current settings), the CDS
threshold for Day to switch to Night, CDS threshold for Night to switch
back to Day, and current CDS level, for reference.
EXT LED
AUTO / OFF AUTO: Enables the IR LED board. OFF: disable the camera's LEDs.
DELAY
Low/Mid/High Time interval delay before switching from day mode to night mode.
B&W BURST
ON / OFF If ON is selected, the camera provides a color burst signal in night mode.
SMART IR
0 ~ 20 Enable Smart IR and set the level. Higher values will make Smart IR stronger.
